Salter PT-0050 STR Owner's Manual

Salter pt-0050 str indoor bike
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PT-0050 STR INDOOR BIKE
ENGLISH
OWNER'S MANUAL
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT-0050 STR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Salter PT-0050 STR

Summary of Contents for Salter PT-0050 STR

  • Page 1 PT-0050 STR INDOOR BIKE ENGLISH OWNER’S MANUAL...

  • Page 2: Safety Instructions

    This is especially important if you are over the age of 35, have never exercised before, are pregnant, or suffer from any illness. OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...

  • Page 3: Tools List

    Hex Head Bolt 10*60 (5) Flat washer 10*26*2 (7) Plastic washer 10*26*2 (6) Washer 8*19*1.5 (65) Screw 8*15 (64) Scerw Screw driver Screw Driver Screw driver M5 Allen wrench OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...

  • Page 4: Main Parts

    ENGLISH 3. MAIN PARTS Handle bar (45) Computer Seat Upright post (47) Seat post (50) Main frame (1) Hottle holder Front stabilizer (9) Pedal (26&28) OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...
  • Page 5 Attach the front stabilizer (9 ) and rear stabilizer (2) to the main frame (1) through the pvc plate (84) and fix with 4 hex head bolts (5), 4 washers (7), 4 plastic washers (6) and 4 nut caps (8). Use the screw driver. OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...
  • Page 6 B. Connect the extension wire (19) with the sensor wire (20) and loosen the adjustable knob (49); then attach the upper upright post (47) and the seat post (50) to the main frame (1). OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...
  • Page 7 Attach the consoler (48) to the handlebar (45) and connect the extension wire (19) to the cable of the console (48). Then, attach the bottle holder (96) to the main frame (1) with 2 bolts (55). OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...
  • Page 8 3. When Battery working voltage is low, the ‘Low battery’ indicator will show up on the Console display. Console Installation: 1. Insert the console in the support at the center of the handlebar. OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...

  • Page 9: Console Functions

    This is the approximation of heart rate detect from the chest belt during the work out. Average Heart Rate will be automatically shown after 3 seconds if the console cannot detect the current Heart Rate. OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...

  • Page 10: Function Modes

    Power Saving Mode Quick Start mode MODE SELECT Press the left hand key to select the SPEED, DIST, TIME or CLOCK at the bottom of the display. OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...

  • Page 11: Time Of Day

    2. To clear the exercise Time press the right hand key until the time is displayed then hold the right hand key for three seconds. Wait a few seconds until the console returns to the start-up screen. OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...
  • Page 12 3. BODYWEIGHT: Press the left hand key to set the bodyweight, press the right hand key to increase the weight. Press and hold the right hand key for rapid advance. Wait a few seconds until the console returns to the start-up screen. OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...

  • Page 13: How To Adjust The Resistance

    HOW TO ADJUST THE HANDLEBAR Use the knob located in the vertical post to adjust the position of the handlebar. OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...

  • Page 14: Maintenance

    1. Ensure that your chest strap is worn correctly and that there is moisture under the electrodes. 2. Relocate the bike away from any equipment that could potentially interrupt the radio frequency signal, such as a DVD player or television, etc. OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...

  • Page 15: Parts List

    18KG Φ450*28 BEARING 6001ZZ NBK BELT WHEEL SKIDPROOF PLATE Φ42.5*4 SPHC AXLE OF FLYWHEEL 14*185 SCM415 WASHER 12.2*16.6*1 M12*P1.5 ADJUST PLATE OF ZIP 19*4 FLANGE NUT 13*20*2 OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...

  • Page 16: Front Cover

    BRAKE BOLT 10*133 BRAKE NUT 16.8*16.8*31 UMBRELLA BOLT M5*5 DIN M10*P1.5 ROUND MAGNETIC 16.8*3 SPRING 2*16*30 BRAKE SCREW 10*101.5 SPRING 2 1.5*15*25 BRAKE NUT 2 16.8*16.8*25 OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...
  • Page 17 176*59*1.5 PVC BELOW POST CUSHION 12*92 WASHER Φ8*Φ18*1.0 SEAT DD680 WASHER Φ11*Φ21*1.5 U SLIDE BLOCK BRAKE KNOB SCREW 4*16 UMBRELLA BOLT 5*10 SCREW 4*16 BOTTLE CAGE OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...
  • Page 18 ENGLISH OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...

  • Page 19: Environmental Note

    STR INDOOR BIKE SALTER Design and quality Made in: CHINA Imported by Cial. SALTER, S.A. Lluis Millet, 52 08950 Esplugues de Llobregat Barcelona – Spain N.I.F.: A-08544298 OWNER’S MANUAL V.1 ENGLISH PT-0050 STR INDOOR BIKE This manual is available at www.salter.es...
