1 Description of the devices
1.1
Wippy: the remote control
Uses 3 alkaline batteries
types AAA or LR03
1.2
eConv devices
Description of the Status indicator
No Light
Device connected
Yellow
Device not connected
Yellow
Connection in progress
Blinking
Lights for 5 seconds to indicate
Green
that there is a connection
Red
Hardware errors (call assistance)
________________________________________________________________________
Preliminary
iGreen
U
G
SER
1
Status indicator
2
Command button to
connect devices
From Main Power
Max power:
16A to 230Vac
When installing the system
bind the
Wippy first (easily identified as they have a
battery). An eConv+ or eSwitch+ is the main
communicator, once this is binded with the
Wippy, bind each other eConv unit one by one.
UIDE
Electrical connections to eConv
Live
Neutral
Earth
3600 Watts
IMPORTANT
eConv+ or eSwitch+
Non compliance will result in system failure.
Brief Guide Ver:002
Pilot Wire
Live
Neutral
To Electric Radiator
Earth
always
connect and
with the
1 / 6
