Domestic Chescold F400 Manual

Domestic chescold f400 explorer fridge/freezer, chescold rc1180 combi box
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model:
Chescold F400 Explorer Fridge/Freezer
Part Number: F400
Specifications:
Height:
500mm
Width:
610mm
Depth:
510mm
Consumption:
Electric
240V - 120 Watts
Battery
12V - 120 Watts
10 Amps
Gas
Approx. 375 grams
per day
Capacity:
Approx. 39 litres
Weight: Approx. 23 kg
Model: Chescold RC1180 Combi Box
Part Number: RC1180
Specifications:
Height:
525mm
Width:
665mm
Depth:
505mm
Consumption:
Electric
240V - 120 Watts
Battery
12V - 120 Watts
10 Amps
Gas
Approx. 375 grams
per day
Capacity Gross:
Approx. 50 litres
Refrigerator Capacity:
Approx. 30 litres
Freezer: Capacity:
16 litres
Removable Divider
Capacity: Approx 4 litres
Weight: Approx. 25 kg
PORTABLE REFRIGERATORS AND FREEZERS
Index
The removable internal divider is
used to split the Combi Box into
one compartment for refrigeration
and another for freezing. When the
divider is removed, the whole unit
becomes one powerful refrigerator.

Advertisement

Table of Contents
loading

Related Manuals for Domestic Chescold F400

Summary of Contents for Domestic Chescold F400

  • Page 1 PORTABLE REFRIGERATORS AND FREEZERS Model: Chescold F400 Explorer Fridge/Freezer Part Number: F400 Specifications: Height: 500mm Width: 610mm Depth: 510mm Consumption: Electric 240V - 120 Watts Battery 12V - 120 Watts 10 Amps Approx. 375 grams per day Capacity: Approx. 39 litres Weight: Approx.

  • Page 2: Table Of Contents

    CONTENT CONTENT 1. Unpacking 2. View of the appliance 3. Cleaning 4. Positioning the appliance 5. Using the appliance 5.1. From 240 Volt electrical mains 5.2. From 12 Volt vehicle battery 5.3. From LP bottled gas 6. Useful suggestions 7. Defrosting, cleaning and maintenance 8.

  • Page 3: Unpacking

    1. Unpacking After removal from the cardboard packaging, make sure the appliance is not damaged. If you find damage to the appliance resulting from transport, report it immediately to the transportation firm. 2. View of the appliance Figure 1. 4. grill 1.

  • Page 4: Cleaning

    3. Cleaning Clean both the inside and outside of the appliance before putting it into use. To do so, use a soft towel, lukewarm water and a non-abrasive detergent. Ensure water does not enter the rear cover grill or the control panel. Afterwards, wipe the appliance with a clean towel and cleanwater, and then wipe it dry.

  • Page 5: From 12 Volt Vehicle Battery

    5.2. Operating from 12 Volt vehicle battery Make sure the voltage shown on the data plate of the appliance matches the voltage of the vehicle battery (12V). In 12V operation, the appliance runs continuously without temperature control. The appliance is supplied with a matching pair of 12 Volt MALE + FEMALE plugs (see 9,2 connection to vehicle power source).

  • Page 6: Useful Suggestions

    6. Useful suggestions When setting out on a trip, run the appliance on 240 V for 24 hours prior to departure. Place food in a pre-cooled condition into the appliance. Frost forms on the evaporator panel when in operation. When opening the lid or putting in food, some of this frost melts and collects in the form of water on the bottom of the appliance.

  • Page 7: Trouble Shooting

    8. Trouble shooting Connecting to 240 Volt electrical mains Before calling a service technician please check Make sure no other energy source is connected carefully the operating instructions, service booklet (gas, 12V). and the warranty terms and conditions: The appliance may only be operated from nominal Are location and ventilation satisfactory? voltage mains as shown on the data plate.

  • Page 8: Connecting To 12 Volt Vehicle Battery

    9.2 Connecting to 12 Volt vehicle battery Make sure no other energy source is connected (gas, 240V). The 12V female socket is on the backwall of the appliance, while the male plug is an accessory supplied with your new RC1180. Connect the wires from the 12 Volt battery to the male plug (see recommended 12 Volt wiring for vehicle).

  • Page 9: Connection Of Gas Supply

    Connection of gas supply The gas bottle (Propane) may only be used in an upright position and particular care must be taken Always connect in the following sequence: every time the appliance is connected to the gas GAS BOTTLE → PRESSURE-REGULATOR → bottle to ensure that there are no leaks, that the →...

  • Page 10: Environmental Protection Information

    10. Environmental protection information The appliance does not contain any CFCs. Ammonia (natural hydrogen and nitrogen compound) is used as a refrigerating agent in the refrigeration unit. The ozone-friendly cyclopentane is activated as a motive agent for the PU foam insulation. Sodium chromate is used for corrosion protection (less than 2 weight % of the coolant).

This manual is also suitable for:

Chescold rc1180
