USER'S MANUAL
BF - 041S/BF - 041W
First of all, we would like to thank you very much for
purchasing a PLUS Copyboard MODEL BF-041.
Please read this User's Manual before using the
copyboard to get the best performance out of the
product.
We recommend that you keep this manual for future
reference.
PRODUCT FEATURES .................................... E-4
CONTROL FUNCTIONS ................................... E-5
HOW TO USE ................................................... E-7
PLUS COPYBOARD SOFTWARE ................. E-12
MAINTENANCE/HOW TO STORE ................. E-16
HANDLING PRECAUTIONS ........................... E-16
TROUBLE SHOOTING ................................... E-18
SPECIFICATIONS .......................................... E-19
CONTENTS
E-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BF-041S and is the answer not in the manual?

Questions and answers

Summary of Contents for Mono Machines BF-041S

  • Page 1: Table Of Contents

    http://www.monomachines.com/ For More Info Click Here ---> USER’S MANUAL BF - 041S/BF - 041W First of all, we would like to thank you very much for purchasing a PLUS Copyboard MODEL BF-041. Please read this User’s Manual before using the copyboard to get the best performance out of the product.

  • Page 2: Package Contents

    For More Info Click Here ---> PACKAGE CONTENTS Please be sure all of the following items are included in the carton of the BF-041S and BF-041W COPYBOARD • Copyboard main unit ........[1] ACCESSORIES • Set of Dry-eraseble markers (one each black, red and blue) ............

  • Page 3: Features

    FEATURES • The board size is BF-041S: W1300 mm × H920 mm (51.2 × 36.2 inches), BF-041W: W1800 mm × H920 mm (70.9 × 36.2 inches)-large enough to show all the ideas that you discuss during your meetings, without any omissions.

  • Page 4: Product Features

    http://www.monomachines.com/ PRODUCT FEATURES FRONT Sheet 50mm × 50mm (2 × 2 inches) gridded effective reading area Dust tray Printer Operation panel T-shaped stand (*optional) Printer cover Stabilizer Note: Please fix supplied sta­ Caster bilizers at each end of the dedicated stand when you mount the BF­...

  • Page 5: Control Functions

    CONTROL FUNCTIONS OPERATION PANEL (BF-041S) OPEN A Opening button ........ Press this button to open the printer cover when replac­ ing the thermal paper. B Power switch ........Press “ I ” to turn ON the power of the copyboard.
  • Page 6 http://www.monomachines.com/ CONTROL FUNCTIONS OPERATION PANEL (BF-041W) OPEN A Opening button ........ Press this button to open the printer cover when replac­ ing the thermal paper. B Power switch ........Press “ I ” to turn ON the power of the copyboard. C Power lamp ........

  • Page 7: How To Use

    A4/ Letter paper. When copying reduced two-page in one copy (BF-041S only): Press two-in-one page copy key. At this time the sheet scrolls by two pages, and the written contents are reduced to A4/Letter size and copied.
  • Page 8 http://www.monomachines.com/ For More Info HOW TO USE Click Here ---> WHEN SCROLLING THE SHEET FORWARD... Scrolling by using key Press the feed/stop key. Then, the sheet scrolls to the left by one page and stops. It stops immediately when the feed/stop key is pressed during the scrolling operation.
  • Page 9 http://www.monomachines.com/ For More Info HOW TO USE Click Here ---> Replace the print paper in the following situations • When a red line appears at the edges of the print paper. The red line will appear when there is only about one meter (3 feet) or so of print paper left on the roll. • When the paper warning lamp lights red.
  • Page 10 http://www.monomachines.com/ For More Info HOW TO USE Click Here ---> How to customize the operating configuration (BF-041 Setup Utility Software) The following operating configurations of the BF-041 can be changed using the BF-041 Setup Utility Software. • Auto Power Off Time If no button is pressed after the power is turned on, the lamp automatically turns off after 120 minutes and the copyboard goes into standby mode.
  • Page 11 2. Start Quick Calibration 1) Turn off the power. 2) Turn on the power while pressing One-page copy key(BF-041S) or A4 size copy key(BF­ 041W) 3) It goes into warm-up mode. Both Power lamp and Paper warning lamp blink simultaneously, and the fluorescent lamp lights.

  • Page 12: Plus Copyboard Software

    http://www.monomachines.com/ PLUS COPYBOARD SOFTWARE Before Using the Software Software Contents and Overview The supplied CD-ROM contains the software and manuals described below. See the Help infor­ mation of each program for information about how to use the software. • USB Driver This driver software makes the computer recognize the BF­...
  • Page 13 http://www.monomachines.com/ PLUS COPYBOARD SOFTWARE Connection to a computer Turn the copyboard’s power on and connect the copyboard to the computer using the USB cable. Note: • Use a USB-IF certified shielded USB cable. • When connecting for the first time, the USB driver must be installed on the computer. • For Windows 98 or Windows Me, the operating system installation CD-ROM or floppy disc may be required.
  • Page 14 http://www.monomachines.com/ PLUS COPYBOARD SOFTWARE Saving the copyboard’s data on the computer The PLUS Image Viewer and TWAIN driver must be installed in order to save the data drawn on the copyboard onto the computer, display it and print it. Notice: When using a TWAIN compatible application, these operations are possible even if only the TWAIN driver is installed.
  • Page 15 http://www.monomachines.com/ PLUS COPYBOARD SOFTWARE Using the Setup Utility The copyboard’s operating environment can be changed using the Setup Utility. Settings: Auto power off time, Warm-up time, Brightness adjustment. Installation 1. Preparations for installation Quit any applications that are currently running on the computer. If not, installation may not be completed properly.

  • Page 16: Maintenance/How To Store

    http://www.monomachines.com/ MAINTENANCE/HOW TO STORE Carry out the following maintenance procedures periodically to ensure high quality copying performance at all times. 1.Cleaning of the sheet surface When the surface gets stained, wipe it off with a slightly damp cloth. Also, if the stain is particularly stubborn, use a solution of water-thinned neutral de­...
  • Page 17 http://www.monomachines.com/ HANDLING PRECAUTIONS 7. When replacing print paper, do not place any objects on the open printer cover or do not put your elbows on it. 8. After use, make sure to turn OFF the power switch. In addition, when it is not to be used for a long time, make certain that the plug of the power cable is pulled out from the outlet.

  • Page 18: Trouble Shooting

    http://www.monomachines.com/ TROUBLE SHOOTING Please check the following matters before making a request for servicing. Condition Please Check Pressing the POWER button does • Check that the power cable is securely plugged into the power outlet. not switch on the power. A press of the COPY button does •...

  • Page 19: Specifications

    SPECIFICATIONS Item Specification (BF-041S) Specification (BF-041W) W1300 × H920 mm W1800 × H920 mm Board surface size (51.2 × 36.2 inches) (70.9 × 36.2 inches) W1240 × H880 mm W1740 × H880 mm Effective reading area (48.8 × 34.6 inches) (68.5 ×...
