Service Manual
Model : XG-52x[V][K] Series
XG-52x[V][K] Series
XW-52x[K] Series
DAEWOO DAT CO., LTD.
SN : 9CD8304100
XG-53x[V][K] Series
XW-52x[K] Series
XW-53x[K] Series
XG-53x[V][K] Series
XW-53x[K] Series
JUN. 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XG-522 and is the answer not in the manual?

Questions and answers

Related Manuals for DAT XG-522

Summary of Contents for DAT XG-522

  • Page 1 SN : 9CD8304100 Service Manual Model : XG-52x[V][K] Series XG-53x[V][K] Series XW-52x[K] Series XW-53x[K] Series XG-52x[V][K] Series XG-53x[V][K] Series XW-52x[K] Series XW-53x[K] Series DAEWOO DAT CO., LTD. JUN. 2005...

  • Page 2: Table Of Contents

    Mini component sound system with CD-R/RW/MP3/Video CD playback XG-522[V]/524[V][K)/525[V][K)/526[V][K)/527[V][K)/528[V][K) XG-532[V]/534[V][K)/535[V][K)/536[V][K)/537[V][K)//538[V][K) Mini component sound system with CD-R/RW playback XW-522/524[K)/525[K)/526[K)/527[K)/528[K) XW-532/534[K)/535[K)/536[K)/537[K)/538[K) Table of Contents SAFETY PRECAUTIONS ..................1 ADJUSTMENTS ......................2 EXPLODED VIEW AND PARTS LIST ..............3 WIRING DIAGRAM ....................4 BLOCK DIAGRAM ....................

  • Page 3: Safety Precautions

    Safety Precautions WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE laundry tub, in a wet basement, or near a swimming pool, THIS APPLIANCE TO RAIN OR MOISTURE. and the like. 2. Carts and Stands - The appliance PORTABLE CART CAUTION should be used only with a cart or RISK OF ELECTRIC SHOCKS...
  • Page 4 Safety Precautions 13.Outdoor Antenna Grounding - If an outside antenna is 15.Object and Liquid Entry - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through connected to the receiver be sure the antenna system is openings.

  • Page 5: Adjustments

    Adjustments TAPE SECTION Output Level Measurement Input Point Scope Point 47 kohm R-CH VTVM Input Level Measurement Point L-CH 47 kohm Test Tape be used Tape Contents MTT-111N 3 KHz Tape Speed Adjustment MTT-114N 10 KHz Head Azimuth Adjustment MTT-5511/ Blank Record Frequency Property HEAD ADJUSTMENT (AZIMUTH)
  • Page 6 Exploded View and Mechanical Parts List XG-522[V] Model Only 27-1 27-2...
  • Page 7 Exploded View and Mechanical Parts List...
  • Page 8 Title Exploded View and Mechanical Parts List XG-524[V][K]/525[V][K]/526[V][K] Models Only 34-1 34-3 27-1 34-2 27-2 XG-525 XG-526...
  • Page 9 Exploded View and Mechanical Parts List...
  • Page 10 Title Exploded View and Mechanical Parts List XG-527[V][K]/528[V][K]/XW-527[K]/528[K] Models Only 34-2 13-1 13-2 34-1 27-1 27-2 XW-527 / XG-527 [100W]...

  • Page 11: Exploded View And Parts List

    Exploded View and Mechanical Parts List PARTS NAME CODE NO. DESCRIPTIONS Q'TY REMARKS PARTS NAME CODE NO. DESCRIPTIONS Q'TY REMARKS SCREW TAPTITE 7173261011 TT2BIN 2.6*10 MFZN PANEL FRONT 9CD0313700 HIPS, SPRAY WINDOW DOOR "A" 9CD16224A0 ACRYL, SMOG SCREW TAPTITE 7173301011 TT2 BIN 3*10 MFZN WINDOW DOOR "B"...
  • Page 12 Exploded View and Mechanical Parts List XW-522 Model Only 27-1 27-2...
  • Page 13 Exploded View and Mechanical Parts List...
  • Page 14 Title Exploded View and Mechanical Parts List XW-524[K]/525[K]/526[K] Models Only 34-1 34-3 27-1 34-2 27-2 XW-526 XW-525...
  • Page 15 Exploded View and Mechanical Parts List...
  • Page 16 Exploded View and Mechanical Parts List XG-532[V]/XW-532 Models Only 13-2 13-1 XG VER. 30-1 30-2...
  • Page 17 Exploded View and Mechanical Parts List...
  • Page 18 Title Exploded View and Mechanical Parts List XG-534[V][K]/535[V][K]/536[V][K], XW-534[K]/535[K]/536[K] Models Only 37-1 13-2 13-1 XG VER. 37-3 30-1 37-2 30-2 XW/XG-536 XW/XG-534...
  • Page 19 Exploded View and Mechanical Parts List...
  • Page 20 Title Exploded View and Mechanical Parts List XG-537[V][K]/538[V][K], XW-537[K]/538[K] Models Only 37-2 13-2 13-1 XG VER. 37-1 30-1 30-2 XW-537 / XG-537 [100W]...
  • Page 21 Exploded View and Mechanical Parts List PARTS NAME CODE NO. DESCRIPTIONS Q'TY REMARKS PARTS NAME CODE NO. DESCRIPTIONS Q'TY REMARKS PANEL FRONT 9CD0313700 HIPS, SPRAY SCREW TAPTITE 7173261011 TT2BIN 2.6*10 MFZN WINDOW DOOR "A" 9CD16224A0 ACRYL,SMOG SCREW TAPTITE 7173301011 TT2 BIN 3*10 MFZN WINDOW DOOR "B"...

