Warnings and Safety Instructions..................................................................................5
Safety precautions
⊡
Operation reminder
⊡
Introducing............................................................................................................6
System Requirements and Specifications........................................................................8
System Requirements
⊡
Specifications
⊡
Checking the items in the Package.............................................................................10
Standard Package Contents
⊡
⊡ Optional Accessories
⊡ Software
Name of each part.................................................................................................11
Front View
⊡
Rear View
⊡
Remote Controller
⊡
Installation..........................................................................................................13
Installment of Hard Drive
⊡
Separation of Hard Drive
⊡
Connect to the PC..................................................................................................15
Connect MODIX HD-3520 to the PC
⊡
Disconnect USB connection
⊡
Format the Hard Drive
⊡
Connection of TV/ HiFi.............................................................................................21
Connecting the Video cables to TV
⊡
Connecting the Audio cables to TV/Amplifier
⊡
- 3 -
Advertisement
Summary of Contents for DTS ModiX HD-3520
- Page 1 ⊡ Installation......................13 Installment of Hard Drive ⊡ Separation of Hard Drive ⊡ Connect to the PC....................15 Connect MODIX HD-3520 to the PC ⊡ Disconnect USB connection ⊡ Format the Hard Drive ⊡ Connection of TV/ HiFi.....................21 Connecting the Video cables to TV ⊡...
- Page 2 Connection to the Car TV..................23 How to Connect Video/Audio Cable to Car TV ⊡ Small remote controller for optional car package ⊡ Using of USB HOST Feature..................25 Setting a USB equipment ⊡ Installment of FM Wireless Transmitter................26 Getting Started....................27 Power on player ⊡...
- Page 3 This section describes precautions that should be observed in order to prevent injury to the user and damage to property, and to ensure safe use of the product. Be sure to observe the following items when using the product not to cause malfunction. ▣...
- Page 4 Once you have transferred your data to MODIX, you can connect it to any TV to enjoy your movies, music and photos. Also you can watch your favorite films in HDTV quality Video and Dolby Digital or DTS quality Audio. MODIX has a pocket design that lets you take it wherever you go.
- Page 5 We wish you many years of enjoyment from MODIX MediaPlayer. Don't forget to check our web site: www.modix.co.kr, as we periodically update the internal operating software (Firmware) to offer new functions and improved features. Wishing you the best Video, Music, and Photo experience. DTS INFOCOM CO., LTD. - 7 -...
-
Page 6: Environment Required
／ ／ S-VIDEO × 1 Analog Audio Output (L/R Stereo PCM) × 1 Audio Connections ※ Optical Digital Audio Output for DTS/Dolby digital output × 1 USB Spec USB 2.0(High Speed, Full Speed:Max.480Mbps) USB Interface Connector Type USB Mini-B Type × 1, USB HOST × 1 When used in USB1.1 mode, transfer speed is so slow... - Page 7 MPG, MPEG, AVI, DIVX, WMV9 OVER, VOB, MP4, M4P, M2T, M2P, M1V, Video M4V, TS, TRP, TP Note that some files may not be played properly. ※ Audio MP2, MP3, RPCM, WMA, AC3, MPA, WAV, AAC, DTS Photo JPEG, PNG Subtitle SMI, SMIL, SRT, TXT, SUB, IMG SUB Environmental Specifications Rating Power Voltage AC 100~240V±10% ;...
- Page 8 Select the check boxes to confirm that all items are included in the package. �� MODIX HD-3520 MediaPlayer (*No HDD Disc included） �� Stand �� Infrared Remote Control including AA batteries*2 �� Power adaptor with automatic voltage changeover 110/220V �� USB 2.0 High Speed Cable (A to mini B) ��...
- Page 9 . IR : Aim remote controler to this Remote control Sensor. ① . HDD : Blinks during hard disk activity. ② . PWR : Yellow when in stand-by mode and red when power on. ③ . EXT REMOTE: Connect optionally purchased Remote Extender Cable for easy car use ①...
- Page 10 * Bookmark, Capture, Password functions are only supported to FAT32 HDD Format. << Set the batteries >> . Open the battery cover. ① . set the batteries as shown right. ② Check if batteries are inserted correctly. . Install the battery cover again. ③...
- Page 11 No hard drive included in this model and prepares compatible 3.5"IDE hard drive more than �� 40GB capacity. * After installment of Hard Drive, please refer to next chapter of "Connection to PC" carefully. - 13 -...
- Page 12 . Uncover the top case releasing the four screws. ① ② Separate the hard drive pulling out attached tape carefully as shown below. Power off to prevent risks of electric shock. �� - 14 -...
- Page 13 �� Use only the AC Power Adapter supplied with the player. The AC operating voltage of this player is 110~240V,50~60Hz. ①. Connect the adapter to the DC jack on the player and into an AC outlet. ②. Connect USB cable to the USB jack on the player and PC's USB port. ③.
- Page 14 If you are a new hard drive user or when you turn on the player, the MODIX logo appears and do not turn to Video /Audio /Photo select mode, please make a new partition and format hard drive. Owing to limitation of NTFS hard partition, we recommend you to format as FAT32. ��...
