Embroidery mode - edit
In Embroidery edit you can adjust, combine, save, delete and restore designs. You do not need to have the
embroidery unit connected to your machine to edit your designs. The loaded design(s) are shown in the
embroidery field (1).
Embroidery edit - overview
1. Embroidery field
2. Zoom Options
3. Multi-select
4. Select/deselect design
5. Arrows
6. Delete
7. Duplicate
8. Total number of stitches
9. Mirroring side to side
10. Mirroring end to end
11. Move design into hoop
12. Undo
13. Redo
14. Touch function - move
15. Touch function - rotate
16. Touch function - scale
17. Touch function - pan
18. Wheel
19. Wheel center icon
20. Save to Personal designs
21. More options
22. Select hoop
23. Thread color edit
24. Embroidery stitch editor
25. Sequencing
26. Stitch Creator
27. Selection menu
28. Quick help
Note: All symbols and options will not be shown at
the same time.
Quick help (28)
Use Quick help to receive instant information about
any icon or part of the screen. Touch the Quick help
icon (28) and then the icon or the part of the screen
you want information about.
8:2
1
2
9 10 11
12
3
4
5
6
7
8
14 15
18
13 16 17
27
20
21
22
23
24
25
26
19
28
