Frontier MS2342 Operator's Manual

Manure spreader
Hide thumbs
Table of Contents

Advertisement

Quick Links

O P E R A T O R ' S
M A N U A L
MANURE SPREADER
MS2342
HSMFG1212
5HPMSSD42

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS2342 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frontier MS2342

Summary of Contents for Frontier MS2342

  • Page 1 O P E R A T O R ’ S M A N U A L MANURE SPREADER MS2342 HSMFG1212 5HPMSSD42...

  • Page 3: Table Of Contents

    CONTENTS Table of Contents ..............1 Warranty &...

  • Page 4: Warranty & Notes

    WARRANTY: Warranty coverage is provided by John Deere according to the terms of the Agricultural/Commercial & Consumer Equipment Warranty Statement. Carefully read the warranty statement on the back of your original purchase order for details on coverage and limitations of this warranty. NOTES...

  • Page 5: Dealer Pre-Delivery Checklist

     Manure Spreaderwas not damaged in shipment. Check for dents and loose or missing parts. Report damage immediately to Frontier.  All bolts and fasteners are tight. ...
  • Page 6 Intentionally Left Blank...

  • Page 7: Dealer Delivery Checklist

    FRONTIER DEALER DELIVERY CHECK LIST AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS This check list that follows is an important reminder of valuable information that should be passed on to the customer at the time this machine is delivered.
  • Page 8 Intentionally Left Blank...

  • Page 9: Specifications

    2342 Specifications Cubic Ft. Struck Level....564 Gallon Capacity......4200 Tank Length........20’ Overall Length......27’7” Tank Width @ Top......97” Auger Diameter......30” Poly Lined Tank......Left Side Overrunning Clutch....... Yes Shear Bolt Protection....Yes PTO..........1000 RPM 1-3/4” Standard 1000 RPM 1-3/8”...

  • Page 10: Be Alert Symbol

    SAFETY INFORMATION ALERT! YOUR SAFETY IS INVOLVED. THIS SYMBOL IS USED THROUGHOUT THIS BOOK WHENEVER YOUR PERSONAL SAFETY IS INVOLVED. TAKE TIME TO BE CAREFUL. REMEMBER: THE CAREFUL OPERATOR IS THE BEST OPERATOR. MOST ACCIDENTS ARE CAUSED BY HUMAN ERROR. CERTAIN PRECAUTIONS MUST BE OBSERVED TO PREVENT THE POSSIBILITY OF INJURY OR DAMAGE.

  • Page 11: Explanation Of Safety Signs

    SAFETY INFORMATION Keep signs in good condition. Immediately replace any missing or damaged signs. RECOGNIZE SAFETY INFORMATION This is the safety-alert symbol. When you see this symbol on your machine or in this manual, be alert to the potential for personal injury. Follow recommended precautions and safe operating practices.

  • Page 12: Danger - Warning Signs

    SAFETY INFORMATION -10-...
  • Page 13 SAFETY INFORMATION -11-...

  • Page 14: Warning - Owner Must Read And Understand

    STAY CLEAR of hydraulic lines, they may be under extreme pressure or heat. Frontier always takes the operator and their safety into consideration and guards exposed moving parts for their protection. However, some areas cannot be guarded or shielded in order to assure proper operation.

  • Page 15: Bolt Torque Chart

    -13-...

  • Page 16: Set-Up & Assembly

    SET-UP & ASSEMBLY NOTE: Determine right or left side of the Manure Spreader by viewing it from the rear. If instructions or parts lists call for hardened bolts, refer to bolt torque chart. WHEELS & TIRES The Manure Spreader may be shipped without the wheels/tires installed. 1.

