Summary of Contents for Hongda USA Shepherd 220A
- Page 1 Shepherd 220A/AT Installation Manual Rev 1.1 visit www.ca-tec.com DL220A Installation Manual V1.1 © ©Copyright 2004.
-
Page 2: Table Of Contents
Table of Contents 1. Product and Accessories ……………………………………………………….2 1.1 Parts List………………………………………………………………………2 1.2 Parts Composition……………………………………………………………3 2. Installation………………………………………………………………………….5 2.1 Preparation before Installation………………………………………………5 2.2 Drill Holes……………………………………………………………………...6 2.3 Adjust Latch’s Backset……………………………………………………..6 3 Install Latch and Strikes ………………………………………………………….8 3.1 Install Latch …………………………………………………………………..8 3.2 Install Strike…………………………………………………………………..9 4 Install the Lock Units……………………………………………………………..10 5 Check and Adjust after Installation…………………………………………….11 DL220A Installation Manual V1.1... -
Page 3: Product And Accessories
1. Product and Accessories 1.1 Parts List After open the package, please check the product and its accessories. If they are missing or damaged, please contact your dealer for replacement. Indoor unit Outdoor unit Emergent keys Latch Latch strike Strike lining box Pinch Pinch Wood screw... -
Page 4: Parts Composition
The Manuals Cutout template sheet 1.2 Parts Composition DL220A Installation Manual V1.1 © ©Copyright 2004. Hongda USA Inc. - Page 5 1. Scanner cover 10. Latch 2. Indicator LED 11. No Disturb switch 3. Fingerprint scanning window 12. Battery compartment 4. Front Panel 13. Battery compartment cover 5. Display 14. Battery compartment screw 6. Keypad 15. Indoor lever 7. Outside lever 16.
-
Page 6: Installation
US market. If there is only one hole or no hole in the door, drill 2 1/8” face holes and 1’’ edge bores using the door lock installation kit from such as BLACK & DECKER Inc. DL220A Installation Manual V1.1 © ©Copyright 2004. Hongda USA Inc. -
Page 7: Drill Holes
2.2 Drill Holes (1) Paste the provided cutout template on the door as the figure. Mark 1” holes at center of door edge and make 2” holes at the surface of the door (the offset is 2 3/8” or 2 3/4” from door edge to the center of the 2” hole). (2) Drill two 1”... - Page 8 The clip of regulator pin Regulator pin Pull regulator pin to the right edge. Pull The right edge of adjust hole backset been adjusted to 2 3/4” position. Screw-post hole Make sure of the regulator pin at correct angle as the left figure.
-
Page 9: Install Latch And Strikes
3 Install Latch and Strike 3.1 Install Latch Insert the lock bolt into the hole, mark the Dig a support notch 1/8” in depth. The frame lines of foil board. The frame lines notch edge lines should be parallel with should be parallel with the door edge. -
Page 10: Install Strike
3.2 Install Strike Dig a square concave according to the Close the door; use pencil to mark strike strike size at the marked location in the hole in the doorjamb from face hole. doorjamb. Draw strike plate line and screw holes Install strikes, tighten the screws. -
Page 11: Install The Lock Units
4 Install the Lock Units (1) Insert two screw posts on the outdoor unit into two regulator holes in the latch. Pass cable through upper hole of the door. Let outdoor unit remain close on the door surface. (2) Pass the square axle through the square hole of regulator pin of the latch and the outside lever connecting with the outdoor unit. -
Page 12: Check And Adjust After Installation
battery compartment on the upper indoor unit. (8) Fasten two M4×48 pinch screws (longer ones) through the two holes on the lower indoor unit near the lever. (9) Install 6 pieces of AA batteries. Fasten battery compartment cover with a M3 screw.
