Aimco MSG-3BSN Operation Manual

AIR SUPPLY
AIR HOSE SIZE:
1/8" NPT air inlet
1/4" NPT air inlet
3/8" NPT air inlet
AIR PRESSURE: 90 PSI (6.5 kg/cm2) Air Pressure is recom-
mended for the most efficient performance. Too high of air
pressure will shorten the life of the tool.
LUBRICATION
FOR AIR MOTOR: Apply turbine oil before and after opera-
tion. (For example, MOBIL TURBINE OIL #32, SHELL TURBINE OIL #32, or
equivalent.)
FOR BEARINGS: Apply recommended high quality grease
properly (for example, SHELL ALVANIA NO.2, SHELL ALVANIAEP,
MOBILPLEX 2, MOBILPLEX 47 or equivalent) once every three
months or when the tool is overhauled. Over-greasing
will cause dull motion or overheating.
MAINTENANCE
DRY AND CLEAN AIR: Drain daily and install filter at or near
the take-off point to prevent trouble from foreign matter.
AIR HOSE AND JOINTS: Use air hose (the shorter, the better),
joints and other fittings of good condition and of proper
size to avoid pressure drop.
REGULAR OVERHAUL: At least once every three months
regular or periodical overhaul by a competent person is
needed for best performance and trouble free operation.
GENUINE PARTS: Use only AIMCO genuine spare parts for
replacement.
Any repair of AIMCO tools must be completed by
AIMCO or an authorized AIMCO Service Center.
Contact AIMCO at (503) 254-6600 for an authorized
Service Center in your area.
C OR P OR A TE HE A DQ U AR TE R S
10000 S.E. Pine St.
1204 E. Maple Rd.
Portland, OR 97216
Troy, MI 48083
(800) 852-1368
(800) 852-1368
FAX (800) 582-9015
FAX (800) 582-9015
www.aimco-global.com
Air Inlet Air Hose
use 1/4" ID air hose
use 3/8" ID air hose
use 1/2" ID air hose
Ave. Morones Prieto 2110 Pte.
Col. Loma Larga
Monterrey, NL CP 64710, Mexico
52-81 1001-1600
FAX 52-81 1001-1630
LIT-MAN790, Rev.01/07
Printed in USA
©2007 AIMCO

Die Grinders

Operations Manual
PO Box 16460, Portland OR 97292-0460
800-852-1368 • Fax 800-582-9015
www.aimco-global.com
