Summary of Contents for Star SC18
- Page 1 STRIP HEATERS MODEL SC18, SC24, SC30, SC36, SC42, SC48, SC60, SC72 Installation and Operation Instructions 2M-Z16424 Rev. - 10/31/2012 IL2532 SC36P...
-
Page 2: Safety Symbol
RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. Star reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment. - Page 3 Dimensions Single Model Dual Model Model Length Height Width Width w Lights Width Width w Lights SC18 18” (45.7 cm) SC24 24” (61.0 cm) SC30 30” (76.2 cm) SC36 36” (91.4 cm) 2.5” 6” 9” 15” 18” (5.1 cm) (15.25 cm) (22.9 cm)
-
Page 4: General Information
GENERAL INFORMATION This equipment is designed and sold for commercial use only by personnel trained and experienced in its operation and is not sold for consumer use in and around the home nor for use directly by the general public in food service locations. Before using your new equipment, read and understand all the instructions &... -
Page 5: Conduit Connection
ELECTRICAL INSTALLATION continued Conduit Connection Supply Wire Units supplied with conduit connections have had Circuits Minimum AWG Copper wire needed all internal connections pre-wired and must be up to 15 amps No. 14 installed using angle brackets. All final electrical 15 to 20 amps No. -
Page 6: Installation
INSTALLATION TO REDUCE THE RISK OF FIRE, THE APPLIANCE IS TO BE INSTALLED IN NON- COMBUSTIBLE SURROUNDINGS ONLY, WITH NO COMBUSTIBLE MATERIAL WITHIN 18" (45.7 cm) OF THE SIDES, FRONT OR REAR OF THE APPLIANCE OR WITHIN 40" (101.6 cm) ABOVE THE APPLIANCE. THE APPLIANCE IS TO BE MOUNTED ABOVE CAUTION SURFACES OF NON-COMBUSTIBLE CONSTRUCTION WITH NON-COMBUSTIBLE SURFACES AND SURFACE FINISH, WITH NO COMBUSTIBLE MATERIAL AGAINST THE... - Page 7 INSTALLATION continued Installing Portable Legs Single strip heaters containing a power cord can have portable leg assemblies like the C-Leg & T-Leg Stands shown here. DO NOT PLACE ANYTHING ON TOP OF THE STRIP HEATERS, THE SURFACE GETS HOT. . Position the unit upside down, it must be unplugged. .
-
Page 8: Operation
With unit cool, remove the bad bulb and replace with a NSF standard bulb made for food holding and display area, for replacement bulb contact a qualified Star service agent of call Star parts department at --0. - Page 9 LIMITED EQUIPMENT WARRANTY All workmanship and material in Star products have a one (1) year limited warranty on parts & labor in the United States and Canada. Such warranty is limited to the original purchaser only and shall be effective from the date the equipment is placed in service. Star's obligation under this warranty is limited to the repair of defects without charge, by the factory authorized service agency or one of its sub-agencies.
- Page 10 Nameplate SK2619 Rev. - 9/7/2012 Model: Strip Heaters w/o Lights...
-
Page 11: Parts List
Parts List October , 0 Model: SC18, SC24, SC30, SC36, SC42, SC48, SC60, SC72 Strip Heaters (non-lighted) Fig No Part Number Description Quantity Application D5-Z15915 COVER, END, 6 WIDE 2C-Z15735 SCR.8-32X1/2 F RHP STL NP 2C-6349 SCREW #8X3/8 B THP STL NP 2C-8477 CLIP .125 PO STL PHOS... - Page 12 Model: SC18, SC24, SC30, SC36, SC42, SC48, SC60, SC72 Strip Heaters (non-lighted) Fig No Part Number Description Quantity Application 2E-6272 CORD SET 14-3 SJTO 6-8 2K-Z15730 CORDGRIP, LIQUID TIGHT, NYLON 2C-Z15731 LOCKNUT, NYLON 2K-34136X FTG FLEX CON 90 X 1/2 MOD 2E-Z15932 FLEX.
