HDsport Quick User Guide
HDsport
User Guide
All information and instructions included in this manual are current as of April 01, 2013.
However, due to the fluid nature of advancing technology, some characteristics may change or
need modifications in the future. Should you encounter any problems or have any further
questions about your purchase, please visit us at
www.ElectroFlip.com
and visit the contact us
page.
HDsport Mini HD Digital Video Recorder
Please carefully read this user guide before attempting to install and operate this product.
Retain user guide for your future reference.
1
Advertisement
Table of Contents
Related Manuals for ElectroFlip HDSport
Summary of Contents for ElectroFlip HDSport
-
Page 1: User Guide
HDsport Mini HD Digital Video Recorder Please carefully read this user guide before attempting to install and operate this product. Retain user guide for your future reference. -
Page 2: Table Of Contents
HDsport Quick User Guide Index Preface............................... 3 Approval Information ................Error! Bookmark not defined. About the User Guide ........................3 Warnings............................4 Main Features ........................... 5 Main Unit & Buttons .......................... 5 Display & Icon ........................... 6 Power Charger ..........................7 Checking the Battery Status ...................... -
Page 3: Preface
Preface Thank you for purchasing the HDsport which with its unique, ultra-small high-performance design. It can be used in a variety of recording situations. The HDsport brings convenience, portability and High-Definition video recording to your adventures. About the User Guide We do our very best to ensure that our user guides are correct and up to date. -
Page 4: Warnings
HDsport Quick User Guide Warnings • Do not store the device in any place with following conditions: -High temperature (112°F or higher) -Exposure to direct sunlight or a heating device -Inside the car with the windows closed (especially in the summer) -Humid areas such as the bathroom or basement •... -
Page 5: Main Features
HDsport Quick User Guide Main Features • 1.5inch TFT LCD (480×240) • 5.0 MP high definition CMOS image sensor • Water and weather resistant – Light rain & snow • Easy operation for recording and taking a picture • Optional recording resolution (Full HD/HD/WVGA/VGA) •... -
Page 6: Display & Icon
HDsport Quick User Guide 8) Power ON/OFF, /Picture Capture/Quit/Confirm 9) Record/Play/Select Display Instructions Display & Icon HDsport... -
Page 7: Power Charger
HDsport Quick User Guide Power Charger Checking the Battery Status Please close the battery door after installing the battery. Charging by Connecting to PC 1) User can charge the HDsport by connecting the USB cable to your computer. -
Page 8: Charging With Ac Adaptor
HDsport Quick User Guide Connecting the HDsport to your PC with the “Power Off” will charge the battery. With the HDsport’s “Power On”, the HDsport will automatically start transferring data. Power Charger Charging with AC Adaptor... -
Page 9: Charging With Cigarette-Lighter
Charging With Cigarette-Lighter Battery Charging Time & Operating Time While plugging or unplugging the AC adaptor to the HDsport, turning off the unit is strongly recommended. The manufacturer strongly recommends using the supplied AC adaptor, but if it is necessary that another AC adaptor be used, please make sure the electric specifications are in accordance with the HDsport’s specifications. -
Page 10: Storage Card
HDsport Quick User Guide • Do not overcharge the battery or leave on the charger more than 3.5 hours with the power off. Overcharging the battery can diminish the battery’s operating life. • Recharge the battery before use if it has been stored for a while. The battery will discharge during storage. - Page 11 HDsport Quick User Guide A. The HDsport has a built in 32MB ROM memory for system files only. B. The HDsport has a built in standard SD card reader, supports up to 32 GB memory cards. SD cards including SDHC are compatible, but not all brands are compatible. Make sure the SD card is compatible with the HDsport before recording.
- Page 12 HDsport Quick User Guide...
- Page 13 HDsport Quick User Guide...
-
Page 14: Basic Operation
HDsport Quick User Guide Basic Operation Record Settings Press and hold to turn power on, then press to enter the setting menu. to select menu, press to change the setting and press save and quit. System Setting Press to enter the record setting menu, and then to enter the “system... -
Page 15: Take Picture And Record Video
HDsport Quick User Guide Basic Operation III. Take picture and Record video Pressing in viewing mode will take a picture. The red recording indicator light will flash once. Pressing in viewing mode will start recording. The red indicator light will keep blinking. -
Page 16: Video Playback
HDsport Quick User Guide Basic Operation Video playback a. Playback Mode Press and hold to enter playback mode. While in playback mode use the to select video files. Video file display: Picture file display: Slideshow Browse: Browse the files in slideshow playback mode. Press in playback mode, use to select “SLIDE SHOW”... -
Page 17: Tv Playback (Hdmi)
HDsport Quick User Guide Basic Operation b. TV Playback (HDMI) Connect the camera to your TV with the HDMI cable, turn the HDsport on and switch the TV to the HDMI video input channel. Press and hold to enter playback mode. Use to select the files. -
Page 18: Delete Files
The output resolution is 1080i in playback mode and 480i in recording mode. Some TVs won’t be able to display correctly because the TV does not support 1080i HD signal, the HDsport will recognize the TV system when connected. Basic Operation C. -
Page 19: Connect With Computer
HDsport Quick User Guide Press to confirm “delete” operation. Basic Operation D. Connect with Computer Connect the HDsport to your PC using the provided USB cable for downloading or uploading files and upgrading firmware. - Page 20 (2) Turn the HDsport on. (3) The screen of the HDsport will display “USB connected”. Note: You cannot do any operations on the HDsport once it is connected to the computer. Basic Operation (4) Open “My Computer” to check if there is a removable hard disk, called “No Name”...
- Page 21 HDsport Quick User Guide (5) Open the video files in the folders. (6) Check the video files in the folders, and play it using the default media player in your computer.
- Page 22 HDsport Quick User Guide...
- Page 23 Should you encounter any problems or have any further questions about your purchase, please visit us at www.ElectroFlip.com and visit the contact us page. This document is property of ElectroFlip LLC. No unauthorized reproductions allowed.
