Page 1: Table Of Contents
FUZZY LOGIC CONTROL FULLY AUTOMATIC WASHING MACHINE Model: WMT7010 CONTENTS 1. SAFETY WARNING 2. PARTS IDENTIFICATION 3. ACCESSORIES 4. CONTROL PANEL 5. SPECIFICATIONS 6. INSTALLATION 7. DETERGENT CONTAINER 8. PROGRAMS 9. OPERATION 10. MAINTENANCE 11. TROUBLE SHOOTING 12. ELECTRICAL G DIAGRAM...
Page 2: Safety Warning
SAFETY WARNING Never use the plug as Do not only hold the cord Do not let children to play shown. while pulling out the plug. with the machine. Do not put hands into the Do not clean the body of K e e p t h e w a s h i n g rotating tub.
Page 3: Parts Identification
PARTS IDENTIFICATION Detergent box Inlet hose (Please turn off the Softener dispenser tab after using) Magic lint filter Inner tub Control panel Lint filter Pulsator Power cord Noise and mice-proof plate Drain hose (It is inserted into the base to reduce noise and keep the mice away.) Base...
Page 4: Control Panel
CONTROL PANEL FUZZY WOOL COTTON ECONOMY SOAK SOAK 9MIN 9MIN POWER POWER MINI 5MIN 5MIN STRONG WARM 12MIN 12MIN COLD GENTLE 9 MIN 9 MIN 3MIN 3MIN ANTI-CREASES INNER TUB 6 MIN 6 MIN 1MIN 1MIN SPEEDY START CLEAN PAUSE WATER WATER SUPPLY...
Page 5: Installation
INSTALLATION Insert the noise-proof plate into the washing machine base 1. Take out the noise-proof 2. The entrance is in the front plate. of the base. 4. Lay down the washing 3. Insert the noise-proof plate machine, fasten the two into the base.
Page 6: Water Supply Requirements
INSTALLATION Connection of the drain hose Change the direction of the drain hose Unfasten the fixed screw of Lead out the drain hose from Fasten up the screw to fix the drain hose joint. the opening to the other side. the drain hose.
Page 7 INSTALLATION Faucet: Connection of the inlet hose The faucet must be with G3/4" standard screw thread. If not , it is impossible to connect the inlet hose properly. NOTE: water supply faucets should be readily accessible to permit turning them off when washer is not being used. Installation and connection of the Inlet hose Note: The washing machine is to be connected to the water mains using new...
Page 8: Detergent Container
INSTALLATION Connection of the power cord Note: The socket should have assembled the 5A fuse. Use the socket which can be connected ground wire. Warning: The ground wire of the washing machine is set in the plug, don't try to modify it. The socket should have reliable ground wire.
Page 9: Programs
DETERGENT CONTAINER Softener for laundry Note: Softener dosage Water Inject softener into the softener dispenser before level Normal Concentrated washing, At the last time for rinse, the softener will be infused into the rinsing automatically. Dilute concentrated softener with triplicate water.
Page 10: Operation
OPERATION Preparation nsert the end of the drain Connect the water inlet 3.Plug in the power supply hose into the hook shelf, and cord. hose to the water faucet. hang the drain hose over a Turn on the water faucet. drain outlet.
Page 11 OPERATION B: Edit program yourself. FUZZY WOOL COTTON ECONOMY SOAK SOAK 9MIN 9MIN POWER POWER MINI 5MIN 5MIN STRONG WARM 12MIN 12MIN GENTLE COLD 9 MIN 9 MIN 3MIN 3MIN ANTI-CREASES INNER TUB 6 MIN 6 MIN 1MIN 1MIN SPEEDY START CLEAN PAUSE...
Page 12: Operation Instructions
OPERATION INSTRUCTIONS C: Combine the program 1. Wash program only 1) Press the "PROGRAM" button to choose the desired function and then the corresponding indicator will blink. 2) Press the "WASH" button continuously to choose wash time. 3) Press the "RINSE" button until all the indicators of "RINSE" are off. 4) Press the "SPIN"...
Page 13 OPERATION INSTRUCTIONS Special functions FUZZY WOOL 1. Delay function COTTON ECONOMY MINI STRONG the program above-mentioned, After choosing press the "DELAY “ GENTLE ANTI-CREASES INNER TUB SPEEDY CLEAN button (before press the "START/PAUSE" button) continuously the digital indicator indicates the desired time to finish wash. (Example: If PROGRAM PROGRAM DELAY...
Page 14: Maintenance
MAINTENANCE Clean the filter in the water inlet valve Body maintenance Unplug the power supply cord first. Clean the surface of the washing machine 2.Take off the water inlet hose and clean the with a soft cloth regularly. filter with a brush. After spinning each time, please clean the inner tub to avoid deposit.
Page 15: Trouble Shooting
TROUBLE SHOOTING Indicators and roubles Checklist Unable to drain Is the highest point of the drain pipe 0.7m to 1.2m above floor level? If the draining time passes 10 Is the drain frozen or blocked? min, the washing machine will buzz and indicate "E1".
Page 16: Electrical G Diagram
ELECTRICAL DIAGRAM Microcomputer Programmer gr y safety water level switch switch sensor motor plug y/gr b-blue bl-black br-brown g-gray gr-green r-red w-white y-yellow p-purple C-capacitor L-inductance IV-inlet valve Ms-drain water motor assembly CAUTION: If this appliance is supplied with a cord extension set or and electrical portable outlet device, the cord extension set or electrical portable device must be positioned so that it is not subject to splashing or ingress or moisture.
