- Page 1 Surix IP Entrix 1° Edición Made in Argentina...
- Page 2 IMPORTANT!: This product´s warranty is 1 year from the reception of this Warranty Register. We will not accept any complaints for no-registered products. FIRST NAME AND LAST NAME Name of holder Address where the IP Entrix is installed STREET AND NUMBER Company Particular...
-
Page 3: Table Of Contents
(they are read-only values). Busy (In conversation or call) If at that moment the IP Entrix was making a call (or receiving one), this value will be On. If it was not, it will be Off. Registered in IP PBX central It shows if it is registered in the IP PBX central whose data is in the Communication Parameters menu. -
Page 4: Introduction
General Description The SURiX IP Entrix is an intelligent IP Door Phone, that is connected as an IP intern of an IP PBX. There are models for buildings (or gated communities) of diverse sizes: 25, 50, 75, 100, 150, 200 and 250 apartments/houses. -
Page 5: Technical Features
Exit to relays: 20 A/125VAC - 20 A/14 VDC Intern number of this equipment (IP Entrix) Intern number the IP Entrix will have for the IP PBX central (if it is connected to an IP central). IP PBX IP Address Verify that the IP address of the IP Entrix and the IP PBX are in the same range (accessible). - Page 6 Programming The IP Entrix has an internal web server that responds in port 8085. The setting of the configurable parameters of the IP Entrix is done by a web browser (Internet Explorer, Firefox, etc.) At the initial start-up, the IP Entrix has the IP adrress: 10.0.0.100. To start the setting, browse: http://10.0.0.100:8085...
- Page 7 IP Entrix - v1 In the submenu Key Programming it can be seen the telephone keyboard table, which includes The IP Entrix should respond with this screen to entry the programming key: the keys * (asterisk) and # (pound). The Online Guide button is available in all the menus and (with Internet access) by clicking it, another window will open, accessing to this guide in pdf.
-
Page 8: Main Menu
When in programming, the Main Menu screen is shown: In the submenu Interns by Number the numeration table that the user marks and its correspondence with the IP PBX interns the IP Entrix calls. NOTE: See in this example that the user can mark 1 or 10. - Page 9 Enter or something similar. To recognize between apartments (house, ground lot, or intern) 1 concept. and 15, the IP Entrix waits some time after every dialed digit. After that time, it automatically Particularly, the Front Functionality element to be programmed defines the door phone validates the data (as if the user would have pressed Enter).
-
Page 10: Call By Building-Floor-Apartment
For the operation to be intuitive, the visitor user is not asked to validate the data with Enter or something similar. Therefore, to recognize between floor 1 and floor 15, the IP Entrix waits some time after every dialed digit. After that time, it validates the data automatically (as if the... -
Page 11: Welcome Text
BS"D IP Entrix - v1 In a case like this, you should modify the Floor and Apartment column, so that it reflects the Number of buildings in the property Maximum number of floors reality. The table, then, would be as shown below (assuming that all apartments from 101... - Page 12 IP Entrix will be reached before the table is completed. Supposing a building with 24 apartments that has 4 apartments per floor on floors 1 to 4, and 2 apartments per floor on floors 5 to 8.
