Page 1 DVR Server Manual Netvision DVR system USER’ S GUIDE China Chongqing Netvision Technology Co., Ltd TEL: (86)23—68697255 FAX :(86)23—68639816 www.jstdvr.com www.Netvisiondvr.com...
Page 2: Table Of Contents
DVR Server Manual Contents Chapter1 Start up and Main Interface......12 1.1 Preparation & Uninstallation ............. 12 1.1.1 Preparation ..................12 1.1.2 Uninstallation ................. 13 1.1.3 NV Series IPC Scan ................ 14 1.2 Disk Management..............15 1.2.1 Create Package ................17 1.2.2 Manage Package................
Page 3 DVR Server Manual Chapter2 Local Setup ........... 50 2.1 System Setup ................50 2.1.1 System Setup..................50 2.1.2 Network Setup ................. 52 2.1.3 Boot Setup ..................54 2.2 Camera Setup ................55 2.2.1 Camera Setup.................. 55 2.2.2 Group Setup ..................59 2.3 Sensor Setup ................
Page 4 DVR Server Manual 2.7.1 User Information................71 2.7.2 User Right Setup ................72 Chapter3 IP Camera Setup ........... 74 3.1 Functional Buttons ..............76 3.2 Server Setup ................77 3.3 Channel Setup................78 3.4 PTZ Control................80 3.5 Sensor Setup ................82 3.6 Alarm Setup................
Page 5 DVR Server Manual 4.5.3 View Backup File ................95 4.5.4 Burn Video File to DVD/CD ............96 4.6 Search Captured Pictures............98 4.7 POS Playback ................99 4.8 ACU Playback ................. 101 4.9 ICON Playback................ 103 Chapter5 IE Client ............105 5.1 Functions of IE Client .............
Page 6 DVR Server Manual 6.1 Recommended Mobile Phone Requirements......110 6.2 Download Software ..............111 6.3 Install and Connect ..............111 6.3.1 Installation ..................111 6.3.2 Connection ..................112 6.4 Login Interface ................ 112 6.5 Camera List ................112 6.6 PTZ Control................113 Appendix A: Fast Key Reference.......
Page 7 Introductions Thank you for purchasing Netvision DVR System. This operation manual is to introduce how to set DVR system and explain each function for you to use the system effectively and stably. Users should read this manual thoroughly before you install/utilize the...
Page 8: System Features
DVR Server Manual System Features -Support Backup manually or by schedule. Manual backup data can be played by TV, DVD or windows media player directly without plugins. Please refer to Backup Manual for details. -Support Android phones. -Support 3G functions for DG series IP cameras. -Support plug and play disks.
Page 9 DVR Server Manual -Backup & burn CD directly -Remote talking between server and client or server and server -Support the following eight kinds of resolution: 1024*768 pixels, 1280*768 pixels, 1280*1024 pixels, 1366*768 pixels, 1440*900 pixels, 1600*900 pixels, 1680*1050 pixels and 1920*1080 pixels.
Page 10: Important Information
DVR Server Manual Important Information: For optimal performance of your system, it is important to follow these recommendations. We recommend that you divide your hard disk into two partitions (E.g. C and D) at least. The first partition is used to install Windows OS and system software, the other for storing record files.
Page 11: Recommended System Requirements
DVR Server Manual Recommended System Requirements Chipset: Intel 875PE, 915P, 945P, 965P Motherboard: Intel: D915/945PCY, D865PERL Asus: P4P800SE, P5P800 MSI: 865PE Neo2-F, 915/925/945; Gigabit: GA-865GME, GA-945PL-G etc Video Card: ATI Rodeon 9250 128MB, ATI Radeon 9550 128MB, ATI X500, X550, X700 etc; Processor: Intel Pentium 4 2.4GHz or better Memory: 512MB minimum This is the lowest requirements to run the system.
Page 12: Chapter1 Start Up And Main Interface
Chapter1 Start up and Main Interface 1.1 Preparation & Uninstallation 1.1.1 Preparation Before you run DVR system, please be sure following issues: All connectors are firmly connected; Install the driver of compression cards correctly. For detailed information, please refer to Driver Installation Manual;...
Page 13: Uninstallation
DVR Server Manual 2. Adjust UAC settings to "Never notify", shown in the below pictures: To 64 bit OS, you have to download and install two patches: KB978637 and KB976264. You should download them from MSDNAA manually. They can’t be installed automatically when system updates. 1.1.2 Uninstallation When you want to change this version to another one, you should uninstall it.
