Internal Use Only Website http://biz.lgservice.com Mini Hi-Fi System SERVICE MANUAL MODEL: MCV1306 (MCV1306, MCS1306F/S/W) CAUTION BEFORE SERVICING THE UNIT, READ THE “SAFETY PRECAUTIONS” IN THIS MANUAL. P/NO : AFN74972291 AUGUST, 2011...
Page 2
CONTENTS SECTION 1 ..GENERAL SECTION 2 ..CABINET & MAIN CHASSIS SECTION 3 ..ELECTRICAL SECTION 4 ..REPLACEMENT PARTS LIST...
SERVICING PRECAUTIONS NOTES REGARDING HANDLING OF THE PICK-UP 1. Notes for transport and storage 1) The pick-up should always be left in its conductive bag until immediately prior to use. 2) The pick-up should never be subjected to external pressure or impact. Storage in conductive bag Drop impact 2.
Page 5
NOTES REGARDING COMPACT DISC PLAYER REPAIRS 1. Preparations 1) Compact disc players incorporate a great many ICs as well as the pick-up (laser diode). These components are sensitive to, and easily affected by, static electricity. If such static electricity is high voltage, components can be damaged, and for that reason components should be handled with care.
ESD PRECAUTIONS Electrostatically Sensitive Devices (ESD) Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive Devices (ESD). Examples of typical ESD devices are integrated circuits and some field-effect transistors and semiconductor chip components. The following techniques should be used to help reduce the incidence of component damage caused by static electricity.
SERVICE INFORMATION FOR EEPROM POWER ON FLD no disc status Remote control ‘ ’ + Front ‘STOP’ DETECT NEW EEPROM push same timing during 5s (OPTION EDIT SCREEN) NAME FLD ‘OP-0…. Move to appropriate position and make changes with remote control. /■...
PROGRAM DOWNLOAD GUIDE 1. AUDIO PROGRAM Download program file name must be MCV1306_YYMMDDX.HEX If security program (Water Wall) is activated on your PC, you must save the file to the usb storage device and disable the security software, then download the file to your set. Caution: When downloading the file, you should neither unplug the usb device, change to the other function, nor power off the device.
Page 9
2. CD PROGRAM Download program file name must be HD003_DATE_00.BIN If security program (Water Wall) is activated on your PC, you must save the file to the usb storage device and disable the security software, then download the file to your set. Caution: When downloading the file, you should neither unplug the usb device, change to the other function, nor power off the device.
Page 10
3. BEAT BOX PROGRAM Download program file name must be BEAT_BIN_DATE_00.BIN If security program (Water Wall) is activated on your PC, you must save the file to the usb storage device and disable the security software, then download the file to your set. Caution: When downloading the file, you should neither unplug the usb device, change to the other function, nor power off the device.
SPECIFICATIONS • GENERAL Power requirements Refer to main label Power consumption Refer to main label Dimensions (W x H x D) 285 x 388 x 351 mm without foot Net Weight (Approx.) 7.2 kg Operating temperature 5 °C to 35 °C (41 °F to 95 °F) Operating humidity 5 % to 90 % Bus Power Supply...
Page 12
2. ORDER OF ASSEMBLY FOR MECHANISM DECK ................2-6 EXPLODED VIEWS ........................... 2-11 1. CABINET AND MAIN FRAME SECTION (MCV1306) ................2-11 2. MECHANISM DECK SECTION (CDM-H1803) ..................2-13 3. PACKING ACCESSORY SECTION ....................... 2-15 4. SPEAKER SECTION ..........................2-16...
DISASSEMBLY AND ASSEMBLY FOR MECHANISM DECK (CDM-H1803) 1. ORDER OF DISASSEMBLY FOR MECHANISM DECK 1) Disassemble the Cover Guide Disc. Figure 1 2) Disassemble the Loading FFC from the Main PCB Assy. Turn the Gear in OPEN direction as shown in Figure 2 to take out the Tray Loading Assy in 3 direction.
ORDER OF DISASSEMBLY FOR MECHANISM DECK 4) Loosen the screw to pull up and disassemble the Tray Disc. Figure 4 5) Loosen the screw to pull up and disassemble the Gear Tray CAM. Figure 5 6) Disassemble the Gear Tray, Tray Motor Assy and Loading PCB Assy from the Tray Loading.