  • Page 17: Preparing For Operation

    PREPARING FOR OPERATION PREPARING MANURE SPREADER Properly lubricate the Manure Spreader, check automatic oiler level, and fill if necessary before operating. Refer to Lubrication Section of this Operator’s Manual for locations. If theManure Spreader is going to be operated in freezing temperatures, review and comply with recommendations in the Operation Chapter, under the Winter Operation section.
  • Page 18 PREPARING FOR OPERATION The Manure Spreader is equipped with a constant velocity telescoping PTO drive shaft. This constant velocity capability, results in a smooth, quiet running drive line, without power fluctuation. The Manure Spreader can only be properly hooked-up to a tractor which has PTO and hitch dimensions conforming to ASAE Standard S203.

  • Page 19: Transporting

    TRANSPORTING TRANSPORT LIGHTING & REFLECTORS Transport lighting with a 7 pin plug is standard equipment. The lighting system is to be connected to the 7 pin power receptacle (per SAEJ560B) on your tractor. If your tractor is not equipped with the proper receptacle, see your tractor dealer for details.

  • Page 20: Operation

    OPERATION EMERGENCY SHUTDOWN In case a foreign object becomes lodged in the expeller or auger area, disengage the PTO. Stop the tractor engine, remove ignition key, and allow all mechanisms to stop before cleaning or working on the machine. If an object is lodged inside the tank, block-up the discharge gate and raise the conveyor auger before attempting to remove the object.
  • Page 21 OPERATION APPLICATION RATE The side discharge style Manure Spreader features a hydraulically operated discharge gate to control the material flow out of the tank and into the expeller. Several factors influence the rate of discharge and the spread pattern. These factors include: ground speed, type or consistency of discharge material, PTO RPM, and discharge gate opening.
  • Page 22 OPERATION UNLOADING & SPREADING Packed Material To unload and spread packed material and prevent unnecessary stress on the drive line components, observe the following guidelines: 1. Make sure the auger is completely lowered. 2. Engage the tractor PTO at as low an RPM as possible. Then, slowly bring the PTO up to the rated RPM.
  • Page 23 OPERATION DRIVE CHAIN TOLERANCES Drive chains must be kept in adjustment within the following tolerances. Jackshaft Chain Spring Length - 9-3/4” to 10-1/4” Auger Chain Spring Length - 13-1/2” to 14” Expeller Drive Chain Deflection - 1/2”-3/4” AUGER & EXPELLER SPEED OPTIONS The Manure Spreader is factory equipped with drive components selected to provide the best possible performance for processing basic material and manure types available.
  • Page 24 OPERATION CONTROLS & SAFETY EQUIPMENT The Manure Spreader is provided with several features for operator safety and convenience. GUARDS & SHIELDS Whenever possible and without affecting the operation of the Manure Spreader, guards, shields and/or hinged shields have been used on this equipment to protect potentially hazardous areas.

  • Page 25: Operation

    OPERATION JACK A jack is furnished with the Manure Spreader to support the machine when the tractor is disconnected and to adjust the hitch clevis to the tractor drawbar for hookup. The jack should never be used to support a loaded Manure Spreader. When the jack is not being used to support the Manure Spreader, it should be relocated to the...

  • Page 26: Adjustments

    ADJUSTMENTS DRIVE CHAIN IDLERS Expeller Drive Chain Idler The expeller drive chain is tensioned with an adjustable sprocket Idler. The chain is properly tensioned when the chain can be deflected 1/2” to 3/4" (13-19 mm) with hand pressure. NOTE: If an Idler fails to maintain proper tension, replace the worn chain.
  • Page 27 ADJUSTMENTS FRONT & REAR AUGER SLIDES The front and rear auger slide assemblies are retained by adjustment plates with diagonal slots. To adjust, loosen retaining hardware and drive the plates downward with a hammer until the slide assembly is snug against the tank, then re-tighten the retaining hardware. Grease the slide assembly to ensure a leak free seal.