Page 14: Nv Series Ipc Scan
DVR Server Manual 1.1.3 NV Series IPC Scan Click Start All programs DVR Server Insatll WinPcap_4_0_2 to install the NV series IPC scan tool. Click Start All programs DVR Server NV Series IPC Scan to scan NV series IP cameras connected in the LAN. Device type, IP address, Port number, Device Serial No., mask, mac, channels, software version, DSP version and start time will be displayed in the search tool.
Page 15: Disk Management
DVR Server Manual Note: To DG series IPC scan, please refer to Add DG Series IP Device for details. 1.2 Disk Management After installed DVR Server, you should assign space for recording, otherwise, software can’t record. Actually, system will run disk management automatically after you installed DVR Server.
Page 16 DVR Server Manual Disk manager under installed folder Main interface of disk manager 【Disk Drives】:Display the disk and its format. 【Total Size(M)】:Display the total size of the disk. 【Free Space(M)】:Display the total free space of the disk, which is the maximum space can be assigned for recording.
Page 17: Create Package
DVR Server Manual been assigned for recording before. 【Residual Data Package】:Display the number of data package that can be assigned for recording. 【】【】 Residual Data Package Free Space(M) /256 【New Data Package】:Select the number of the data package that user want to create for recording.
Page 18: Manage Package
DVR Server Manual software will not use it (default: 【New Data Package】= 0) unless you change Since windows will pop up information to warn when the disk has low space, by default, our software will leave 3 packages (about 256*3=768 MB) for disks (except C and D) to avoid that information.
Page 19: Main Interface
DVR Server Manual Main interface of DVR Server Note: When user runs the DVR Server without a valid license for compression cards or IP products, system will pop up a dialog box to inform you. System will work under trial version; if you want to use full version, please contact your supplier or us directly to get it.
Page 20: Screen Menu
DVR Server Manual Recording status: -- The system is recording continuously; -- The system is recording manually; -- The system is recording in motion detection alarm; -- The system is recording in event alarm. 1.4.2 Screen Menu After user enable Keyboard Shortcut, you can press TAB key or Page Down (select next camera window) and Page UP (select previous camera...
Page 21 DVR Server Manual system will play back video data of current camera in current window according to your selection (E.g.: you select 1min, system will play back previous 1 minute video data of current camera in current window). Also, you can play back video data of one current live camera in a window that is not used by any cameras (always black background with no “Video Loss”...
Page 22 DVR Server Manual While instant playback is in processing, if you want to play it again, you can select Review playback function. You can press Space key to switch the play/pause status. In pause status, you can press key → or ← to play next or previous frame.
Page 23 DVR Server Manual Also, you can view the disk record status of your PC-DVR remotely via NVR. Please refert to NVR user manual for details. 5. Record Time Calculate Click “Record Time Calculate” to calculate the record time of your cameras.
Page 24 DVR Server Manual 6. OSD Adjustment Single-Right-Click video image area in main interface and select “OSD Adjustment” to adjust the position of OSD (IP Camera does not have this function. You can set the OSD position in IP Camera Setup remotely).
Page 25: Ip Camera Setup
DVR Server Manual OSD includes time and channel name. In this screen you can press time or channel name and drag them to where you want directly, after that you can press button to save and press button to resume time and channel name to default position.
Page 26 DVR Server Manual mouse-left in the image, it will zoom out as bellow: If you want to display the normal image, you should select IP Video Restore function. Note: The 3 functions as above are only suitable for the IP camera. 11.
Page 27: Interface Description
DVR Server Manual 1.4.3 Interface Description 1. Partition Mode Press button to set the window’s partition mode of the main screen. There are many types of partitions; the available partition is determined by the total channels of cards, you can select the suitable partition according to the number of video inputs.
Page 28: Local Setup
DVR Server Manual Press button to save a still image of a selected camera to local hard disk for reviewing or printing. It will ask you for file name and save path when you use to capture pictures for the first time. Next time, it will save to the previous path directly.
Page 29: Motion Setup
DVR Server Manual 10. Motion Setup Set the functions of motion detection areas and add/delete mask and so on. It will be described in details in Motion Detection Area & Cover Setup. 11. System Log Press button to view all actions of recording as well as operations. There are three types of logs: System log, Playback log and Network Access log.
