- Page 1 LCD display solutions User Manual 46” FHD LCD AP-W46 Aluminum front bezel NAP-W46 Front NEMA4 / IP65 OP-W46 Universal Mounting Open Frame Designed and manufactured by Austin Hughes UM-UV-W46-Q112V1 www.austin-hughes.com...
- Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents < Part. 1 > AP-W46 / NAP-W46 Package Content Structure Diagram & Dimension P.2 - 3 Mounting Hardware & Installation OP-W46 < Part. 2 > Package Content Structure Diagram & Dimension P.6 - 7 Mounting Hardware & Installation < Part. 3 >... - Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 5: Ap-W46 / Nap-W46
< Part 1 > < 1.1 > Package Content - AP / NAP-W46 46" FHD LCD Display AP-W46 / NAP-W46 46" FHD LCD display X 1 6ft VGA cable X 1 6ft DVI-D cable X 1 6ft HDMI cable X 1... - Page 6 < 1.2 > Structure Diagram - AP / NAP-W46 Front view AP-W46 NAP-W46 Bottom view Rear case Rear view LCD panel 6mm aluminum front bazel Audio speaker, pair LCD membrane Wall-mount bracket Remote sensor Power Audio Audio DVI-D S-Video R C A...
- Page 7 < 1.2 > Dimension - AP / NAP-W46 46” FHD LCD Display Side View AP-W46 NAP-W46 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-W46-Q112V1 www.austin-hughes.com...
- Page 8 < 1.3 > Wall-mount Installation - AP / NAP-W46 Front wall-mount bracket Step ■ Install left & right front wall-mount brackets at the rear side of the LCD shown above. ■ M5 screw x 8 pcs included ( Left & right side ). Rear side Step Rear wall-mount bracket...
- Page 9 < Part 2 > < 2.1 > Package Content - OP-W46 46” FHD LCD Display OP-W46 46" FHD LCD display X 1 6ft VGA cable X 1 6ft DVI-D cable X 1 6ft HDMI cable X 1 6ft RCA cable X 1 6ft S-Video cable X 1 Power cord X 1 Remote controller X 1...
-
Page 10: Front View
< 2.2 > Structure Diagram - OP-W46 Front view OP-W46 Bottom view Rear case LCD panel Rear view Universal open frame mounting Audio speaker, pair LCD membrane Extended remote sensor membrane cable ( 66cm from AD board to sensor end ) Power Audio Audio... -
Page 11: Part. 2 > Op-W46
< 2.3 > Dimension - OP-W46 46" FHD LCD Display Front View Side View OP-W46 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-W46-Q112V1 www.austin-hughes.com... - Page 12 < 2.3 > Installation - OP-W46 Universal mount No VESA mount provided for 46" and 55” models. Only universal mount available. UM-UV-W46-Q112V1 www.austin-hughes.com...
-
Page 13: Product Specifi Cations
< Part 3 > < 3.1 > Product Specifi cations 46” FHD LCD Display Mechanical AP / NAP-W46 OP-W46 Design Front Panel Black, RAL 9005 Rear Casing Dark grey, RAL 7037 Dark grey, RAL 7037 VESA Mounting 100 x 100mm 100 x 100mm Other Mounting Panel mount... - Page 14 < 3.1 > Product Specifi cations Safety Approval FCC & CE Regulatory Operating Temperature 0 to 50°C degree Environmental Conditions Humidity 20~90%, non-condensing Storage Temperature -5 to 60°C degree Humidity 5~90%, non-condensing Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random Physical AP / NAP-W46 OP-W46...
-
Page 15: On-Screen Display Operation ( Osd )
< 3.2 > On-screen Display Operation ( OSD ) 46” FHD LCD Display Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen... - Page 16 < 3.2 > On-screen Display Operation ( OSD ) Audio Audio mode : Movie / Voice / Normal / Music mode to choose Volume : Adjust the volume of sound Bass : Set the value of bass sound Treble : Set the value of treble sound Balance : Set the balance value of treble and bass sound...
-
Page 17: Remote Controller ( Rc-2 )
< 4.6 > How to Use the Remote Controller 46” FHD LCD Display INPUT MUTE -/-- AUTO FREEZE MENU SELECT ASPECT SLEEP ENTER BACK EXIT SWAP SOURCE POSITION AUDIO Select the source INPUT Switches on or off the TV Only use in TV mode. Select channels. For channel numbers 10 0 - 9 and above, enter the second digit within two seconds. -
Page 18: Part 4 > Options
< Part 4 > Options < 4.1 > Option Table Basic Options AP / NAP SDI *** Touchscreen MCS multi-screen control *** MIL-type / lockable connector The user can only select either SDI or MCS inputs. P.14 UM-UV-W46-Q112V1 www.austin-hughes.com... - Page 19 < 4.2 > Options : 3G / HD / SD-SDI input 46” FHD LCD Display Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with UltraView Full HD 1080p and ultra high resolution 1920 x 1200 LCD displays, Austin Hughes provides a SDI input module without using additional space or power and it comes standard with a 2-year warranty.
- Page 20 < 4.3 > Options : MCS 46” FHD LCD Display More control is always good. Especially when it is necessary and easy. Austin Hughes provides MCS solution to control the OSD of ( Multi-display Control ) various UltraView LCD display up to 64 units. The RS-232C is used for the communication between the PC and the fi...
- Page 21 < 4.3 > Options : MCS 46” FHD LCD Display P.17 UM-UV-W46-Q112V1 www.austin-hughes.com...
- Page 22 < 4.4 > Options : Touchscreen & driver W46" USB Touchscreen Specifi cation Multi-touch Model TMR2 Infrared Technology Dual Touch Point Finger or Gloved Hand Method No pressure required Activation Force 300 million touches Durability 25 ms Response Time 90% ±2% Optical Transmittance Surface Hardness Haze...
- Page 23 < 4.5 > Options : MIL-type or Lockable Connector 46” FHD LCD Display Input Part no. MIL Standard MS3470W8-33P MIL - DTL - 26482 MIL - type DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most design fl...
- Page 24 HDMI DVI-D Audio S-Video R C A Audio Power For RC-2 remote controller specifi cations, please refer to P.13 P.20...
