Owner & Operator's Manual
Model No: Voltage:
9490950
115V 50/60Hz
9490952
220V 50/60Hz
DESCRIPTION
Safety...................................................................................................2
Features...............................................................................................3
Furnace Description............................................................................4
Installation............................................................................................5
Control Description..............................................................................6
Setup & Maintenance..........................................................................7
Operating Instructions.........................................................................8
Specifications.......................................................................................9
Trouble Shooting..................................................................................10
Accessories.........................................................................................11
Product Service...................................................................................11
Warranty..............................................................................................Back
1
PAGE
Advertisement
Table of Contents
Related Manuals for DENTSPLY Miniglaze/2
Summary of Contents for DENTSPLY Miniglaze/2
-
Page 1: Table Of Contents
Owner & Operator's Manual Model No: Voltage: 9490950 115V 50/60Hz 9490952 220V 50/60Hz DESCRIPTION PAGE Safety....................2 Features....................3 Furnace Description................4 Installation....................5 Control Description................6 Setup & Maintenance................7 Operating Instructions.................8 Specifications..................9 Trouble Shooting..................10 Accessories..................11 Product Service...................11 Warranty....................Back... -
Page 2: Safety
OSHA AND CALIFORNIA PROPOSITION 65: MUFFLE DUST EXPOSURE In keeping with the policy of DENTSPLY Ceramco to build safe products, comply with all National and State statutes and keep you, the valued customer informed; the services of a Certified Industrial Hygienist firm were employed to test and evaluate the lab operator’s exposure to respirable refractory ceramic fiber (RCF) and... -
Page 3: Features
FEATURES: • 1100°C (2010°F) Max. Temperature: 200°C (400°F) Min. Temperature • Adjustable Heat Rate: 10-100°C/M (18-180°F/M) • Small Foot Print: 6-1/4W x 6D x 11-1/2H • Visual /Audio Indicator: Lights or Sounds When At Temperature • Easy Temperature Calibration • Fast Cooling Fiber Muffle... -
Page 4: Furnace Description
FURNACE DESCRIPTION Clear Vue Door Muffle Shelf Muffle Power Light Tone/Light MINIGLAZE/2 ® Switch On/Off Temperature Rise Control Dial Switch TONE RATE Calibration Screw CALIBRATION LIGHT Indicating Light Temperature Indicator Temperature Control Dial Miniglaze/2 Figure 1... -
Page 5: Installation
UNPACKING • Carefully unpack and remove the Miniglaze/2 from its shipping carton. • Save the carton and other packing material for future use in transporting the Miniglaze/2. • Shipping damage should be reported to the carrier as soon as detected. -
Page 6: Control Description
It will blink intermittently during temperature rise due to the automatic temperature control. • Temperature Rise Control Dial: (5) The Miniglaze/2 is designed to provide an approximate straight line temperature rise. Complete counterclockwise adjustment ("S", Slow setting) will give an approximate 10°C (18°F) per minute temperature rise. -
Page 7: Setup & Maintenance
SETUP & MAINTENANCE CALIBRATION: Your new Miniglaze/2 has been factory calibrated and should not need any adjustment. After long term use of this furnace there may be some change in the temperature control. Periodic calibration is necessary to mini- mize the effects of these changes. -
Page 8: Operating Instructions
OPERATING INSTRUCTIONS • Turn the furnace on • Insert muffle door • Turn temperature control dial to 650°C (1200°F) • Turn the rate control knob to the midpoint between "S" and "F" • After 15 minutes, adjust the temperature control knob to 1000°C (1832°F) and the rate to maximum ("F"). •... -
Page 9: Specifications
SPECIFICATION: Width: 16cm (6-1/4 in.) Depth: 15cm (6 in.) Height: 29cm (11-1/2 in.) Weight: 2.7kg (6 lbs.) Operating Voltage: 115V ac (100-120V), 50-60Hz, 5.0A 230V ac (200-250V), 50-60Hz, 2.1A Power Requirements: 720 watts Temperature Display Accuracy: ± 10°C @ 650°C - 1000°C ±... -
Page 10: Trouble Shooting
Replace muffle P/N: 9490567 (115V) P/N: 9490585 (230V) 5. Wiring problem 6. TC shorted. Muffle heats continually 1. Faulty triac Return unit to DENTSPLY with muffle temperature Ceramco greater than the set temperature 2. Circuit board not Replace circuit board... -
Page 11: Accessories
9982561 PRODUCT SERVICE Two methods of product service are available for the MINIGLAZE/2. The first is telephone assistance available at the numbers listed below. The second is to return the furnace for servicing using the instructions below. BEFORE RETURNING THE FURNACE, DO THE FOLLOWING: •... -
Page 12: Warranty
DENTSPLY Ceramco warrants its products to be free from defects in material and workmanship for a period of two years from the date of sale. The warranty period for the muffle, a component of DENTSPLY Ceramco's Miniglaze/2 Porcelain Staining and Glazing Furnace, shall be 2 years from date of sale.