  • Page 28: Service

    SERVICE EXPELLER Periodically inspect the expeller teeth for wear or damage. Damaged, broken, or missing expeller teeth will cause excessive machine vibration. Consult with your local Frontier dealer for additional ordering information. AUGER & EXPELLER SPEED OPTIONS The expeller input drive sprocket can be changed by raising the auger and then removing the indicated sprocket which is retained by a snap ring and set screws.
  • Page 29 SERVICE TIRES & WHEELS Check the tire pressure after every 50 hours of operation. Tires should be inflated to the appropriate pressure listed in the table. Tire Pressure 28Lx26 29 PSI Wheel lug torque should be checked after every 50 hours of operation and tightened to the appropriate torque.

  • Page 30: Lubrication Guide

    LUBRICATION Become familiar with all lubrication points and establish a routine to ensure complete lubrication of Manure Spreader. GENERAL INFORMATION IMPORTANT: Catch and dispose of fluid per local waste disposal regulations whenever service is performed on hydraulic components, valves, cylinders, hoses, etc. PTO ASSEMBLY Keep the male and female shafts of the PTO well lubricated and free sliding.
  • Page 31 LUBRICATION DRIVE CHAINS The drive chains are lubricated by a automatic chain oiler. Any time that the discharge door is raised, a specified amount of oil is sent to the brushes on each of the chains. The oiler is adjustable to set the amount that is being discharged.
  • Page 32 LUBRICATION GREASING There are numerous grease fittings on the Manure Spreader. Lubricated properly and often with a high-quality grease, will prolong the life of the spreader. Replace any missing or plugged grease fittings. Wipe dirt from the fittings before greasing to prevent the dirt from being forced into the bearing or pivot. Grease should come out around the shaft on sleeve type bearings.
  • Page 33 LUBRICATION Grease Fitting Locations - Grease Every 10 Hours (or Daily) 1. Main Auger Thrust Washer (1 Zerk) 2. Main Auger Front Bearing (1 Zerk) 3. Auger Jackshaft (Zerk in Sprocket Hole) 4. 2 Idler Arms (1 Zerk on each) 5.

  • Page 34: Optional Features & Accessories

    OPTIONAL FEATURES & ACCESSORIES NOTE: The optional features & accessories listed in this chapter, are shipped with separate instruction for installation, as applicable. AUGER SPEED OPTIONS Several different drive sprockets are available to change auger speeds to various spreading needs. Sprockets are available as service parts.

  • Page 35: Troubleshooting Guide

    TROUBLESHOOTING NOTE:This Troubleshooting Chapter presents problems, causes and suggested remedies beyond the extent of loose, worn or missing parts and it was developed with the understanding that the machine is in otherwise good operating condition. PROBLEM CAUSE REMEDY 1.) Material NOT discharging Discharge gate is NOT open.

  • Page 36: Decal Location & Identification

    DECAL LOCATION Your Frontier Manure Spreader was manufactured with operator safety in mind. Located on the Manure Spreader are various decals to aid in operation, and to warn of danger or caution areas. Pay close attention to all the decals on your Manure Spreader.
  • Page 37 DECAL LOCATION 5HP51010 5HP111209C 5HP111210A 5HPLW112901 5HP72203A 5HP51010 5HP111209B 5HP1494J 5HPDCAMB 5HP9194B 5HP11599 5HP1494B 5HP1494B 5HP5896B 5HP111209A 5HP111209A 5HP311 5HP11599 5HP1494A 5HP11599 5HP1494A 5HP093020 5HP112-11176 5HP111209A 5HP3494A 5HP82602 5HP111209C 5HP11599 5HP5896B 5HP9194A 5HPDCAMB 5HPDCAMB 5HP022310 5HP9194A -35-...
  • Page 38 DECAL LOCATION 5HP111209C 5HP102196 5HP82602 5HPDCAMB 5HP9194A 5HP022310 5HPDCAMB 5HPDCRED 5HP8515 5HP1494L 5HP111209B 5HP11210B 5HP093020 5HP2FP-C 5HP11599 5HP111209C 5HPDCRED 5HPDCRED 5HP32320 5HP51010 5HP093020 5HP51010 5HP111209B -36-...