Page 30: System Lock
Default User ID is “admin”, no password. Note: If the DVR system is not configured as User Manage Mode, the lock button will be unusable and allow any client’s access (even in client program, user name and password will be useless).
Page 31: System Menu
DVR Server Manual After clicking this button, the dialog as below will be displayed. Click “OK” to quit DVR system. 1.4.4 System Menu 1. Backup System Parameters Select this function to export system configurations. 2. Import System Parameters Select this function to import system configurations.
Page 32 10. DVR Board Work Mode Setup Each DVR system supports maximum 8 PCs 400XHC (total channel is equal to 64) series board, so user can set its work mode via this GUI. The new work mode of DVR board will take effect after rebooting DVR Server software.
Page 33 12. Add/Del IP Camera Press this bar to add IP devices to DVR system. For resource limitation, you can add max 64 IP cameras, including DVS and EM DVR. Now our software supports the following types of IP products: NV Series IP/EMDVR,...
Page 34 DVR Server Manual MD series decode card work mode: Select D1 work mode or CIF work mode to decode IP cameras when there are MD cards. Only NV series normal IP devices and NV 40 series cards can be decoded. Megapixel cameras and NV 42 series cards can’t be decoded.
Page 35 DVR Server Manual (1). Add IP Device I. Add IP Device (except DG series) Press button to add an IP Camera device: You can add the mega pixel IP camera in the system. If you want to use the Record sub stream function in the IP device, you should select the data stream type Double Stream.
Page 36 DVR Server Manual 【If use DNS to get IP】Select whether use DNS to get IP or not, if the server end is the dynamic IP address, users need use DNS to get the server’s 【DNS Server IP】Set IP address of DNS server host. 【DNS Server Port】...
Page 37 DVR system. When you finished adding IP Camera to DVR system, it will show the status of that camera, including Sever name, IP Address, connect port, sequence number for IP Camera, connect status and register information.
Page 38 DVR Server Manual selecting Playback to TV Monitor function. Note: Each NV4002MD card can decode 2 channels D1 or 4channels CIF. Each NV4004MD card can decode 4 channels D1 or 8 channels CIF. When you select the work mode, system will send out corresponding channels of IP camera from the first IP camera.
Page 39: Motion Detection Area & Cover Setup
DVR Server Manual POS Filter Check the box in front of the rectangle to enable POS filter. You can type any word according to the POS text to display the lines you want. For example, if you want to display all the lines less than 5$, then you can type “<5$” as the filter.
Page 40 DVR Server Manual alarm. When the sound is detected over the value you selected, then the software will take it as a motion alarm. (2). Motion Link to PTZ You can press “Link to PTZ” button to activate motion link PTZ preset function.
Page 41 DVR Server Manual First, you should select the PTZ camera and set the preset. Then, you should select the detected camera, which is showed as . Next, select the detected area named Zone01 like the green frame. If you select the number is 64, the total of the zone is 64, you can detect the number of areas is 64.
Page 42: Network Panel
You can set several cover areas. Press this button again to finish adding. II. Delete Mask Press button to delete all cover areas. 1.4.6 Network Panel This panel displays the network configuration of DVR system.
Page 43: Ptz Control Panel
DVR Server Manual 1.4.7 PTZ Control Panel In DVR system, there are three ways to operate PTZ: a. Panel operate; b. Operate in video area directly; c. Keyboard operates. 1. PTZ Speed Press and drag the slider bar to adjust the speed of PTZ.
Page 44 DVR Server Manual 6. Iris + / Iris – Overrides the PTZ cameras auto-iris and brighten or darken the image. 7. Speed Dome For local board cards, press button to operate the speed dome, including Preset Setup, Preset Call and Preset Tour as below: For IP camera, the preset should be set remotely in IP Camera Setup.
Page 45 DVR Server Manual I. Add/Delete Preset In this section you can set the preset name with its sequence number, then you can press button to add/delete a preset, when you want to modify the preset you can press button to confirm your modification. For different cameras, there are different commands to open and set, so you can choose the call mode in the drop-list for different cameras.
Page 46: Color And Audio Adjustment
DVR Server Manual when you call preset 95, you can see: When you enter the menu, you can control it by , using up, down, left and right buttons. Press IRIS- to enter the sub menu. When you use up or down to move to “exit”, press IRIS- to exit the menu.
Page 47: Matrix & Display
DVR Server Manual ① Press the first button and drag it to adjust the brightness of the image that you selected, and you can resume its default value by pressing ②Press the second button and drag it to adjust the contrast of the image that you selected and you can resume its default value by pressing ③Press the third button and drag it to adjust the hue of the image that you selected, and you can resume its default value by pressing...
