WATER BOILERS
WKI
WKT
WKT-D
TYPE: 3, 10, 10HA, 10VA, 18, 20/3, 20/6, 25HA, 25VA, 40, 60, 80
Accessories
Tap and swiwel arm left
Tap and swiwel arm right
Tap and swiwel two arms
Installation and Operation Manual
S/N:
Rev.: 2.0