  • Page 39: Instructions For Ordering Parts - About Improvements

    INSTRUCTIONS FOR ORDERING PARTS All service parts should be ordered through your authorized Frontier dealer. They will be able to give you faster service if you will provide them with the following Model & Serial number is located on the main frame.
  • Page 40 FIGURE 1 AUGER/LINER/SLIDES/HITCH -38-...
  • Page 41 FIGURE 1 AUGER/LINER/SLIDES/HITCH ITEM PART # DESCRIPTION 5HPAPX4WE01 AUGER 5HPAPX4PL01 TUB SIDE POLY 5HPTS4 POLY TOP HOLD DOWN 5HPTS202 BACK PANEL 5HPTS7 BACK SLIDER POLY 5HPTS309 BACK SLIDER 5HPTS9 REAR AUGER BUSHING 5HPTS10 SLIDER GUIDE 5HPTS308 SLIDER GUIDE THIN 5HPTS203 FRONT POLY SLIDE 5HPTS204 FRONT SLIDE PLATE...
  • Page 42 FIGURE 1 AUGER/LINER/SLIDES/HITCH -40-...
  • Page 43 FIGURE 1 AUGER/LINER/SLIDES/HITCH ITEM PART# DESCRIPTION 5HPYBHH10105 BOLT, 5/16" X 3/4" GR. 5 5HPYBHH20101 BOLT, HEX HEAD, 5/8" X 6" GR. 8 5HPYBHH24018 BOLT, HEX HEAD, 3/4"-10 X 2" GR. 8, YELLOW ZINC FINISH 5HPYBHH32018 BOLT, HEX HEAD, 1"-8 X 4" GR. 8, YELLOW ZINC FINISH 5HPYBHH32026 BOLT, HEX HEAD, 1"...
  • Page 44 FIGURE 2 AUGER/EXPELLER DRIVE -42-...
  • Page 45 FIGURE 2 AUGER/EXPELLER DRIVE PART # DESCRIPTION ITEM 5HPTS211 COUNTER SHAFT 5HPTS212 COUNTER SHAFT REDUCTION 5HPTS213 AUGER CHAIN TENSIONER 5HPTS25 ROLLER IDLER 5HPTS214 CHAIN TENSIONER 5HP16SV328 SPROCKET/IDLER ASSY 5HPTS217 SPROCKET 140-B-54 5HPTS218 CHAIN/ROLLER #140HE X 77 5HPTS219 LINK/OFFSET (#140HE) 5HPTS220 LINK/CONNECTOR (#140HE) 5HPTS221 SPROCKET/DRIVE #80X14T (STANDARD)
  • Page 46 FIGURE 2 AUGER/EXPELLER DRIVE -44-...
  • Page 47 FIGURE 2 AUGER/EXPELLER DRIVE DESCRIPTION ITEM PART# 5HPK103 SPRING/EXTENSION 5HPG89 GREASE ZERK GREASE ZERK 90 DEGREE 5HPRG51 ZERK, 90 DEGREE, 1-13/16" X 1/8" PIPE THREAD 5HPZK90 5HPBFR28 1/8" NPT GREASE ZERK #1610 (LEFT SIDE AXLE) 5HPS36 SHIM, 3/16" SHIM, 1/8" 5HPS409 WASHER 5HPT73...
  • Page 48 FIGURE 3 EXPELLER/DISCHARGE GATE/BEARINGS -46-...
  • Page 49 FIGURE 3 EXPELLER/DISCHARGE GATE/BEARINGS PART # ITEM DESCRIPTION 5HPTS43 DOOR SEAL CLAMP 5HPTS44 EXPELLER DOOR TOP SEAL 5HPTS45 EXPELLER BEARING SHIELD 5HPHGV41 EXPELLER BEARING 5HPTS47 COVER PLATE 5HPAPX3WE69 CYL MOUNT SUB WELD 5HPAPX3SH15 DOOR CYL TOP PIN 5HPAPX33G52 DOOR CYL REINFORCEMENT 5HPDWM314 HEX PLUG 5HPAPX310G66...
  • Page 50 FIGURE 4 EXPELLER/DISCHARGE GATE/DOOR -48-...
  • Page 51 FIGURE 4 EXPELLER/DISCHARGE GATE/DOOR ITEM PART # DESCRIPTION 5HPTS232 EXPELLER SPOUT LEFT HAND 5HPTS49 PAN HINGE BRACKET LEFT 5HPTS233 EXPELLER SPOUT RIGHT HAND 5HPTS51 PAN HINGE BRACKET RIGHT 5HPTS52 DOOR SLIDER POLY 5HPTS53 EXPELLER DOOR GUIDE 5HPTS54 EXPELLER DOOR 5HPTS55 DEFLECTOR ADJUSTMENT HANDLE 5HPTS56 DEFLECTOR ADJUSTMENT LINK...
  • Page 52 FIGURE 5 EXPELLER/DISCHARGE GATE/PAN -50-...