  • Page 22: Wiring Diagram

    Title Wiring Diagram...

  • Page 23: Block Diagram

    Title Block Diagram...

  • Page 24: Schematic Diagram

    Schematic Diagram CD Section...

  • Page 25: Mp3/Vcd Section

    Schematic Diagram MP3/VCD Section : XG-52x[V][K]/XG-53x[V][K] Series Only...

  • Page 26: Front Section

    Schematic Diagram Front Section : XG-52x[V][K]/XW-52x[K] Series Only...
  • Page 27 Schematic Diagram Front Section : XG-53x[V][K]/XW-53x[K] Series Only...

  • Page 28: Tape And Function Section

    Title Schematic Diagram TAPE and Function Section...

  • Page 29: Amp Section

    Schematic Diagram AMP Section : XG-522[V]/532[V], XW-522/532 Models only...
  • Page 30 Schematic Diagram AMP Section : XG-524[V][K]/525[V][K]/526[V][K]/534[V][K]/535[V][K]/536[V][K], XW-524[K]/525[K]/526[K]/534[K]/535[K]/536[K] Models only...
  • Page 31 Schematic Diagram Digital AMP Section : XG-527[V][K]/528[V][K]/537[V][K]/538[V][K], XW-527[K]/528[K]/537[K]/538[K] Models only...

  • Page 32: Mic Section

    Title Schematic Diagram MIC Section : Karaoke Models only...

  • Page 33: Power Section

    Schematic Diagram POWER Section...

  • Page 34: Pcb Pattern Layout

    P.C.B Pattern Layout MAIN <Top View>...
  • Page 35 P.C.B Pattern Layout MAIN <Bottom View>...
  • Page 36 P.C.B Pattern Layout AMP Section <Top View> <XG-524[V][K]/525[V][K]/526[V][K]/534[V][K]/535[V][K]/536[V][K], <XG-522[V]/532[V], XW-522/532 Models Only> XW-524[K]/525[K]/526[K]/534[K]/535[K]/536[K] Models Only>...
  • Page 37 L802 R848 R816 PCB FIX PAD CM817 CM849 CM820 CM851 J801 L801 R847 CM822 R817 CW803 CM818 HC806 HC817 HC815 HC805 HC825 HC804 HC801 HC858 HC802 HC859 HC803 HC827 CM823 CM821 CM824 CM819 FQPF15P12 FQPF16N15 FQPF16N15 FQPF15P12 HC882 HC881 HC884 TH801 HC822 HC839...
  • Page 38 Title P.C.B Pattern Layout FRONT : XG-52x[V][K], XW-52x[K] Series Models Only <Top View>...
  • Page 39 P.C.B Pattern Layout FRONT : XG-52x[V][K], XW-52x[K] Series Models Only <Bottom View>...
  • Page 40 Title P.C.B Pattern Layout FRONT : XG-53x[V][K], XW-53x[K] Series Models Only <Bottom View>...
  • Page 41 Title P.C.B Pattern Layout FRONT : XG-53x[V][K], XW-53x[K] Series Models Only <Bottom View>...
  • Page 42 P.C.B Pattern Layout POWER <Bottom View> <Top View>...
  • Page 43 Front PCB ASS'Y [9CDC078100] : PCB FRONT AS Location Part Code Part Name Description Remark FD701 DHNA11MS26 VFD HNA-11MS26 HD351 HD352 HD353 HD381 HD701 HD702 HD703 HD704 DZDS160--- DIODE SW CHIP KDS160(KDS511) HD705 HD706 HD707 HD712 HD713 HQ351 HQ352 HQ353 HQ704 TZTC3875S- TR CHIP KTC3875Y...
  • Page 44 AMP PCB ASS'Y [9CDC07634] : PCB AMP AS Location Part Code Part Name Description Remark D801 D802 DZN4148--- DIODE IN4148 AUTO 52MM XW-522,532 1TDA7269A- TDA7269A XG-522,532 XW-524.534 1STK433030 R CHIP STK433-030 XG-524,534 IC801 XW-525,535 1STK433060 STK433-060 XG-525,535 XW-526,536 1STK433070 STK433-070...
  • Page 45 DRLZ5R6B-- DIODE ZENER CHIP RLZ5.6B IC901 1L4959---- L4959 IC991 1AIC1117CY- IC REGULATOR AIC117-CY XW-522,532 5TP0066949 TRANS POWER EI=66X30 127/220V, 60Hz/50Hz XG-522,532 XW-524.534 5TP0066950 TRANS POWER EI=66X45 127/220V,60/50Hz XG-524,534 XW-525,535 5TP0066951 TRANS POWER EI=74 x 42 127/220V,60/50Hz XG-525,535 PT991 XW-526,536 5TP0066952...
  • Page 46 DAEWOO DAT CO., LTD.