ORDER OF DISASSEMBLY FOR MECHANISM DECK Figure 7 7) Disassemble the Harness Cable from the Base Main. Disassemble the Base Sled Assy from the Base Main by referring to Figure. Figure 9 9) Push the Guide UD in direction 1 to disassemble it from the Base Main.
Page 16
ORDER OF DISASSEMBLY FOR MECHANISM DECK 10) Use a solder to remove the Motor Jump Wire from the Main PCB Assy and then disassemble the FFC Cable. Loosen the screw to disassemble the Main PCB Assy. Figure 10...
Page 17
2. ORDER OF ASSEMBLY FOR MECHANISM DECK 1) Assemble the Loading Motor Assy to the Base Main. (When assembling the Motor Assy, use the hook on the surface of the Base Main to preassemble, and then tighten the screws.) Figure 1 2) Set the Guide UD on the Base Main.
ORDER OF ASSEMBLY FOR MECHANISM DECK 3) Set the Gear Loading 1 and Gear Pulley 2 on the Base Main. Hang the belt between the Gear Pulley and Motor Pulley. Assemble the Clamp Disc, Clamp Magnet and Cover Plate to the Base Main. Figure 3 4) After setting the Gear Main 2, Gear Pu Up 3 and Gear Pu Down 4 on the Base Main, tighten the screws.
Page 19
ORDER OF ASSEMBLY FOR MECHANISM DECK Figure 5 Figure 6 5) After setting the Main PCB Assy on the Base Main, 6) Set the Base Sled Assy on the Base Main. tighten the screw. (When setting the part, assemble with the CAM part of (Set the part accurately on the hook) the Guide UD inserted in two locations of the Boss of Solder the Motor Jump Wire on the PCB set on the...
Page 20
ORDER OF ASSEMBLY FOR MECHANISM DECK Figure 7 Figure 8 7) After setting the Gear Tray, Tray Motor Assy and Load- 8) Assemble the Gear Tray CAM on the Tray Loading ing PCB Assy on the Tray Loading, tighten the screw. and set the Tray Disc.
Page 21
ORDER OF ASSEMBLY FOR MECHANISM DECK Figure 9 Figure 10 9) Assemble the Tray Loading Assy on the Base Main 10) After setting the Cover Guide Disc, tighten the screw. Assy as shown in the Figure. After assembling, insert the Loading FFC to the 5 Pin Wafer of Main PCB Assy.
EXPLODED VIEWS NOTES) THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT THE SERVICE PERSONNEL 1. CABINET AND MAIN FRAME SECTION (MCV1306) TO THE PRESENCE OF IMPORTANT SAFETY INFORMATION IN SERVICE LITERATURE. CABLE6 CABLE1 CABLE7 VOLUME iPod SMPS...
Page 28
SECTION 3 ELECTRICAL CONTENTS TRAINING MASTER ........................... 3-2 1. NO SOUND FROM SPEAKERS ......................3-2 2. NO SOUND IN AUX FUNCTION ......................3-3 3. NO SOUND IN PORT. IN FUNCTION ....................3-4 4. NO SOUND IN IPOD FUNCTION ......................3-5 5.
TRAINING MASTER 1. NO SOUND FROM SPEAKERS Make sure to connect the cables to each specified Are the speaker cables connected correctly connector tightly on the unit. between the speaker terminals on the unit Connect the woofer cables to the WOOF SYSTEM and the speakers? connectors on the rear panel.
TRAINING MASTER 2. NO SOUND IN AUX FUNCTION Make sure to connect some cables Does the customer select correctly between the AUX IN jacks of the unit the AUX function he or her wants to listen to? and the Audio output jacks of a external Audio device. After pressing the FUNCTION, Make sure to select the AUX IN function is “AUX”...
TRAINING MASTER 3. NO SOUND IN PORT. IN FUNCTION Make sure to connect a cable Does the customer select correctly between the PORT. IN jack of the unit and the Audio the PORT. IN function he or her wants to listen to? output jack of a portable device like a MP3 player.