  • Page 53: Parts

    FIGURE 5 EXPELLER/DISCHARGE GATE/PAN ITEM PART # DESCRIPTION 5HPTS67 EXPELLER 5HPTS68 EXPELLER PADDLE 5HPTS72 SWING AWAY PAN FRAME 5HPTS73 SWING AWAY PAN 5HPTS74 PAN LATCH HANDLE 5HPTS75 EXPELLER BACK POLY 5HPTS76 EXPELLER PAN POLY 5HP56N146 SHIELD ANGLE 5HPT73 SPACER 5HPK103 SPRING 5HPG89 1/4"-28 STRAIGHT GREASE ZERK...
  • Page 54 FIGURE 6 GUARDS/SHIELDS -52-...
  • Page 55 FIGURE 6 GUARDS/SHIELDS ITEM PART # DESCRIPTION 5HPTS234 FRONT SHIELD 5HPTS235 FRONT CYLINDER COVER 5HPTS236 FRONT SHIELD RIGHT SIDE 5HPTS237 GEARBOX SHIELD 5HPTS238 FRONT SHIELD LEFT SIDE 5HPTS239 HOSE HOLDER 5HPTS240 GEARBOX 5HPTS241 JACKSHAFT BRACE 5HPTS242 SHIELD HINGE 5HPTS243 FRONT SHIELD MOUNT 5HPF87 S HOOK 5HPX194...
  • Page 56 FIGURE 7 SPLASH GUARDS/RAILS -54-...
  • Page 57 FIGURE 7 SPLASH GUARDS/RAILS ITEM PART # DESCRIPTION 5HPTS245 SPLASH GUARD 5HPAPX4MS04 WOOD RAIL 5HPYBCR12010 CARR. BOLT, 3/8" X 1" GR. 5 5HPYBCR12080 CARR. BOLT, 3/8" X 3-1/4" GR. 5 CARR. BOLT, 3/8" X 6-1/2" GR. 5 5HPYBCR12123 5HPYWFL12005 WASHER, FLAT, 3/8" USS 5HPYWFL16005 WASHER, FLAT, 1/2"...
  • Page 58 FIGURE 8 HYDRAULICS -56-...
  • Page 59 FIGURE 8 HYDRAULICS DESCRIPTION ITEM PART # 5HP56015 2 X 16 CYLINDER 5HPTS105 3-1/4 x 8 CYLINDER 3 X 8 CYLINDER 5HPTS104 CYLINDER PIN 5HPLW55 CYLINDER PIN 5HPT143 5HPYPHR02010 HAIR PIN, #21-07 HYDRAULIC HOSE 1/2" X 49" -8 JIC FEMALE 5HPTS115 SWIVEL&...
  • Page 60 FIGURE 9 TANDEM AXLES -58-...
  • Page 61 FIGURE 9 TANDEM AXLES ITEM PART # DESCRIPTION 5HPAPX4WE03 DROP TANDEM BEAM RIGHT 5HPAPX4WE05 DROP TANDEM BEAM LEFT 5HPAPX4MS06 OUTSIDE AXLE BEARING 5HPAPX4MS05 AXLE BEARING TANDEM COLLAR 5HPAPX4TU08 5HPTS260 SPINDLE PIN 5HPTS394 TANDEM SPINDLE (15000 LB HUB) 5HPTS387 SEAL INNER BEARING 5HPTS388 5HPTS389 INNER RACE...
  • Page 62 FIGURE 10 OILER KIT -60-...
