Second Sun

Flameless Tank Heater

Installation, Operation & Maintenance

Manual

151 South Michigan Street, Seattle, Washington, USA 98108

Tel: +1-206-789-5410

Fax: +1-206-789-5414

Web:

www.algas-sdi.com

ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856

Table of Contents

Need help?

Do you have a question about the Second Sun and is the answer not in the manual?

Questions and answers

Summary of Contents for Algas SDI Second Sun

Page 1 ...Innovative vaporizing and pressure building solutions ™ Second Sun Flameless Tank Heater Installation, Operation & Maintenance Manual 151 South Michigan Street, Seattle, Washington, USA 98108 Tel: +1-206-789-5410 Fax: +1-206-789-5414 Web: www.algas-sdi.com ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 2 When components are replaced with components not approved for use in our FM/UL listed equipment, the FM/CSA listing becomes void for that unit. ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 3: Warranty Registration
All rights reserved. No part of this manual may be reproduced or copied in any form or by any means, photographic, electronic, or mechanical, without the prior express written consent from Algas-SDI International, LLC, Seattle, Washington, USA. APPROVALS ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 4 ASDI CONTACT NUMBERS If you have questions, need help with your equipment, or want information on other products, contact Algas-SDI at: Telephone: 206.789.5410 Facsimile: 206.789.5414 Email: sales@algas-sdi.com Internet: http://www.algas-sdi.com ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 5: Table Of Contents
Figure 7 – Heater does not start Figure 8 – Heater does not come up to temperature after 30 minutes Figure 9 – Heater and pilot both turn off Figure 10 – Wiring Diagram ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 6 Figure 11 – Adjustable Pressure Switch Settings Page Appendix A: Technical Information 21-23 Terminal Strip Drawing Spare Parts List ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 7 This page is left intentionally blank ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 8 ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 9: Introduction
On a temporary basis, the SECOND SUN™ may be used to boost the pressure in a container that has been over drawn and refrigerated.
Page 10 The SECOND SUN™ is a “staged” heater consisting of a smaller portion called the “pilot” heater and a larger section called the “main” heater. These two sections are both contained within the overall heater and cannot be seen without removing the catalyst material.
Page 11 Figure 1 – SECOND SUN Starting instructions Removable controls cover. Gas safety valve. High Temperature safety switches Over-pressure safety switch. Access holes to fuel inlet fittings. ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 12 This page is left intentionally blank ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 13: Installation
INSTALLATION GENERAL REQUIREMENTS Install the Second Sun™ on a “raised” tank to allow space for the heater to be rotated under the tank. Inspect the heater face visually for any damage to the catalyst material. At the same time, the tank surface, covered by the heater, should be inspected for corrosion, using the same method for inspecting all other exposed surfaces.
Page 14 15. The temperature switches should be in close contact over the full surface of the switch. Loosen the turnbuckle on the control cover side for an easier inspection of the switches. ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 15 Once the tank has been filled, the main heater will come on automatically. Heater should be turned OFF while refueling the tank. ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 16 HEATER SHOULD BE ADJUSTED OUTWARD IN ITS ENCOLUSRE DEPENDING UPON THE SIZE OF TANK ITS PRESSURIZING. A 1INCH SPACE SHOULD BE MAINTAINED BETWEEN THE HEATER FACE AND TANK SURFACE FOR PROPER VAPORIZATION. ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 17: Installation
Open to adjust pressure to heater To High Pressure tank connection To Low Pressure regulator connection Connect regulator low pressure supply here. CRITICAL: Connect to unregulated tank vapor space ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 18 This page is left intentionally blank ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 19: Operation
OPERATION GENERAL Second Sun™ is controlled by tank pressure. The tank heater utilizes an adjustable operating pressure switch with a range of 55 psi – 100 psi. When the pressure in the storage tank falls below the operating switch set point the heater will cycle on providing heat (energy) into the liquid stored in the tank.
Page 20: Operation
TEMPERATURE SWITCHES ARE MAKING FULL CONTACT WITH THE TANK SURFACE. FAILING TO DO SO WILL TRIGGER THE TEMPERATURE SWITCHES AND KEEP THE HEATER FROM MONITORING TANK SURFACE TEMPERATURES PROPERLY ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 21: Maintenance
MAINTENANCE GENERAL REQUIREMENTS Second Sun™ is designed for long term trouble free operation. Because of the nature of its use, and the low maintenance requirements, it is important to provide scheduled maintenance. Below is a check off list for annual inspections.
Page 22: Maintenance
After fuel lines have been emptied, loosen gas fittings from the access holes on the back before attempting to remove the cover. ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 23: Troubleshooting
HEAT BEFORE ACTUATING PILOT VALVE. DEPRESS PILOT KNOB FOR 60 SECONDS TO ALLOW PROPER CATALYZATION PROCESS TO BEGIN. FOLLOW STEPS 8 THROUGH 10 OF STARTING INSTRUCTIONS TO FINISH START UP PROCEDURE. ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 24 PRESSURE DROPS BELOW 57 PSI, HEATER UP TO TEMPERATURE. WILL TURN ON AUTOMATICALLY. PROPANE LEVEL IN TANK IS BELOW UPPER TEMPERATURE SWITCH. REFILL TANK AND HEATER WILL COME UP TO TEMPERATURE AUTOMATICALLY. ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 25 BROKEN. CHECK ALL WIRES AND CONNECTIONS. SOLDER ALL WIRING REPAIRS AND COVER REPAIR WITH HEAT SHRINK FOR ADDITIONAL PROTECTION. RESTART HEATER USING STARTING INSTRUCTIONS GIVEN ON HEATER COVER OR MANUAL. ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 26 Figure 10: Wiring Diagram ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
Page 27 Every 60 degrees of counter-clockwise rotation (one wrench flat) will increase the pressure setting by 30 psi.  Every 60 degrees of clockwise rotation (one wrench flat) will decrease the pressure setting by 30 psi. ASDI Installation, Operation and Maintenance Manual – SECOND SUN – P/N 51856...
