Before using your air conditioner, please read
this manual carefully and keep it for future reference.
INVERTER SPLIT TYPE
ROOM AIR CONDITIONER
-
Please read this installation manual completely
before installing the product.
If the power cord is damaged, replacement work
shall be performed by authorised personnel only.
Installation work must be performed in accordance
with the national wiring Standards by authorised
personnel only.
Contact an authorised service technician for
repair, maintenance or installation of this unit.
SERIES
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Klimaire KSID Series
Summary of Contents for Klimaire KSID Series
- Page 1 Before using your air conditioner, please read this manual carefully and keep it for future reference. INVERTER SPLIT TYPE ROOM AIR CONDITIONER SERIES Please read this installation manual completely before installing the product. If the power cord is damaged, replacement work shall be performed by authorised personnel only.
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS Warning .............................2 Caution ............................2 INSTALLATION INSTRUCTIONS Selecting installation place......................3 Accessories ..........................4 Indoor unit installation........................8 Outdoor unit installation......................9 REFRIGERANT PIPE CONNECTION Refrigerant pipe connection ......................10 ELECTRICAL WORK Electrical work .........................12 TEST RUNNING Test running ...........................14 CAUTION Contact an authorised service technician for repair or maintenance of this unit. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Read the follow SAFETY PRECAUTIONS carefully before installation. Installation must be performed in accordance with the requirement of NEC and CEC by authorized personnel only. Incorrect installation due to ignoring of the instruction will cause harm or damage, and the seri ousness is classified by the following indications. -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS Selecting installation place Read completely, then follow step by step. Indoor unit More than 12cm/4.72in Do not expose the indoor unit to heat or steam. Select a place where there are no obstacles in front or around the unit. Make sure that condensation drainage can be conveniently routed away. -
Page 5: Accessories
INSTALLATION INSTRUCTIONS Accessories ’ Name of Accessories Number Q ty Installation Plate Clip Anchor 5-8(depending on models) Self-tapping Screw A ST3.9X25 5-8(depending on models) Seal (For cooling & heating models only) Drain Joint (For cooling & heating models only) Remote controller Self-tapping Screw B ST2.9X10 Optional Remote controller holder... - Page 6 INSTALLATION INSTRUCTIONS Correct orientation Indoor unit installation of Installation Plate 1. Fit the Installation Plate 1. F i t t h e i n s t a l l a ti on p la te horizontal ly o n s t r u c t u r a l p ar ts o f the wall with s p a c e s a r o u n d t he i ns t allation plate.
- Page 7 INSTALLATION INSTRUCTIONS Wall 2. Drill a hole in the wall Outdoor Indoor 1. Determine hole positions according to the diagram detailed in Fig.5. Drill one (1) hole (φ90mm/3.54in) slanting slightly to outdoor side. 2. Always use wall hole conduit when drilling metal grid, metal plate or the like.
- Page 8 INSTALLATION INSTRUCTIONS Do not smoke during the installation work. The equipment must never be operated without the refrigerant lines connected, otherwise the equipment will be damaged immediately. The screw connections may only be tightened using the appropriate open-ended spanner. Remember that if they are tightened with too little torque they will leak but if they are tightened with too much torque, the screw connections may suffer damage.
-
Page 9: Indoor Unit Installation
INSTALLATION INSTRUCTIONS Note: Route the package of pipes/hoses in the direction of (rear)right or (rear)left. See Fig.13 . 1.Both sides drainage structure is standard. For both sides drainage structure, it can be choosen for right, left or both sides drainage connection. If choosing both sides drainage connection, another proper drain hose is needed as there is only one drain hose offered by factory. -
Page 10: Outdoor Unit Installation
INSTALLATION INSTRUCTIONS Outdoor unit installation Outdoor unit 1. Outdoor installation precaution Refrigerant pipe Select the location for installation(follow the previous Indoor unit notes on selecting the installation place). If the outdoor unit is higher thanthe indoor unit, make sure that a curve is made in the refrigerant pipe which is lower than the bottom edge of the indoor unit. -
Page 11: Refrigerant Pipe Connection
REFRIGERANT PIPE CONNECTION 4. Connecting the refrigerant pipe to outdoor unit CAUTION: For your safety, always wear goggles and work gloves when connecting the pipes. NOTE: To distinguish the connectors to be connected to the indoor unit and outdoor unit, the connectors of the refrigerant pipe has been labelled “A”, “B”,“C”and “D”. - Page 12 REFRIGERANT PIPE CONNECTION Coup ling size (last 2 part numb ers) Poun d-for ce foot( 1bf-f t) Newt on mete r(N-m ) Kilog ram- force mete r(kgf -m) -06(9.5mm/3/8 dash size) 18 - 20 24.4 - 27.1 2.4 - 2.7 40.6 - 47.4 -08(12.7mm/1/2 dash size) 30 - 35...
-
Page 13: Electrical Work
ELECTRICAL WORK CAUTION CAUTION CAUTION CAUTION After the confirmation of the above conditions, prepare the wiring as follows: 1) Never fail to have an individual power circuit specifically for the air conditioner. As for the method of wiring, be guided by the circuit diagram posted on the inside of control cover. - Page 14 ELECTRICAL WORK Front Panel Connect the cable between indoor Electronic box cover unit and outdoor unit NOTE: Before performing any electrical work, turn off the main power to the system. 1. The connection cables of indoor and outdoor units have been connected to the terminals Fig.26 on the control board except the grounding Terminal block of indoor unit...
-
Page 15: Test Running
TEST RUNNING Test running Perform test operation after completing gas leak check at the flare nut connections and electrical safety check. Check that all tubing and wiring have been properly connected. Check that the gas and liquid side service valves are fully open. 1. - Page 16 The Klimaire logo is a registered Trademark of Klimaire Products inc. Copyright 2010 Klimaire Products Inc. 2190 NW 89 Place, Doral, FL 33172 - USA Tel: (305)593-8358 Fax (305) 675-2212 www.klimaire.com sales@klimaire.com The design and specifications are subject to change without prior notice for product...
