FSC B17-2 SERVICE MANUAL FSC MONITOR B17-2 HESE DOCUMENTS ARE FOR REPAIR SERVICE INFORMATION ONLY.EVERY REASONABLE EFFORT HAS BEEN MADE TO ENSURE THE ACCURACY OF THIS MANUAL; WE CANNOT GUARANTEE THE ACCURACY OFTHIS INFORMATION AFTER THE DATE OF PUBLICATION AND DISCLAIMS RELIABILITY FOR CHANGES, ERRORS OR OMISSIONS.
FSC B17-2 2. LCD MONITOR DESCRIPTION The LCD MONITOR will contain a main board, a PWPC board, an audio board and a keypad board which house the flat panel control logic, brightness control logic and DDC. The power board will provide AC to DC Inverter voltage to drive the backlight and the main board chips each voltage.
FSC B17-2 3. OPERATING INSTRUCTIONS 3.1 GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located in the front of the monitor. By changing these settings, the picture can be adjusted to your personal preferences.
FSC B17-2 4. INPUT/OUTPUT SPECFICATION 4.1 INPUT SIGNAL CONNECTOR PIN NO. DESCRIPTION PIN NO. DESCRIPTION Red Video +5V input Green Video Logic Ground Blue Video Monitor Ground N / C DDC-Serial Data DDC-Return H-Sync. Red Ground V-Sync. Green Ground DDC-Serial Clock...
FSC B17-2 4.3 POWER SUPPLY Features (ROOM TEMPERATURE 25 ±4 ) ℃ ℃ • A/C Line voltage range: 90 V - 264 V • A/C Line frequency range: 47 Hz - 63 Hz • Current: 1.5 A max. at 100V 0.7 A max. at 240V •...
FSC B17-2 5.2 SOFTWARE FLOW CHART Page 18 of 55...
Page 19
FSC B17-2 1). MCU initialize. 2). Is the eeprom blank? 3). Program the eeprom by default values. 4). Get the PWM value of brightness from eeprom. 5). Is the power key pressed? 6). Clear all global flags. 7). Are the AUTO and SELECT keys pressed? 8).
FSC B17-2 8.2 TROUBLE SHOOTING 8.2.1 MAIN BOARD No power No power Press power key and look if the picture is normal Please reinsert and make sure the AC of 100-240 is normal Reinsert or check the Adapter/Inverter section Measure U201 PIN2=1.8V U202 PIN2=3.3V...
Page 35
FSC B17-2 No picture (LED orange) No picture The button if under X601 oscillate Replace X601 control waveform is normal Check Correspondent Check reset circuit of component U601 is normal Measure U201 PIN2=1.8V U202 PIN2=3.3V Replace U601 X401 oscillate waveform is normal...
Page 36
FSC B17-2 White screen White screen Measure Q204 base X601 oscillate waveform is normal is high level? Replace X601 Check Q204,Q203 are Check reset circuit of broken or CN503 solder? U601 is normal Check Correspondent Check Correspondent component. component. Replace U601...
FSC B17-2 8.2.2 INVERTER BOARD No power No power Check AC line volt 110V or 220V Check AC line Check the voltage of C904(+) Check F901, BD901 Check start voltage for the pin3 of IC901 Check R906, R907, IC901 The auxiliary voltage (pin 7) is between 10V-16V jumping...
Page 38
FSC B17-2 No backlight Check C201 (+) =12V Check F201 Check D201/Q209/Q210 Check ON/OFF signal Check Interface board Check U201 pin9=12V voltage Change Q201 or Q202 Check the pin7/10 of U201 if have waveforms Short Q203/Q204 if the picture normal...
FSC B17-2 8.2.3 KEY PAD BOARD OSD is unstable or not working Connect Key Pad Board Is Key Pad Board connecting normally? Replace Button Switch Is Button Switch normally? Is Key Pad Board Normally? Replace Key Pad Board Check Main Board...
B. MEM.CHANNEL 4 (6500 color): 6500 color temp. parameter is x = 315±15, y = 325 ±15. 3. into factory mode of B17-2 Press MENU button during 2 seconds along with press Power button will activate the factory mode, then MCU will do AUTO LEVEL automatically.
Page 55
Parallet-res Buck Parallet-resonant (·§²¤¹Ï) inverter Circuit Driver Dimming control CCFL control onant Connector FSC B17-2 15G8145 1 BASE BRACKET 15G8146 1 KEVSINGTON BRACKET 33G4818 2 POWER LENS 33G4819BAS L KEY PAD 33G4821 EF L ROLLER COVER-B 34G1508 EF B STAND COVER(TOP)
