Gesytec Easylon Router+ Quick Start Manual

The Router

IP A S
DDRESS ETUP
Establishing connection
+
The Easylon Router comes with the IP address 192.168.100.100 and sub-
net mask 255.255.255.0. At first establish a direct connection to your PC,
using an Ethernet cable.
If the PC is not in the same subnet as the Easylon Router
following procedure – provided the device is in its delivery status (or after
a factory reset):
Open the command prompt.
With Windows Vista or Windows 7 please select the command prompt by
right-clicking the start menu and selecting "run as administrator".
Windows XP: please type
route add 192.168.100.100 mask 255.255.255.0 %COMPUTERNAME%
Windows Vista and Windows 7: at first please determine the IP address
of your PC, using the "ipconfig" command. Knowing this address enter
route add 192.168.100.100 mask 255.255.255.255 xxx.xxx.xxx
with xxx.xxx.xxx.xxx being the IP address of your PC.
Setting the IP Address
Open a browser and connect to the device by typing 192.168.100.100 as
URL. The user interface will be displayed. Select the SETTINGS tab and
Local Area Network from CATEGORIES to the left. In order to access the
SETTINGS user name "gesytec" and password "admin" are required.
Now enter the TCP/IP parameters. It is not recommended to use DHCP but
static IP addresses. Having entered the parameters click the Save button.
The device will immediately change to the new IP address settings. There-
fore you must reconnect using the new IP address parameters.
Gesytec GmbH, Pascalstr. 6, 52076 Aachen, Germany, www.gesytec.de
Easylon Router
S
ETTING UP THE
Connect to the Easylon Router
of the device as URL. Select the SETTINGS tab and CEA-852 from the
CATEGORIES (login required, see above).
+
you can use the
Enter a Device Name for the Router (default: Basic Node ID) and the IP
address of the machine, running the Configuration Server.
The Device Name must be unique in the 852 channel!
Then click the Save button. The Easylon Router
to connect to the Configuration Server.
S
ETTING UP THE
Start the LonWorks IP Configuration Server. Add a new LON IP device
by right clicking on New Channel in the device tree and select New Device.
Enter a name for your Easylon Router
entry you can enter the IP address of the Easylon Router
steps for each Easylon Router
using the Enable command from the Network menu.
+
2 Port Quick Start Guide
LON/IP P
ARAMETERS
+
through a browser by using the IP address
+
will now periodically try
LON/IP C
HANNEL
+
. After a double click on the new
+
. Repeat these
+
in your network. At last enable the network
+
U E R
SE THE ASYLON OUTER IN A
Placing the Router Shapes
+
The Easylon Router with two ports is configured in the LonMaker as any
LonWorks Router. Just place a Router Shape between the LON IP and the
LON FT channel.
Status
ON Free
+
Easylon ® Router
LON
OFF Bus
LON / IP
LON IP Start / Reset
Service Factory Reset
Ethernet
Commissioning
The easiest way for commissioning is to press the Service Pin of the router
using the device's web interface. Connect to the Easylon Router
browser and select Service in the INFORMATION tab. Click the Service
Pin button to release a service pin message.
N
ETWORK
A B PE
LON
24 V DC
– +
+
with a