  • Page 63 FIGURE 10 OILER KIT PART # ITEM DESCRIPTION 5HPHGV63 RESERVOIR 5HPHGV71 OIL TUBE 5HPHGV66 FILLER HOSE 5HPHGV82 PUMP (COMPLETE) 5HPHGV86 STANDOFF 5HPHGV87 FERRULE 5HPHGV85 SLEEVE NUT 5HPHGV68 PUMP MOUNT BRACKET 5HPHGV77 EDGING 5HPTS322 EXTRA LONG BRUSH BRACKET 5HPTS98 OILER BRUSH BRACKET SINGLE 5HPHGV70 BRACKET MOUNT 5HPHGV74...
  • Page 64 FIGURE 11 FRONT GREASE LINES See page 30 for order of zerk/line destination -62-...
  • Page 65 FIGURE 11 FRONT GREASE LINES ITEM PART # DESCRIPTION 5HPTS323 1/4"-28 TO 1/8" PIPE ADAPTER 5HPGM30 1/8" 90° GREASE LINE ADAPTER 5HP45N57 1/8" NPT X 2-5/8" LONG GREASE ZERK 5HPTS265 GREASE LINE - 81" 5HPTS266 GREASE LINE - 82" 5HPTS267 GREASE LINE - 97"...
  • Page 66 FIGURE 12 LIGHTING -64-...
  • Page 67 FIGURE 12 LIGHTING PART # DESCRIPTION ITEM 5HPS309 YELLOW HAZARD LIGHT 5HPS310 RED TAIL LIGHT 5HPS308 RUBBER LIGHT MOUNT 5HP1080 TAIL LIGHT LOOM 5HPS441 FLASHER MODULE 5HPTS317 HARNESS MODULE TO TRACTOR 5HPHGV162 1/2" RUBBER WIRE HOLDER 5HPTS129 SPIRAL WRAP, 30" 5HPYBHH08100 BOLT, 1/4"...
  • Page 68 FIGURE 13 AUGER -66-...
  • Page 69 FIGURE 13 AUGER PART # DESCRIPTION ITEM 5HPAPX4WE01 AUGER 5HPTS275 AUGER PADDLE FRONT 5HPTS276 AUGER PADDLE REAR 5HPTS277 AUGER REAR ASSEMBLY 5HPTS278 AUGER INPUT SHAFT -67-...
  • Page 70 FIGURE 14 GEARBOX -68-...
  • Page 71 FIGURE 14 GEARBOX PART # DESCRIPTION ITEM 5HPTS240 GEARBOX 5HPTS279 GEARBOX COVER 5HPTS280 SECONDARY SHAFT 5HPTS281 SPUR GEAR 40 TOOTH 5HPTS282 SPLINED INPUT SHAFT 5HPTS283 SPUR GEAR 20 TOOTH 5HPTS284 BUSHING 5HPTS285 BEARING 5HPTS286 SHIM, 1/32" THICK 5HPS36 SHIM, 3/16" THICK 5HPS409 SHIM, 1/8"...
  • Page 72 FIGURE 15 AUGER FRONT/REAR HYDRAULIC CYLINDER ITEM 3" BORE 3-1/4" BORE DESCRIPTION 5HPTS160 BASE (3/4-16 SAE PORT) 5HPTS176 5HPTS158 HEAD (3/4-16 SAE PORT) 5HPTS174 5HPTS159 5HPTS175 PISTON NUT 5HPTS156 5HPTS172 5HPTS157 5HPTS173 TUBE 5HPTS153 TIE ROD 5HPTS171 5HPTS145 PISTON NUT 5HPTS166 5HPTS152 “...
