Menards Master Force 252-8033 Operating Instructions Manual

20v lithium-ion

Hide thumbs

Table Of Contents

Quick Links

Download this manual

20V Lithium-Ion

Battery Pack

252-8033

For questions/comments, technical assistance or repair parts –

Please call toll free: 1-866-917-4374 (M – F 8am – 6pm EST)

OPERATOR'S MANUAL

CAUTION: To Reduce The Risk Of Injury, User Must

Read And Understand Operator's Manual. Save These

Instructions For Future Reference.

Table of Contents

Need help?

Do you have a question about the Master Force 252-8033 and is the answer not in the manual?

Questions and answers

Summary of Contents for Menards Master Force 252-8033

Page 1 20V Lithium-Ion Battery Pack 252-8033 For questions/comments, technical assistance or repair parts – Please call toll free: 1-866-917-4374 (M – F 8am – 6pm EST) OPERATOR’S MANUAL CAUTION: To Reduce The Risk Of Injury, User Must Read And Understand Operator’s Manual. Save These Instructions For Future Reference.
Page 2: Table Of Contents
TAbLE OF CONTENTS Safety Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 2 Safety Instructions .
Page 3: Safety Symbols
SAFETy SyMbOLS Some of these following symbols may be used on this tool . Please study them and learn their meaning . Proper interpretation of these symbols will allow you to operate the tool better and more safely . Symbol Designation / Explanation Name Volts...
Page 4: Safety Instructions
SAFETy INSTRUCTIONS The purpose of safety symbols is to attract your attention to possible dangers . The safety symbols and the explanations with them deserve your careful attention and understanding . The symbol warnings do not, by themselves, eliminate any danger . The instructions and warnings they give are no substitutes for proper accident prevention measures .
Page 5 SAFETy INSTRUCTIONS bATTERy TOOL USE WARNING: Read all safety AND CARE warnings and instructions! Failure follow warnings 1 . Recharge only with charger instructions may result in electric shock, fire specified by the manufacturer. A charger and/or serious injury . Save all warnings and that is suitable for one type of battery pack instructions for future reference .
Page 6 SAFETy INSTRUCTIONS 2 . know your power tool. Read the 10 . Have your battery pack serviced by a qualified repair person using only identical Instruction Manual carefully . Learn the tool’s replacement parts. This will ensure that the applications and limitations, as well as the specific potential hazards related to this safety of the battery pack is maintained .
Page 7: Overview/Specifications
OVERVIEW FIG. 1 Electrical contacts Battery-release button Power indicator button Power indicator SPECIFICATIONS Battery Type Lithium-Ion Battery Voltage 20V DC Battery weight 1lb . 9oz . (0 .72kg) Battery capacity 3 .0Ah Operating temperature -4°F(-20°C)—104°F (40°C ) Page 6...
Page 8: Assembly
ASSEMbLy CONTENTS WARNING: If any part is broken or missing, do not attempt to plug in the battery pack and instruction manual power cord or operate the tool until the broken or missing part is replaced. Failure to do so could result in possible serious injury.
Page 9: Operation
OPERATION POWER INDICATOR (FIG. 2) The LED lights will stay lit for approximately 4 seconds . NOTICE: The power indicator can be used This Lithium-Ion battery pack is equipped whether the battery is attached to or removed with a power indicator that displays the from tool .
Page 10 OPERATION COLD WEATHER OPERATION A fully discharged battery pack will charge about 60 minutes (with charger 252-8037) in the desired surrounding temperature . When the battery pack is very cold, it may 1 . Charge the battery pack with the correct “pulse”...
Page 11 OPERATION LED FUNCTIONS OF CHARGER (FIG. 4) FIG. 4 bATTERy GREEN LED INDICATOR ACTION PACk Fast charge will begin Hot/Cold when battery returns HI / LO TEMP. battery to between 50°F (10°C) and 104°F (40°C) DEFECTIVE Battery pack or Defective Flashing BATTERY charger is defective...
Page 12: Maintenance
MAINTENANCE bATTERy PACk REMOVAL AND WARNING: To ensure safety and PREPARATION FOR RECyCLING reliability, all repairs should be performed by a qualified service technician. To preserve natural resources, please WARNING: Always wear safety recycle or dispose of batteries properly . goggles or safety glasses with side This product contains Lithium-Ion batteries .
Page 13: Troubleshooting
TROUbLESHOOTING PRObLEM CAUSE SOLUTION The battery pack Attach the battery pack to Unconnected to charger isn’t charging the charger . Page 12...
Page 14 NOTES Page 13...
Page 15: Warranty
Guarantee . If you are not completely satisfied with your MASTERFORCE® brand power tool for any reason within ninety (90) days from the date of purchase, return the tool with your original receipt to any MENARDS® retail store, and we will provide you a refund – no questions asked .
