LCD TV SERVICE MANUAL CHASSIS : AL-04CA MODEL : 32LX3DC-UA/32LX3DCS-UA CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
SAFETY PRECAUTIONS IMPORTANT SAFETY NOTICE Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent Shock, Fire, or other Hazards.
SERVICING PRECAUTIONS CAUTION: Before servicing receivers covered by this service unit under test. manual and its supplements and addenda, read and follow the 2. After removing an electrical assembly equipped with ES SAFETY PRECAUTIONS on page 3 of this publication. devices, place the assembly on a conductive surface such as NOTE: If unforeseen circumstances create conflict between the aluminum foil, to prevent electrostatic charge buildup or...
Page 5
IC Remove/Replacement Some chassis circuit boards have slotted holes (oblong) through Circuit Board Foil Repair which the IC leads are inserted and then bent flat against the Excessive heat applied to the copper foil of any printed circuit circuit foil. When holes are the slotted type, the following technique board will weaken the adhesive that bonds the foil to the circuit should be used to remove and replace the IC.
Page 7
Set Password New/Confirm Block Ch. Movie Rating G/PG/PG-13/R/NC-17/X TV Rating-Children Age/Fantasy Violence TV Rating-General Age/Dialogue/Language/Sex/Violence Aux.Block Video1/Video2/Component1/Component2/RGB1/RGB2/DVI Etc. Comb Filter 3D Comb(main), 4H Comb(sub) 3D comb for main display, 4H comb for sub display Remocon LG code - 7 -...
Page 10
7. External Interface - AV Input Item Unit Remark AV Video Out Level 0.85 1.15 AV Video Sync Out Level 0.24 0.29 0.32 AV Burst Out Level 0.14 0.28 0.35 AV Video Out Frequency Charactristic AV Video Out S/N 40.0 AV Audio In S/N, L/R 43.0 AV Audio In Frequency Response, Low...
Page 11
9. Electro Optical Characteristic Specifications Item Unit Remark Contrast Ratio It measured at center point Surface Luminance, White Cd/m Full white Luminance Variation Response Time Tr (Rising time) msec Color coordinate 0.640 Full Pattern 0.343 GREEN 0.275 -0.03 0.605 +0.03 BLUE 0.145 0.065...
Page 12
11. Factory default condition Item Condition Remark Input Mode N.A.(Specified by D-Box) Volume Level N.A.(Specified by D-Box) Mute Aspect Ratio 16:9(Specified by D-Box) Picture Ez Picture Normal User Control Contrast Brightness Colour Sharpness Tint Color Temperature Medium Sound EZ Sound Normal Audio Language Empty Ch map...
ADJUSTMENT INSTRUCTION 1. Application Object 3. Total Adjustment This instruction is for the application to the LCD TV. 3.1 EDID (Extended Display Identification Data ) / DDC (Display Data Channel) download 2. Designation. 3.1.1 Summary 2.1 As this chassis is a non-charging type of chassis for : This function was created by VESA and is intended to insulation of the power supply part, it may not use an realize "Plug and Play"...
Page 14
3.2.2 Adjustment Method 3.3 Color adjustment of main/subsidiary part Color adjustment of main/subsidiary part is intended to A) Enter the 100% Vertical Color Bar Pattern reduce color difference of the main/subsidiary part in the (TVBAR_100) of the 720P Mode supported for entry PIP/POP/SPLIT Screen.
SVC REMOCON FUNTION REAMARK To turn the TV on or off POWER To turn the TV on automatically if the power is supplied to the TV. (Use the POWER ON POWER key to deactivate): It should be deactivated when delivered. To activate the mute function.
TROUBLESHOOTING No power Power supply Check Connector connection connector connection status. Fail Pass Connection Stand voltage check: of power supply part : D-board P810 '+5V-STDBY Check wiring status of the 13-pin Fail connector Pass Pass Replace Power_board Connection Stand voltage check: of power supply part : A-board P818 #5Pin 5V Check wiring status of the 15-pin...
Page 17
No Raster Stand by voltage : Check No Power Replace Power board D_board P810 +12V-P (Go to Power) Pass Fail Pass Stand by voltage : Check No Power D_board IC480 Replace IC480/Q411 (Go to Power) Pass Fail #5, #6, #7, #8 12V Pass Replace D_board Fail...
Page 18
No Sound Power board 15Pin Check Sound supply: Connector Replace Connector A_board P817 #1, #2 18V Fail Fail check Pass Pass Replace Power Board Speaker output check : Replace A_Board Is there waveform of P601 #1? Fail Pass Replace Speaker - 18 -...
BLOCK DIAGRAM DESCRIPTION(MAIN) ATSC/NTSC tuner (TDVB-001P) can receive both terrestrial analog and terrestrial digital signals. But a NTSC tuner (6700NFNS06C) can receive terrestrial analog only. Therefore if you run two displays at thesame time, it is not possible to see two digital channels. A/V SW (CXA2069) is the IC that takes external input terminal signals and broadcast signals from the tuners and handles them selectively.
REPLACEMENT PARTS LIST For Capacitor & Resistors, the CC, CX, CK, CN, CH : Ceramic RD : Carbon Film charactors at 2nd and 3rd digit in the CQ : Polyestor RS : Metal Oxide Film P/No. means as follows; CE : Electrolytic RN : Metal Film CF : Fixed Film RH : CHIP, Metal Glazed(Chip)