TRAINING MASTER 4. NO SOUND IN IPOD FUNCTION Does the customer select correctly Make sure to put a iPod or a iPhone the iPod function he or she wants to listen to? on the docking system on the top of the unit. Make sure that The unit supports the models as follows/iPod nano 1 G, 2 G, 3 G, 4 G, 5 G, 6 G/ Does the customer use the compatible iPod?
TRAINING MASTER 5. NO SOUND IN AM/FM FUNCTION Does the customer select correctly Make sure to connect AM/FM antennas the AM/FM function he or she wants to listen to? on the rear panel of the unit. Make sure to select AM or FM function Is “AM or FM”...
TRAINING MASTER 6. NO SOUND IN CD FUNCTION Does the customer select correctly Make sure to put on a CD disc on the tray. the CD function he or she wants to listen to? Is a CD disc put on the tray correctly? Make sure to insert the CD disc upside down.
Page 35
TRAINING MASTER Are the speaker cables connected correctly Make sure to connect the cables between the speaker terminals on the unit to each specified connector tightly on the unit. and the speakers? The sound is output from the speakers. Sound OK...
TRAINING MASTER 7. NO SOUND IN USB FUNCTION Does the customer select correctly Make sure to insert a USB on the USB ports the USB function he or she wants to listen to? on the bottom of the unit. Make sure to select the USB function Is “USB”...
TRAINING MASTER The sound is output from the speakers. Sound OK 8. NO POWER Is the power cord plugged Make sure to plug the power cord of the unit into a electrical outlet? into a electrical outlet. If the customer can not see the red light Does the Standby LED light on the front panel, the SMPS might have any problem.
ONE POINT REPAIR GUIDE 1. NO POWER If the unit doesn’t work by no power problem, repair the set according to the following guide. 1-1. FUSE & BRIDGE DIODE 1-1-1. Solution Please check and replace F901, BD901, TH901, TH903 on SMPS board. 1-1-2.
Page 39
ONE POINT REPAIR GUIDE NO POWER If the unit doesn’t work by no power problem, repair the set according to the following guide. 1-2. D951, ZD951 1-2-1. Solution Please check and replace D951, ZD951 on SMPS board. 1-2-2. How to troubleshoot (Countermeasure) 1) Check the Anode-Cathod Voltage of D951 with a digital multi-meter, it is normally 0.2 ~ 0.3 V.
ONE POINT REPAIR GUIDE 2. NO BOOTING WHEN POWER ON THE SET The set doesn’t work when press the power button on the front board or the remote control. 2-1. FLASH MEMORY 2-1-1. Solution Please check and replace IC101 on MAIN board. 2-1-2.
ONE POINT REPAIR GUIDE 3. VFD IS NOT DISPLAYED WHEN POWER ON THE SET When power on the set, any icons or characters on VFD are not displayed. 3-1. VFD 3-1-1. Solution Please check and replace DIG301 on FRONT board. 3-1-2.
Page 42
ONE POINT REPAIR GUIDE 4. NO OPERATION OF MD When no sound output in the CD function, you can not listen to music reading data from a CD disc if the servo motors in MD don’t work. This step is for checking the SPINDLE MOTOR among them.
ONE POINT REPAIR GUIDE NO OPERATION OF MD When no sound output in the CD function, you can not listen to music reading data from a CD disc if the servo motors in MD don’t work. This step is for checking the SLED MOTOR among them.
Page 44
ONE POINT REPAIR GUIDE NO OPERATION OF MD When no sound output in the CD function, you can not listen to music reading data from a CD disc if the servo motors in MD don’t work. This step is for checking the TRAY MOTOR among them.
Page 45
ONE POINT REPAIR GUIDE NO OPERATION OF MD When no sound output in the CD function, you can not listen to music reading data from a CD disc if the servo motors in MD don’t work. This step is for checking the TRAY OPEN/CLOSE MOTOR among them.
Page 46
ONE POINT REPAIR GUIDE NO OPERATION OF MD When no sound output in the CD function, you can not listen to music reading data from a CD disc if the pickup module in MD doesn’t work. This step is for checking the LASER TRACKING ACTUATOR.
