Endeavor IO-505 Owner's Manual

I O - S E R I E S B O X C O N T E N T S
(2) Cabinet Speakers notched &
(2) Attached "U" brackets solid end-caps
R E A R C O N F I G U R A T I O N S
Elegant cover
conceals and protects
connection terminals
rear mounted view
with SE-DBLSVL
Swivel Bracket
(not included)
(8) rubber feet
Owner's Manual
Warranty Card
Bookshelf
Configuration
Shown with
the included
U-Bracket
IO-505, 605, 805
2-way Cabinet
Indoor / Outdoor
Loudspeaker
S P E C I F I C A T I O N S
Kevlar Woofer:
Frequency Response:
Power Handling:
Sensitivity:
Impedance:
Woofer / Tweeter:
Grille:
Available Colors:
Warranty:
F E A T U R E S
Sealed, port-less design enclosure prevents bugs and moisture from
entering cabinet.
Indoor / outdoor bass equalization
Versatile mounting options, includes standard type "U" bracket, and
mounting bosses on rear for optional double-swivel mounting brackets.
Suitable for use on book shelves with bracket-less finished look
®
IO-505 IO-605 IO-805
5-1/4" 6-1/2" 8" Size
40 - 21K 38 - 21K 35 - 21K Hz
50 / 100 60 / 120 70 / 140 watts nom. / max.
87 88 89 dB 1 watt / 1 meter
8 8 8 ohms
Dupont® Kevlar woofer with butyl rubber surround
1" Tetoron® soft dome pivoting tweeters
Rust proof Perforated Aluminum Grille which is
epoxy painted for long life in high humidity and
salt air environments.
White (IO-505W) & Black (IO-505B)
White (IO-605W) & Black (IO-605B)
White (IO-805W) & Black (IO-805B)
All cabinets, grilles & brackets are
paintable to match your decor.
Lifetime Limited Warranty
