Sony PRS-350 Service Manual

SERVICE MANUAL
Ver. 1.0 2010.08
Note:
Be sure to keep your PC used for service and
checking of this unit always updated with the
latest version of your anti-virus software.
In case a virus affected unit was found during
service, contact your Service Headquarters.

SPECIFICATIONS

Model name
PRS-350
Power source
Built-in rechargeable battery: 3.7 V DC, 940 mA
USB communication: Hi-Speed USB (USB 2.0 compliant)
Battery life (continuous playback)
Maximum Battery: Approx. 10,000 continuous page turns
when reading only * 1
* 1 Measured using a text based content in ePub format and a
fully charged battery, consecutive page-turns at
approximately one second per page under the
recommended operating temperature. Actual battery life
may vary based on usage patterns and individual device.
User available capacity
Approx. 1.4 GB after initial setting
Depending on size of pre-loaded excerpts, available memory
capacity may vary.
Operating/charging temperature
41°F to 95°F (5°C to 35°C)
Dimensions (w/h/d)
Approx. 104.3 × 145 × 8.5 mm (4 1/8 × 5 3/4 × 11/32 inches)
Mass
Approx. 155 g (5.47 oz.)
Display:
127.0 mm (5") diagonal electrophoretic display
600 × 800 pixel, 0.127 × 0.127 pixel/mm
16-level gray scale
Design and specifications are subject to change
without notice.
9-889-952-01
Sony Corporation
2010H05-1
©
2010.08 Published by Sony Techno Create Corporation
PRS-350
The contents of each book pre-loaded on this product are copyrighted works,
edited with the cooperation of the publisher.
Copyright laws prohibit copying the data of this product or the contents of this
manual (illustrations, related documents, etc.) in whole or in part without the
permission of the copyright holder. Additionally, use of the data of this product or
the contents of this manual is not allowed without Sony's permission except for
personal use.
Besides individually enjoying, it is against the copyright law to use any picture you
recorded without prior consent of the copyright holder.
Sony, the Sony logo, "BBeB", "Reader", "Reader Pocket Edition" and their logos are
either trademarks or registered trademarks of Sony Corporation.
Bitstream is a registered trademark, and Dutch, Font Fusion, and Swiss are
trademarks, of Bitstream Inc.
Microsoft, Windows, Windows Vista and Windows Media are trademarks or
registered trademarks of Microsoft Corporation in the United States and / or other
countries.
Macintosh and Mac OS are trademarks of Apple Inc., registered in the U.S. and
other countries.
This PRS-350 contains Adobe® Reader® Mobile software under license from Adobe
Systems Incorporated, Copyright © 1995-2009 Adobe Systems Incorporated. All
rights reserved. Adobe and Reader are trademarks of Adobe Systems Incorporated.
This product includes software developed by the OpenSSL Project for use in the
OpenSSL Toolkit. (http://www.openssl.org/) Copyright© 1998-2008 The OpenSSL
Project. All rights reserved. This product includes cryptographic software written
by Eric Young (eay@cryptsoft.com). This product includes software written by Tim
Hudson (tjh@cryptsoft.com). For details on OpenSSL License, refer to "END USER
LICENSE AGREEMENT" in the book list on the Reader.
All other system names and product names appearing in this document are the
registered trademarks or trademarks of their respective owners. Further, the
trademark ™ and registered trademark ® symbols are not indicated throughout this
document.
Program ©2010 Sony Corporation
Documentation ©2010 Sony Corporation
FLEXIBLE CIRCUIT BOARD REPAIRING
• Keep the temperature of soldering iron around 270 °C during
repairing.
• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
• Be careful not to apply force on the conductor when soldering
or unsoldering.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
DIGITAL BOOK READER
US Model
Canadian Model
AEP Model
UK Model