Page 48 DVR Server Manual 1. DI Control Press number button to check sensor all time forcibly even though user didn’t set check sensor in Sensor Setup. The channel of DI and DO is determined by the setup of DI/DO device you set in System Setup.
Page 49 DVR Server Manual status of DO has two types: Output channel 2 is close. Output channel 1 is open. When there is no alarm triggered out, user can press the number button to output alarm forcibly and the button will show it with green. Press it again, the output will be closed.
Page 50: Chapter2 Local Setup
DVR Server Manual Chapter2 Local Setup The DVR System Configuration and Setup include 7 types of configurations: System Setup Camera Setup Sensor Setup PTZ & Linkage Setup Email & SMS Setup Matrix & Display Setup User Setup 2.1 System Setup 2.1.1 System Setup...
Page 51 POS manual. 【Date Format】 Select the way to display date. It decides the date display mode of DVR system, including the information panel on the main screen, the date panel of the playback window and OSD date in video.
Page 52: Network Setup
Dual Monitor User Manual. 2.1.2 Network Setup 【Remote Connection】Select using network or not. If select “disable”, it will not permit any client connect this DVR system. 【Remote Connect Port】Select remote connection port for Clients. 【Remote buffer Priority】 Select among Smooth, Normal and Realtime.
Page 53 DVR Server Manual select “disable”, it will not permit any PDA devices to connect with this DVR system. 【PDA Connect Port】Select remote connection port for PDA device. 【Web Server Port】The IE Client connecting port. Default value is 80 for http access; but for some windows XP edition, it shields port 80. In this case, user should modify this port to other port, such as 1280.
Page 54: Boot Setup
DVR Server Manual 1. If your DVR is dynamic IP, you should set your DVR system as below: 2. DNS server will get domain name and current IP of your DVR, NVR Client can connect to DVR server through this domain name.
Page 55: Camera Setup
DVR Server Manual 2.2 Camera Setup 2.2.1 Camera Setup 【Selected Camera】To set the parameters for a camera, select the camera from the drop-down list. The cameras you can select are only the cameras of the local board cards, IP Cameras are not included. For IP Camera, you should set it remotely in IP Camera Setup.
Page 56 DVR Server Manual Because of the width limitation, you’d better input the characters within eight. If you input the full characters (20 characters) in the blank, you should select the characters and delete them; Because of the properties limitation, you‘d better not use “\” “:” “/” in camera description.
Page 57 DVR Server Manual Note: If you are not familiar with those features, we advise you not to revise them. Recommend setup: For CIF: Image I frame P frame B frame Max bps Best 900000 Good 750000 Medium 600000 450000 Lowest 300000 For DCIF: Maxbps = (Maxbps/3)*5...
Page 58 DVR Server Manual Recommended resolution configuration for different channels: Board Recommended Remark Channels Resolution Continuous recording recommended DCIF DCIF DCIF 4CIF Less or Equal DCIF to16 【OSD Date】Select whether display the OSD date on the screen or not. When you select “Not”, the date will not display on the screen of corresponding channel.
Page 59: Group Setup
DVR Server Manual will delete the record data from the earliest date. 【OSD Contrast】Set OSD displaying brightness & position. The “auto” item in OSD Contrast’s drop-down list will make OSD suit the background’s color automatically. 【Copy Setup to】Set other cameras with the same setup. Note: 1) When there are no video in some windows, an alarm will appear (beep to tell you some video information is missing).
Page 60 Cameras include local board cards and IP modules. 【Pre-Event Record】Select the start time of record when there is an alarm. When DVR system is in Motion Detect mode or Sensor Detect mode, it can record video before the alarm is trigged.
Page 61: Sensor Setup
4. Motion or Sensor Record (yellow): Combine with above 2 and 3 function (e.g. Wednesday); 5. Normal & Motion Record (light blue): DVR system records in motion detection record when it detects moving object and in normal record when there is no motion (e.g. Thursday);...
Page 62: Group Setup
【Trigger Output Relays】Add alarm devices (alarm out port) to this group such as siren, light. All connecting devices will send alarm message when there is an alarm. Schedule Setup (Example for below figure) 1. Check Alarm (Red): DVR System responds with sensor during this...
