Summary of Contents for Ansonic HD Network Cameras
- Page 1 High-definition Network Cameras Address: 4F, Block 5, Wuzi Industrial Park, Fada Road, Bantian, Longgang District, Shenzhen, China E-Mail: info@cctv-ax. net Website: www. cctv-ax. com High-definition Network Cameras...
- Page 2 compress bigger and clearer image because of faster digital processor. Its smoother transfer and clearer display because of advanced OS and audio. Its reliable and stable running depend on embedded server, out of PC, high scheduling efficiency, curing code in the flash. Accessing it by IE browser. Two-way voice intercom, dynamic IP address and transfer image and audio conveniently are available.
-
Page 3: Table Of Contents
CONTENT 3 PTZ SETUP 3.1 PTZ BASIC 1 NETWORK SETUP 3.2 PTZ ADVANCED 1.1 NETWORK STATUS 4 RECORD AND REPLAY 1.2 ETHERNET SETUP 1.3 WIFI SETUP 4.1 STORAGE INFO 1.4 ADSL SETUP 4.2 PLAY BACK 1.5 DDNS SETUP 4.3 RECORD SETUP 1.6 UPNP SETUP 4.3.1 Basic Setup 1.7 FTP ACCOUNT... -
Page 4: Network Setup
6 SYSTEM SETUP 1 Network Setup 6.1 SERIAL NUMBER AND KERNEL VERSION 1.1 Network Status 6.2 ACCOUNT MANAGE 6.2.1 Add, Delete The connection schematic diagram for the entire system frame of Megapixel IP Camera as figure 1.1. Connect PC 6.2.2 User Group and Megapixel IP Camera directly and set network parameter as follow: 1. - Page 5 HD Network Camera User’s Manual Figure 1.5 networks is not through Fiure1.3 enter “ping 192.168.0.123-t” After then, power on. Enter the IP address in IE browser and press “enter”. Then it will display the following interface as figure1.6, and then enter user name (admin) and password (123456) and click “Login”. Figure1.4 network is through Figure 1.6 Login interface...
-
Page 6: Ethernet Setup
HD Network Camera User’s Manual HD Network Camera User’s Manual After enter system select and click “Network Setup”, it will display interface as figure 1.7, displaying the IP address, gateway, net mask and DNS and so on. The detail information please refers to the actual configuration. Figure 1.7 Network status 1.2 Ethernet Setup Ethernet setup as figure 1.8, all the parameter in the interface is needed to be reset. -
Page 7: Adsl Setup
HD Network Camera User’s Manual HD Network Camera User’s Manual 1.4 ADSL Setup ADSL setup as figure 1.10 The username and password of the ADSL are provided by network operators, enter the correct username and password, enable ADSL and save it. It can run correctly on premise that the username, password and the confirm password is correct. -
Page 8: Upnp Setup
HD Network Camera User’s Manual HD Network Camera User’s Manual 1.7 FTP Account FTP account setup as Figure1.13. First a FTP server is indeed. Then apply a FTP account from the FTP server (username and password). And you must create four directory as “alarm”, “log”, “set”, “update” or other directory name, also you can enter “./”... -
Page 9: Stream Setup
HD Network Camera User’s Manual HD Network Camera User’s Manual Figure1.15 Stream Setup 1.10 Platform Setup Platform Setup as figure1.16. Figure1.14 SMTP Account Setup 1.9 Stream Setup Stream Setup as figure 1.15. Access Protocol: while the device is in public network, TCP is a better choose, while the device and the user are the same network then UDP is a better choose. -
Page 10: Media Setup
HD Network Camera User’s Manual HD Network Camera User’s Manual The device can login platform server on the premise that the server IP and Server port is corresponding to the server. The server account and password can enter them wt will. Of course enable login server is indeed. 2 Media Setup 2.1 Play Video Figure2.1 Playing Video... -
Page 11: Video Capture
HD Network Camera User’s Manual HD Network Camera User’s Manual Detail as follow: Scan Begin: Turn lens and select “Scan Begin” in the “Orbit/Scan List” and click “Run”, then the direction is a “Scan Begin” Scan End: Turn lens again and select “Scan End” in the “Orbit/Scan List” and click “Run”, then the direction is a “Scan End”... -
Page 12: Time And Title Setup
HD Network Camera User’s Manual HD Network Camera User’s Manual 2.3 Time and Title Setup As we know, time and title are displayed in the video window. But you can hide them or set their transparency, position and so on. Transparency range from 0 to 100. -
Page 13: Video Encode
HD Network Camera User’s Manual HD Network Camera User’s Manual 2.4 Video Encode 2.5 Picture Capture In the interface, “Picture Source”, “Picture Quality” and “Capture Speed” need to be set. Of course, the default There is only one resolution with the main stream. But there are five resolutions with sub stream. All the encode format are H.264. -
Page 14: Audio Encode
HD Network Camera User’s Manual HD Network Camera User’s Manual 2.7 Audio Encode 3 PTZ Setup Enable “Enable Encode”. There are two type of encode, one is AAC another is G.711. G.711 with a fixed sample 3.1 PTZ Basic rate and bit rate, but AAC with three sample rate and bit rate such as 16K, 24K, 32K. There are 8 parameters about PTZ basic setup, for example “PTZ Protocol”, “Address Port”, “Baud rate”, “Data bits”, “Stop bits”, “Verify”, “Data Control”, “Boot action”, as following figure: Figure2.9 Audio Encode... -
Page 15: Record And Replay
HD Network Camera User’s Manual HD Network Camera User’s Manual 4 Record and Replay 4.1 Storage Info In this interface, just only show the statue of the storage, as figure 4.1 Figure4.1 Storage Information 4.2 Play Back First you can set the query conditions about querying record as figure 4.2. Be careful, “End Time” can not more 7 days than “Start Time”. - Page 16 HD Network Camera User’s Manual HD Network Camera User’s Manual Then click “Search”, the file will display in list as figure 4.3. The file name is the record time. Figure4.3 Record File List Figure4.4 Play record Last, you can play or delete or download the files. Click “Download” behind the selected record to play. As figure 4.4.