  • Page 73 FIGURE 16 EXPELLER DOOR HYDRAULIC CYLINDER PART # DESCRIPTION ITEM 5HP23N142A CLEVIS CAP 5HP56174 ROD CAP 5HP56180 PISTON 5HP23N145A 5HP23N146 CYLINDER TUBE 5HP23N147 TIE ROD 5HP23N148 PISTON NUT 5HP23N149 PLUG 5HP23N150A ROD CLEVIS 5HP56187 SEAL KIT 5HP56015 COMPLETE HYDRAULIC CYLINDER 5HPYNHX12005 HEX NUT, 3/8"-16 -71-...
  • Page 74 FIGURE 17 ITEM 1000RPM (1-3/8) 1000 RPM (1-3/4) DESCRIPTION 5HP16SV274 5HP16SV275 SAFETY SLIDE LOCK REPAIR KIT 5HPTS190 5HPTS193 SAFETY SLIDE LOCK YOKE ASSEMBLY 5HPTS179 “ CROSS KIT 5HPTS180 “ CENTER HOUSING 5HPTS287 “ YOKE & SHAFT 5HP16SV383 “ GUARD REPAIR KIT 5HP16SV283 “...
  • Page 75 FIGURE 18 SCALE PART # ITEM DESCRIPTION 5HPTS335 SPINDLE LOAD CELL 5HPTS336 HITCH LOAD CELL 5HPTS83 JUNCTION BOX 5HPTS339 SCALE DISPLAY 5HPTS337 SCALE DISPLAY W/GPS (OPTIONAL) 5HPTS338 JUNCTION BOX CORD 5HPTS385 POWER CORD 5HP16SV269 TRACTOR POWER CORD 5HPGM408 SCALE HANGER BRACKET NOTE: * MEANS NOT SHOWN -73-...
  • Page 76 FIGURE 19 LID COMPONENTS -74-...
  • Page 77 FIGURE 19 LID COMPONENTS PART # DESCRIPTION ITEM 5HP52017 5142 LID SUBFRAME WELDMENT 5HP53076 CAM PIVOT WELDMENT 5HP52025 5142 LID WELDMENT 5HP0229MS04 0229 PIPE PLASTIC END PLUG 5HP0229MS06 0229 PIPE PLASTIC END PLUG 1.00 5HP0229WE12 CYLINDER BASE MOUNT WELDMENT 5HPYBHH16012 BOLT, 1/2-13 X 1 GR 8 5HPYWFL16005 1/2"...
  • Page 78 FIGURE 20 LID HYDRAULICS -76-...
  • Page 79 FIGURE 20 LID HYDRAULICS ITEM PART # DESCRIPTION 5HP56070 HOSE, FCR TO RCB 351" 5HP56069 HOSE, VBR TO RCR 455" 5HPCHM206 06 90 DEG TO 3/4-16 ORB FITTING 5HP1023 06-06 M/F ORIFICE, 0.047 5HP1019 3.25 IN X 20 IN STROKE MASTER CYLINDER 5HP8267 MASTER CYLINDER SEAL KIT 5HP1020...
  • Page 80 FIGURE 21 LID SEAL -78-...
  • Page 81 FIGURE 21 LID SEAL ITEM PART # DESCRIPTION 5HP52033 5142 SEAL BELT, LONG 5HPYBCR12006 CARR. BOLT, 3/8" X 1" GR. 2 FULL THREAD 5HP0229MS02 SEAL BELT, SHORT 5HPYWFL12005 FLAT WASHER, 3/8", GR. 5 5HPYNNY12005 HEX NUT, NYLON LOCKNUT, 3/8" 5HP0229MS05 BELTING, CHUTE 5HPYBHH12010 BOLT, 3/8"...

  • Page 82: Service & Parts Notes

    SERVICE & PARTS NOTES -80-...
