- Page 1 Personal Video Recorder Operation Manual CSD-M4...
-
Page 2: Safety Information
Preface This user manual teaches you about the SD Video Recorder and how to make full use of its features. Information contained in this manual has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. -
Page 3: Table Of Contents
TABLE OF CONTENTS 1. Introduction ..................2. Main Features ..................3. Accessories ..................4. Overview of the Remote Control ............. 5. Using the CSD-M4 ................6. Turning on Power ................7. System Menu ..................7.1 Initial Setup .................. 7.1.1 System Language .............. -
Page 4: Introduction
1. Introduction SD Video Recorder (CSD-M4) is the most valuable add-on to any home theater settings. This is great replacement to traditional VCR or even DVD-RW recorders, with their compact size and superior support to variable mobile devices. CSD-M4 can perfectly serve as the data center of all incoming multimedia. -
Page 5: Overview Of The Remote Control
4. Overview of the Remote Control 1. Power: Switch CSC-M4 on or off. Source Power 2. Source: Choose AV/YUV/SV/USB mode. Quality Edit Zoom 3. Quality: Record Pause Rotate Choose the recording quality HQ/SP/LP. 4. Edit: Edit the file name, delete the file or Play mode. 5. -
Page 6: Using The Csd-M4
5. Using the CSD-M4 After connecting the CSD-M4 to the TV and Power on, you are ready to start the CSD-M4. This chapter describes how to turn on the device and how to control On-Screen Display (OSD) menu to configure the device settings. -
Page 7: Initial Setup
7.1 Initial Setup The Initial Setup item guides you to set up CSD-M4 step by step. Press [OK] to enter the Initial Setup 7.1.1 System Language Press [ ▲ / ▼ / / ] to select language. Press [OK] to confirm the selection 7.1.1.1 TV Type... -
Page 8: Enter
Press [ ▲ / ▼ ] to select display type Presses [OK] to confirm the selection, after confirm the Format selection, the CSD-M4 will erase all data on USB/HDD device and re-create a FAT file system. Select "No" to return to the format selection. -
Page 9: Setup
7.3 Setup Press [ ▲ / ▼ ] to select display type. Press [OK] to confirm the selection. 7.3.1 System Press [ ▲ / ▼ / / ] to select the system setup. Press [OK] to confirm the selection. 7.3.1.1 TV System Press [ ▲... -
Page 10: Screen Saver
7.3.1.2 Screen Saver Press [ ▲ / ▼ / / ] to turn on/off the screen saver. Press [OK] to confirm the selection. 7.3.1.3 System Language Press [ ▲ / ▼ / / ] to select the language format or return. Press [OK] to confirm the selection. -
Page 11: Set Date
7.3.1.5 Set Date Press [ ▲ / ▼ / / ] to set system date. Press [OK] to confirm the selection. 7.3.1.6 Set Time Press [ ▲ / ▼ / / ] to set system time. Press [OK] to confirm the selection. 7.3.1.7 Reset Setting Press [OK] to rest the system back to the factory setting 7.3.2 A/V Set... -
Page 12: Video Output
7.3.2.1 Video Output Press [ ▲ / ▼ / / ] to select the output system setup (YCbCr or P-SCAN system). Press [OK] to confirm the selection 7.3.2.2 TV Type Press [ ▲ / ▼ / / ] to select display type. There are PS 4:3, LB 4:3 and 16:9. (PS 4:3 means 4:3 Pan Scan;... -
Page 13: Hdd Browser
7.4 USB Browser Press [OK] to confirm the selection. The system will view the USD device folders. Please refer to system menu as above. 7.4.1 Edit After confirm the selection file, press [Edit] the screen will pop up the selection. Play Mode: Playing file (SEQ Play: Sequence Play, File Rep: File Repeat and Dir Rep: Directory Repeat) Rename: Enter the text input interface to rename the selected file... -
Page 14: Csd-M4 Connections
S-Video Video Audio R/L CSD-M4 supports multiple inputs from other video equipment and output can select the desire source to enjoy the high quality video. When making this connection, ensure you connect the video/audio cables to the corresponding video/audio input terminals on the CSD-M4. -
Page 15: Appendix
9. Appendix Specifications Component with Audio R/L Input ports S-Video with Audio R/L Video with Audio R/L Component S-Video Output ports Video Audio R/L Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/UL certi- Remote Control Discrete IR remote Chassis Material Metal with Plastic Silk Skin Color White with Black Operating Temperature... -
Page 16: Troubleshooting
CSD-M4 input connectors. Volume too low Increase volume setting for No Volume or muted from the the TV or the CSD-M4. CSD-M4 or TV. Make sure the correct TV LR cable may not input source. Refer to the connect correctly.