- Page 17 HD Network Camera User’s Manual HD Network Camera User’s Manual directory and change a name for the record, last click “Save”, well the record save succeeded. Figure4.5 Delete record succeeded First right click “Download” for download the selected record then it will prompt a dialog figure 4.6, select a Figure4.6 Dialog...
-
Page 18: Record Setup
HD Network Camera User’s Manual HD Network Camera User’s Manual 4.3 Record Setup 4.3.1 Basic Setup In this option, you need to set 4 parameters “Local Storage”, “Storage Media”, “Storage Strategy” and “Max Time Each File”. There are 7 methods about storage media. Storage strategy includes “Overwrite When Full” and “Stop When Full”. -
Page 19: Io Alarm Record
HD Network Camera User’s Manual HD Network Camera User’s Manual Figure4.10 Motion Detect Alarm Picture Capture Before enable “Motion Detect Alarm Capture”, you must ensure “Picture Capture Setup” enabled. Figure4.12 IO Alarm Record 4.3.5 IO Alarm Picture Capture The same method with “Motion Detect Alarm Capture”. Figure4.11 Picture Capture Setup 4.3.4 IO Alarm Record The setup method is the same with “Motion Detect Alarm Record”. -
Page 20: Schedule Record
HD Network Camera User’s Manual HD Network Camera User’s Manual 4.3.6 Schedule Record Except “Video Stream” the other parameter is the same with “Motion Detect Alarm Record”, Video Stream include “Snapshot” which means it will take photo during the schedule record time, “Video Main Stream” and “Video Sub Stream”. -
Page 21: Format
HD Network Camera User’s Manual HD Network Camera User’s Manual Figure4.18 Unmount 4.4.2 Format Select the storage to be formatted and click “Format” button, then it will prompt two dialogs figure 4.19, click “OK” to format or click “Cancel” to cancel it. Figure4.19 Format 5 Alarm Setup Figure4.16 Unmount... - Page 22 HD Network Camera User’s Manual HD Network Camera User’s Manual Figure5.1 Motion Detect Alarm Figure5.2 Motion Detect Alarm Time Also you can set alarm time as following. The max number of time span is 24. And the time for schedule record and motion detect alarm record can not be the same.
-
Page 23: Io Input Alarm
HD Network Camera User’s Manual HD Network Camera User’s Manual speaker flash lamp. Alarm duration means during the time you set, it will go on alarm. Figure5 4 Alarm Output 5.2 IO Input Alarm IO input alarm is triggered by IO interface. Enable it in the interface and connect external device for inputting. Figure5.5 IO Input Alarm Figure5.3 Time Span Error Alarm output is another way for alarm. -
Page 24: Video Lost Alarm
HD Network Camera User’s Manual HD Network Camera User’s Manual flash lamp. Alarm duration means during the time you set, it will go on alarm. Figure5.7 Alarm Output Set 5.3 Video Lost Alarm Too many reasons can cause video lost, such as disconnect video cable. In this case, we can enable “Video Lost alarm” for reminding. -
Page 25: Storage Full Alarm
HD Network Camera User’s Manual HD Network Camera User’s Manual 5.4 Storage Full Alarm If the storage with Megapixel IP Camera then you can enable “Storage Full Alarm”, it will alarm when the usage of the storage close to 100%. In this page, alarm rate is usage of storage such as 95, it means it will alarm when the usage is 95%. -
Page 26: User Group
HD Network Camera User’s Manual HD Network Camera User’s Manual Select the user to be deleted, and click “Delete”, and it will pop-up a dialog, click “OK”, then the user was deleted There are three different types of user group, viewer, operator and administrator. As a viewer, you only can view figure 6.3, 6.4. -
Page 27: Time Setup
HD Network Camera User’s Manual HD Network Camera User’s Manual 6.3 Time Setup 6.4 Log Setup There are two type of update mode in this system. One is “Manual”, the other is “NTP Server”. In this page, you can set “output log type” according to actual needs. There are many types such as “Debug”, “Run”, “Error”, “Operation”, “Alarm”, “Statistic”... -
Page 28: Log View
HD Network Camera User’s Manual HD Network Camera User’s Manual 6.5 Log View This page, you can view the all logs that have been saved. First set “Log Date” that you want to view the logs and “Log Type”, click “Search”. Then it will list in the “System Log” table. Search condition figure 6.11: Figure6.12 Log View 6.6 Log File... -
Page 29: Config Manage
HD Network Camera User’s Manual HD Network Camera User’s Manual 6.8 Restore Config “Restore Config” means restore factory settings. All the parameters set by you will be last. There will be confirming figure 6.18, click “OK”. All the parameters restore to default configure and reboot automatically Figure6.15 Delete Succeeded 6.7 Config Manage When all parameters have been modified, you can download the configuration file and save it. - Page 30 HD Network Camera User’s Manual HD Network Camera User’s Manual Figure6.22 Update Succeeded Figure6.20 Select firmware Figure6.21 Confirm Update Figure6.23 Reboot...
-
Page 31: Reboot
HD Network Camera User’s Manual HD Network Camera User’s Manual 6.10 Reboot 7.2 Why the PTZ can not control? When you want to reboot the device, then you can click “Reboot”. It will save all parameters and configuration. Two reasons: NO.1 the PTZ protocol or address port or baud rate is incorrect, and then you need to modify the And it also will prompt a dialog to confirm.
