Summary of Contents for Mixtelematics 4310i
- Page 1 4310i Installation Manual Updated 22 October 2013 www.mixtelematics.com...
- Page 2 Installation of the FM 4310i unit 1. Position the 4310i unit in your vehicle 1.1. The FM 4310i unit must be installed horizontally – or as close to horizontal as possible. A few degrees of tilt are acceptable. 1.2. The unit should preferably be mounted somewhere under the dashboard, but other positions such as under the centre console or under the front seats may also work.
- Page 3 2.3. After a short pause, the FM 4310i unit will ‘wake up’. switch the FM 4310i into Diagnostic Mode by pressing the Shift (up arrow) button on the Remote Control Unit followed by the Alert (orange) button repeatedly until ‘Diagnostic Enabled’...
- Page 4 2.7. If these conditions cannot be met, try moving the FM 4310i unit to a more optimal position. If the unit is left in Self-test mode during the search for an optimal position, ensure that a minute or two is allowed in each new position for the self-test software to acquire the new data.
- Page 5 4.4. Care must be taken not to damage adjacent wires when working with harnesses or bundles of wires. This is especially important when using side cutters, stripping knives, soldering irons or heat guns. 4.5. The FM 4310i harness can be cut shorter but take care not to cut it so short as to eliminate the in-line fuse unit.
- Page 6 Depending on whether you’re a new user or an existing user intending to add a vehicle to the site, please follow the either Step 1 (Registering a new user with a new vehicle (new FM 4310i unit) or Step 2 (Existing user adding an additional vehicle (additional FM 4310i unit)) below.
-
Page 7: Final Checks
1.1. Log onto the relative 4310i website region. Select ‘Click here to register as a new user’ on the Home Page, just under the login box. 1.2. Fill in the IMEI number and Registration Pin as shown on the ‘Important Numbers’ labels in the packaging, that accompanied your unit. - Page 8 Note: A reply is sent to the unit owner and not to the mobile phone that sent the original SMS message. System Test To test your FM 4310i unit, send an SMS message from any mobile phone to your unit’s phone number in the following format: <unit access password>...
-
Page 9: Installation Faqs
Note: A reply is sent to the unit owner and not to the mobile phone that sent the original SMS message. Pair New Remote Control Unit To pair an additional remote control unit with your FM 4310i unit, send an SMS message from any mobile phone to your unit’s phone number in the following format: <unit access password>... - Page 10 How does ambient temperature affect the FM 4310i unit? As a reliability precaution, the FM 4310i unit will shut down when it reaches an internal temperature greater than 70 degrees Celsius. It will automatically restart once the unit cools down again. The unit also stops charging the internal backup battery above 45 degrees Celsius, but this should be of no consequence as the unit runs off the car battery at all times and keeps its internal battery fully charged automatically.
-
Page 11: Trouble-Shoot Chart
Trouble-shoot chart 1 Updated 22 October 2013 www.mixtelematics.com... - Page 12 Trouble-shoot chart 2. Updated 22 October 2013 www.mixtelematics.com...
- Page 13 4310i Remote Control Operation BUTTON IN TRIP OUT OF VOICE PROMPT ACTION COMBINATION MODE TRIP MODE SILENCE SHIFT "Plop" Enters SHIFT Mode for 3 seconds GREEN Disarms the security system (if security system installed and enabled) ...
- Page 14 Enters SHIFT Mode for 3 seconds GREEN "Your unit is disarmed" Disarms the security system (if security system installed and enabled) GREEN Unlocks doors (if central locking system installed and enabled) Updated 22 October 2013 www.mixtelematics.com...
- Page 15 Gx10 ALERT "Plop, alert event" Sends Alert SMS and e-mail messages to specified people SHIFT, ALERT "Voice, diagnostic Switches to "Voice and Diagnostics Disabled" disabled" mode Updated 22 October 2013 www.mixtelematics.com...