Page 47
ONE POINT REPAIR GUIDE NO OPERATION OF MD When no sound output in the CD function, you can not listen to music reading data from a CD disc if the pickup module in MD doesn’t work. This step is for checking the LASER FOCUSING ACTUATOR.
Page 48
ONE POINT REPAIR GUIDE 5. NO SOUND There is no sound output in the CD FUNCTION, repair the set according to the follow- ing guide. 5-1. IN THE CD FUNCTION 5-1-1. Solution Please check and replace IC501, IC602, IC801 on MAIN board. 5-1-2.
ONE POINT REPAIR GUIDE NO SOUND There is no sound output by DIGITAL AUDIO AMP DAMAGE, repair the set according to the following guide. 5-2. BY DIGITAL AUDIO AMP DAMAGE (IN ALL FUNCTIONS) 5-2-1. Solution Please check and replace IC701, IC702, IC703 on MAIN board. 5-2-2.
Page 50
ONE POINT REPAIR GUIDE NO SOUND There is no sound output in the USB FUNCTION, repair the set according to the fol- lowing guide. 5-3. IN THE USB FUNCTION 5-3-1. Solution Please check and replace IC501, IC504 on MAIN board & IC3U01 on USB board. 5-3-2.
Page 51
ONE POINT REPAIR GUIDE NO SOUND There is no sound output in the AUX FUNCTION, repair the set according to the fol- lowing guide. 5-4. IN THE AUX FUNCTION 5-4-1. Solution Please check and replace IC202 on MAIN board. 5-4-2. How to troubleshoot (Countermeasure) 1) Check AUX_L/R signals to IC202 (Pin7, 8).
Page 52
ONE POINT REPAIR GUIDE NO SOUND There is no sound output in the IPOD FUNCTION, repair the set according to the fol- lowing guide. 5-5. IN THE IPOD FUNCTION 5-5-1. Solution Please check and replace IC201, IC202, IC203 on MAIN board. 5-5-2.
Page 53
ONE POINT REPAIR GUIDE NO SOUND There is no sound output in the PORT. IN FUNCTION, repair the set according to the following guide. 5-6. IN THE PORT. IN FUNCTION 5-6-1. Solution Please check and replace IC202 on MAIN board. 5-6-2.
Page 54
ONE POINT REPAIR GUIDE NO SOUND There is no sound output in the TUNER FUNCTION, repair the set according to the following guide. 5-7. IN THE TUNER FUNCTION 5-7-1. Solution Please check and replace IC202, TU101 on MAIN board. 5-7-2. How to troubleshoot (Countermeasure) 1) Check if TUNER_LR is entered from Pin1 &...
Page 55
ONE POINT REPAIR GUIDE NO SOUND There is no sound output in the MIC IN FUNCTION, repair the set according to the following guide. 5-8. IN THE MIC IN FUNCTION 5-8-1. Solution Please check and replace IC603, IC605 on MAIN board. 5-8-2.
ELECTRICAL TROUBLESHOOTING GUIDE 2. SYSTEM PART Power on. CN301 “HELO” cable connection Display on FLD Check FFC cable (Pin29). CN301 Pin27, 28, 29 power Check SMPS board. CN301 Pin20, 21, 22 data signal Check MAIN board. Q301, 303, 304 Replace DIG301. grid voltage OK? Volume LED CN301 Pin18...
ELECTRICAL TROUBLESHOOTING GUIDE 3. NO AUDIO PART CD FUNCTION Is motor_open/ close OK? LOAD +- ok ? disc insert? (IC408 Pin9,10) Check IC301. Is motor impedance Check Loading motor. about 12 Ω? Check IC408. Focusing/ OPU driving Tracking/ Sled Signal Disc reading OK? (Focusing &...
Page 62
ELECTRICAL TROUBLESHOOTING GUIDE USB play IC501 Pin116,117 USB_D output Check IC501. signal OK? IC3U01 When insert USB power +5 V Replace IC3U01. USB,IC502 Pin1,2,3,4 USB_D signal OK? IC202 Pin7,8 AUX input signal Check audio cable. IC202 Check IC501. Pin42,43,44 I2S input signal IC202 Replace IC202.
