V
ICTORY
DIRECT-VENT SEALED COMBUSTION BOILERS
HOT WATER MODELS VSPH-60 THROUGH VSPH-180
GAS-FIRED CAST-IRON BOILERS FOR NATURAL AND L.P . PROPANE GASES

TABLE OF CONTENTS

Dimensions, Rating and Orifice Sizes......................................................2
Identification of Parts ................................................................................3
Installation Requirements .........................................................................4
Venting Application...................................................................................5
Boiler Room Air Supply and Ventilation...................................................5
Flue Gas Venting Requirements ..............................................................5
Vent Material ............................................................................................5
Air Intake Material ....................................................................................6
Flue and Air Intake Restrictions ...............................................................6
Non-Direct Vent Installation......................................................................8
Sidewall Venting, Non-Direct Vent ...........................................................8
Vent Termination Location and Clearance ...............................................8
Non-Direct Vent Vertical Venting ..............................................................8
Direct Vent Installation..............................................................................8
Sidewall Venting, Direct Vent ...................................................................8
Vent/Air Intake Termination Installation ....................................................8
Venting and Air Intake Regular Inspection ............................................15
Gas Piping ..............................................................................................15
Electrical Wiring......................................................................................16
Boiler Water Temperature Control....................................................17-18
Wiring Diagram.......................................................................................19
Multi Zoning ............................................................................................20
Water Piping ...........................................................................................20
Operating Instructions ............................................................................22
Gas Input Rate Adjustment ....................................................................23
Boiler Control..........................................................................................23
Sequence of Operation ..........................................................................25
Status of Indicator Lights (LED's) ..........................................................25
Safety Check .........................................................................................24
Care and Maintenance ...........................................................................26
General Troubleshooting Guide .......................................................27-29
Appendix A-E ...................................................................................29-31
WARNING
The venting system of this boiler is under positive pressure
when it is connected to the outdoors with 76 mm (3") diame-
ter pipe. Leakage from this system can be hazardous and if
not avoided can result in death or serious injury. In addition
to the recommendations within this manual and the User's
Information Manual, the venting system, from the blower to
the outdoor discharge, must be carefully checked annually
by a qualified service agency.
Address
Phone Number
VSPH
READ ALL OF THE FOLLOWING
The installation must conform to the requirements of the
authority having jurisdiction or, in the absence of such
requirements, to the National Fuel Gas Code, ANSI Z2231
latest edition or CSA B 149.1 latest edition
and propane
additional requirements in this Slant/Fin Instruction Book.
In addition, where required by the authority having juris dic -
tion, the installation must conform to American Society of
Mechanical Engineers Safety Code for Controls and Safety
Devices for Automatically Fired Boilers, No. CSD-1 or
B149.1 latest edition for natural gas and propane
is any conflict in the above requirements, then the more
stringent requirement will apply.
This boiler, gas piping and accessories must be
installed, connected, serviced and repaired by a
trained, experienced service technician, familiar with
all precautions required for gas-fired equipment and
licensed or otherwise qualified, in compliance with the
authority having jurisdiction.
Publication No. VSPH-41
This manual must be left
™
with owner and should be
hung on or adjacent to
the boiler for reference.
IMPORTANT
STATEMENTS BEFORE READING THE
INSTALLATION INSTRUCTIONS
WARNING
SEE "WARNING" ON PAGE 4
FOR LIQUEFIED PETROLEUM (L.P .)
PROPANE GAS-FIRED BOILERS
. The installation must also conform to the
WARNING
Boiler Model Number
Boiler Serial Number
Installation Date
Part No. 455035 Revision B
WARNINGS AND
for natural gas
CSA
. If there
Printed in Canada 0713
