- Page 1 Smart Console™ Elite series Installation Guide Smart Console™ E72...
-
Page 2: Table Of Contents
Index Before you start opening boxes – Preparation Furniture specification Unpacking Initial Assembly Initial Connections Physical Configuration Guide Powering Up Plate 1: Module bays Plate 2: Rear of rack showing connection points Plate 3: Rear left of console showing connection points Plate 4: Rear of console showing Video conection points Plate 4:... -
Page 3: Before You Start Opening Boxes - Preparation
This document contains instructions for assembly, connection and configuration of your E72 Smart Console™. If you experience any problems or need any assistance please contact your local distributor first or you can contact SmartAV technical support in Australia via telephone on: +61 2 9648 6744 or via email on support@smartav.net... - Page 4 example of this type of construction method. In this case you may use the m6 screws provided. In this case you MUST ensure that at least 15mm of the thread of each m6 screw is entirely within the console when fully mounted. Alternatively the console may be attached to the furniture directly by passing screws or bolts through the furniture into the console's mounting holes.
-
Page 5: Unpacking
• One five-metre RCA cable • Manuals • Pre-installed Software (including backup disks of the Microsoft Windows XP install disk, SmartAV install disk, and a drivers disk) Initial Assembly Firstly position the control surface in your studio furniture. Once the console has been carefully lowered into the correctly sized space in your studio furniture, attach the console using the three m6 screws on either side of the console . -
Page 6: Initial Connections
Initial Connections Now that the control surface is securely positioned and the rack-mounted computer is bolted into location it is time to start connecting the various cables. Begin with the mains power for each unit. The IEC socket is located on the left-hand side of the back of the control surface if you are facing the back of the unit. -
Page 7: Physical Configuration Guide
Now run the VGA cable from the VGA port on the control surface (indicated by Pointer C on Plate 4) to the VGA input on the back of rack (indicated by Pointer D on Plate 2). Physical Configuration Guide It is now time to start populating the console with the modules. However, let us first look at the different types of modules and note the various legal positions they may occupy in the console. - Page 8 Every console must have a Monitor Panel and an Expert Panel fitted as a pair either in sections A and B or in sections C and D respectively as shown above. Every console must also have an Upper Active Panel and a Lower Active Panel also fitted as a pair in the remaining bays out of the A/B and C/D pairs.
-
Page 9: Powering Up
Powering Up The correct order for powering up the parts of your Smart Console™ for the first time is as follows: First, switch on the rack PC using the switch indicated by Pointer A in Plate 2. Then power on the console via the switch indicated in Plate 3 by Pointer B. On the right- hand end of the Arc™... -
Page 10: Plate 2: Rear Of Rack Showing Connection Points
Plate 2: Rear of rack showing connection points. E72 Smart Console™ Installation Guide March 2007... -
Page 11: Plate 3: Rear Left Of Console Showing Connection Points
Plate 3: Rear left of E72 console showing connection points. Plate 4: Rear of E72 console showing Scribble Strip™ Scanner connector (A), the RCA cable connector (B), the Ethernet cable connector (C), and the SVGA connector (D). E72 Smart Console™ Installation Guide Mar 2007... -
Page 12: Plate 4: E72 Mounting Points
M6 mounting screws Plate 5: E72 mounting points. Plate 6: An example of the suggested angle bracket mounting procedure. E72 Smart Console™ Installation Guide March 2007... -
Page 13: Plate 7: E72 Dimensions
Plate 7: E72 dimensions. E72 Smart Console™ Installation Guide Mar 2007... -
Page 14: Plate 8: Further E72 Dimensions
Plate 8: Further E72 dimensions. Note: Threaded mounting posts are 6.5mm in diameter and 32mm long. Please leave 120mm clearance at rear of console for bolster to open, for ventilation and for rear connecting cables. E72 Smart Console™ Installation Guide March 2007... -
Page 15: Plate 9: Inserting Modules
Plate 9: Inserting modules. Plate 10: Inserting modules 2 E72 Smart Console™ Installation Guide Mar 2007...