Page 63
ELECTRICAL TROUBLESHOOTING GUIDE POT. IN IC202 Pin21,22 POT. IN input signal Check USB board. IC202 Check IC501. Pin42,43,44 I2S input signal IC202 Replace IC202. Pin41 ADC data output signal iPod IC203 IC202 Pin4 USB_VBUS 5 V Pin25,26 iPod input signal Check USB_VBUS of IC203.
Page 64
ELECTRICAL TROUBLESHOOTING GUIDE TUNER TU101 IC202 TUNER_L/R output Pin21,22 TUNER_L/R input Check +3.3 V of TU101. signal OK? signal OK? IC202 Pin42,43,44 I2S input Check IC501. signal OK? IC202 Pin41 ADC data output Replace IC202. signal OK? 3-37...
Page 65
ELECTRICAL TROUBLESHOOTING GUIDE IC501 Replace IC501. Pin83,87,88 I2S data output signal OK? IC507 Check IC507. Pin2,17 DAC_BCK/LRCK input signal OK? IC507 Replace IC507. Pin7,14 BEAT_LRCK/BCK output signal OK? IC501 Check IC501. Pin83 BEAT_DAC_DATA output signal OK? IC501 Check IC501. Pin83 BEAT_DAC_DATA output signal OK? IC801 Check IC501.
ELECTRICAL TROUBLESHOOTING GUIDE 4. DIGITAL AUDIO AMP CHECK IC602 I2S input signal Check IC801 & IC501. IC602 PWM data output signal Replace IC602. IC701 IC702 IC703 FL±/FR± input signal SW1±/SW2± input signal RL±/RR± input signal Check IC602. Check IC602. +12 VA, +48 V Check SMPS.
WAVEFORMS 1. WAVEFORM OF SP- & SP+ FOR 2. WAVEFORM OF SL- / SL+ FOR DRIVING SPINDLE MOTOR DRIVING SLED MOTOR 3. WAVEFORM OF TUR_M+ & TUR_M- 4. WAVEFORM OF LO- & LO+ FOR DRIV- FOR DRIVING TRAY MOTOR ING PICKUP MODULE UP/DOWN MOTOR 3-40...
Page 68
5. WAVEFORM OF RF SERVO 6. WAVEFORM OF I2S SIGNAL TO BEAT BOX IC (IC801) 7. WAVEFORM OF BEAT BOX IC'S 8. WAVEFORM OF VFD GRID CUR- POWER SEQUENCE RENT DRIVER 3-41...
2. SMPS BLOCK DIAGRAM MAIN STR-A6252 for Main Power TRANS Rectifier Circuit (Bridge, CAPACITOR) Filter Section (Varistor, Resistor, Line Filter Snubber Thermistor) Digital TRANS AMP Power & Power MAIN UC3844 for Main Power & 3-47 3-48...
MODIFIED OR ALTERED WITHOUT PERMISSION IMPLEMENTATION OF THE LATEST SAFETY AND during Play mode. FROM THE LG CORPORATION. ALL COMPONENTS PERFORMANCE IMPROVEMENT CHANGES INTO SHOULD BE REPLACED ONLY WITH TYPES IDENTICAL THE SET IS NOT DELAYED UNTIL THE NEW SERVICE TO THOSE IN THE ORIGINAL CIRCUIT.
CIRCUIT VOLTAGE CHART 1. HOW TO CHECK THE VOLTAGE Turn the SMPS board over with cable connected Location / Supply Voltage Source Spec / Rating Measured voltage and check the voltage. Description Pin No. PVDD_X 25~52.5V 47.7V IC701 GVDD_X 10.8~13.2V 11.91V TAS5631 10.8~13.2V...
Page 88
3. CAPACITORS ON MAIN BOARD 4. CAPACITORS ON SMPS BOARD Location Value Capacitor (uF) Voltage Spec. Measured voltage 100V-10% 240V/50Hz+10% Value Capacitor Location Voltage Spec. (uF) C111 47uF 3.37V Measured voltage Measured voltage C145 2.2uF 3.37V C903 1000uF 315V 122.3V 190V C124 1000uF...
