USER'S MANUAL
CAN bus LCD Display
TRI66.003 ver 2
10 April 2011
CAN bus LCD Display
User's Manual
10 April 2011
©2011 Tritium Pty Ltd
Brisbane, Australia
http://www.tritium.com.au
1 of 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAN bus and is the answer not in the manual?

Questions and answers

Summary of Contents for Tritium CAN bus

  • Page 1 USER'S MANUAL CAN bus LCD Display TRI66.003 ver 2 10 April 2011 CAN bus LCD Display User's Manual 10 April 2011 ©2011 Tritium Pty Ltd Brisbane, Australia http://www.tritium.com.au 1 of 7...
  • Page 2: Table Of Contents

    USER'S MANUAL CAN bus LCD Display TRI66.003 ver 2 10 April 2011 TABLE OF CONTENTS Introduction..................3 Device Overview.................3 Hardware...................3 Front panel......................3 Labels........................3 Power Input......................3 CAN Bus.....................4 CAN Network Topology..................4 CAN Wiring......................4 CAN Connector...................... 4 CAN Shielding......................5 CAN Termination....................
  • Page 3: Introduction

    Up to four different variables can be chosen to be displayed, one at a time. The display receives data and power via a CAN bus running at up to 1 Mbit/second, with the factory default at 500kbit/sec. Alteration of either the bit...
  • Page 4: Can Network Topology

    CAN BUS CAN NETWORK TOPOLOGY The CAN bus is structured as a linear network, with short stubs branching from 'T' connectors on the main bus backbone to each device. The CAN bus data lines must be terminated at each end of the main bus with 120 ohm resistors between the CAN-H and CAN-L signals.
  • Page 5: Can Shielding

    1 Mbit/second, and comes programmed from the factory with a CAN base address that will allow it to work without problems with other Tritium devices. Currently, modifying the data rate or CAN base address requires reprogramming the microcontroller, although hardware support is provided to allow updates over the CAN bus in the future.
  • Page 6: Mounting

    The LCD display is based around a Texas Instruments (TI) MSP430 16-bit embedded low-power microcontroller, operating from a clock derived from a multiplied 32.768kHz watch crystal as default. CAN bus support is provided via a Microchip MCP2515 CAN controller and TI SN65HVD234 CAN transceiver. The display is not isolated from the CAN network.
  • Page 7: Revision Record

    USER'S MANUAL CAN bus LCD Display TRI66.003 ver 2 10 April 2011 REVISION RECORD DATE CHANGE 14 May 2007 Document creation (JMK) 10 April 2011 Modified CAN bus connector description (JMK) 7 of 7...