- Page 15 ②. Select 'Y' to enable the large disk support and press 'ENTER'. ③. Enter '5' to change the current disk drive and press 'ENTER'. ④. Select the drive you want to install and format, in this example disk '2' but note that this may vary from your setup! ��...
- Page 16 . Choose '1' to create a primary DOS partition and follow the on screen instructions. After you have ⑤ created the partition according to your requirement, close the MS-DOS command prompt by typing 'exit' and press 'ENTER'. ⑥ Restart your Computer and then go to 'My Computer'. The new drive should appear and you will be prompted to format it after double clicking on the drive icon.
- Page 17 << Windows 2000/ Windows XP >> The tool used here is the so called 'Disk Management' application. You can find this by right clicking on 'My Computer', then choosing 'Manage' and 'Disk Management'. The alternative is to go to 'Start/ Control Panel/ Administrative Tools/ Computer Management'.
- Page 18 . Choose the drive you want to install and right click on it for further commands. Click on ③ the gray field on the left side to initialize the drive or click on the empty field on the right side to create a partition.
- Page 19 Connect only one capable video cable directly to your TV system and set your TV as AV INPUT MODE. Its connection depends on the outlets available on your TV set. Plug the Power Supply adaptor to the MODIX and then into the electrical outlet. ⋄...
- Page 20 The digital 5.1 channel connection provides the best sound quality. It requires a A/V receiver that supports AC3 and DTS audio formats. Connect the Player's digital audio outlets(optical) to the corresponding input on the amplifier.
- Page 21 Take MODIX player and enjoy with you in the car! With our optional car kit, you can get rid of the dozens of CDs laying around your car by using your MODIX portable player on the road. (Option) ① Connect Video Cable into MODIX [VIDEO/ YPbPr] output and CAR TV [AV IN]. .
- Page 22 �� Don't drop the remote control and don't put it in wet place. Don't expose the front panel of infrared receiver to sunshine and strong light directly. �� When the remote becomes insensitive, please replace a new battery. �� - 24 -...
- Page 23 You can play videos, music and images stored in a USB equipment such as USB-compatible hard disk or memory card reader. The following describes how to play a file stored in the USB equipment. * Additional Power supply is required for proper play. .
- Page 24 Let you listen music and audio over any FM tuner and speaker setup without clumsy or constricting audio cable hookup. It's the perfect way to simply and efficiently listen to MP3s and other formats in the comfort of your car or living rook. *Supplied as optional purchasing of transmitter board. - 26 -...
- Page 25 . Connect AC power adaptor to player. ① . Plug in the AC power cord to the power outlet. ② . Turn on your TV & MODIX and select your TV's video input as AV mode. ③ . Appears the main menu on your TV when you turn on the Player. ④...
-
Page 26: Composite Out
Set when connected to composite video cable. If you can not see the correct image COMPOSITE on the TV screen, press N/ P button NTSC TV Out: repeatedly until the image appears. HD COMPONENT Set when connected to HD Component cable. C/S-Video, Set when connected to S-Video or COMPOSITE Out:... - Page 27 . Press ENTER or VIDEO to see list of file and folder the VIDEO menu screen then. ① . Video File and folder name will be displayed. ② . Select the desired file to play using direction key and press ENTER or to play.
-
Page 28: Load Audio
. Press ENTER or AUDIO to see list of file and folder the AUDIO menu screen. ① . Audio File and folder name will be displayed. ② . Select the desired file to play using direction key and press ENTER or to play. - Page 29 . Press ENTER or PHOTO to see list of file and folder the PHOTO menu screen. ① . Photo File and folder name will be displayed. ② . Select the desired file to play using direction key and press ENTER or to play.
- Page 30 MODIX provides you with the latest and best features through Firmware Upgrade. After you have completed the upgrade procedure, your player will typically perform better. . Firstly Confirm the installed firmware version right-below corner in the setup screen after ① pressing Setup button.
- Page 31 More questions and answers are available from our website. Just visit the support site at: www.MODIX.co.kr Why can't I see the drive in the file manager after I reboot my computer? Make sure the assembled HDD is installed correctly, and that the USB cable is connected to ��...
- Page 32 My picture is in black and white? �� Enter the setup menu and go to the video menu and change the settings here to fit your TV screen, this usually happens if the player is set to use s-video instead of Component. When I power on player, the MODIX logo appears and do not turn to Video Audio Photo select mode? Please download 『FAT32 Format Program from our web site and format hard drive before you 』...
- Page 33 C-409, Bundang Techno-Park, 145, Yatap-dong, Bundang-gu, Sungnam City, Kyounggi-do, KOREA ---------------------------------------------------------------------------------------------------------------------- Please note: If in need of technical assistance, do not send products to DTS INFOCOM and the address printed on this instruction manual. Please contact the location at point of purchase.
- Page 34 C-409, Bundang Techno-Park, 145, Yatap-dong, Bundang-gu, Sungnam City, Kyounggi-do, KOREA TEL : 031-702-1283 / FAX : 031-702-6178 http:/ / www.modix.co.kr...