Page 63: Ptz & Linkage Setup
DVR Server Manual time. (00:30 to 12:00 from Sun. to Sat.); 2. Not Check (gray): DVR System responds with no sensor alarm during this time. Note: If you set a camera in several groups, only the last setup is available.
Page 64: Motion Detection Relay
DVR Server Manual 【PTZ Protocol】Select the PTZ protocol for the PTZ camera. 【PTZ Address】Set the camera ID number of the PTZ camera being controlled. Note: The PTZ camera has a dipswitch to set the PTZ address. The PTZ camera ID number must be matched with the number of this dipswitch. 【PTZ Baud rate】Select PTZ Baud rate for the PTZ camera.
Page 65: E-Mail & Sms Setup
Detection alarm in specified time; 3. Video Loss (Yellow): DVR System only responds with Video Loss alarm in specified time; 4. Not Check (gray): DVR System doesn’t respond with any alarms in specified time. Note: Check Alarm Setup (including Motion & Video Loss, Motion Alarm and Video Loss) does not take affection to Motion Detect Record.
Page 66 DVR Server Manual User can modify GSM modem's communicate parameters manually in C:\Program Files\DVR Server\SMS_LIB as bellow: After you insert the GSM MODEM, Firstly, you should install the driver.
Page 67 DVR Server Manual When the driver is installed, the interface as below will be displayed:...
Page 68: Email Setup
DVR Server Manual 2.5.1 Email Setup 【SMPT Server】SMTP server address, e.g.: mail.jstDVR.com, 【SMPT Port】SMTP listen TCP’s port for connect request. 【Auth. Type】Logon mailbox, operator should select SMTP authentic type. Or select “simple login”. 【Login User ID】Mailbox’s ID. 【Login Pass】Mailbox’s password. 【Send To】Set the address of receiver.
Page 69: Digital Matrix Setup
DVR Server Manual Note: The mobile number should be made up of the international code and mobile phone number. E.g.: In China, the mobile number is “86130****1234”. 2.6 Digital Matrix Setup 2.6.1 Matrix Setup 【Matrix Group】System operator can set groups of video images to be sent out through matrix decode card, each group has different display modes.
Page 70: Display Setup
DVR Server Manual local board cards, system uses soft decoding to play to TV Wall, total channels of them are not influenced by decoding channels. For IP cameras, system uses hard decoding; total channels of them are influenced by decoding channels.
Page 71: Password Setup
PC DVR, and activate the lock button in main window. Only authorized user can log into Netvision System at User Manage Mode. 【Auto lock time】Select a time to enable system to lock automatically when there are no actions during this time.
Page 72: User Right Setup
DVR Server Manual 【New User】Press button to edit the user you want to add in the 【User Name】Blank. Input User Name, Note Name, Password, and Confirm Password. Select Manage Right (Administrator or Operator), and then click Add User to save. 【Add User】Up to15 users can be added to system except Admin.
Page 73 DVR Server Manual When manager doesn’t want some operators to manage disk or backup data locally, he should not check the two rights for those users. For example, “admin” doesn’t want “user” to own the two rights, he should select “user” first, and click “Modify”, and then, check the “V”...
Page 74: Chapter3 Ip Camera Setup
DVR Server Manual Chapter3 IP Camera Setup Note: For IP camera setup, its alarm and related setup is only available when you set remotely. The local setup of PC DVR is not available for IP Cameras except Recording Schedule in Camera Setup.
Page 75 DVR Server Manual Remote setup interface of DG series EMDVR For other series IP cameras, such as Sony SNC110/160, ACTi Series IP, Huviron Series IP, Mobotix M12 Series IP, ArecontVision IP, Camtron Series IPC and Axis Series IPC, you will enter the IE interface automatically when you press “IP Camera Setup”.
Page 76: Functional Buttons
DVR Server Manual Remote Setup Interface of Axis IP Camera 3.1 Functional Buttons There are 5 buttons in each page. They are Upgrade, Restart, Time adjustment, Save and Exit. System can upgrade to the server remotely. Click this button, and select the right file. Some settings will come into effect only after device reboots.
Page 77: Server Setup
DVR Server Manual 3.2 Server Setup Press button to set server parameters remotely: In the server window, some blanks’ background are gray. Those parameters are read from foreside server, you can’t modify them. Other blanks whose background is white, you can set them remotely. 【Server Name】Enter the name description for easy identification.
Page 78: Channel Setup
DVR Server Manual Otherwise, you can’t connect the DVS correctly. 【DNS Server IP】If use DNS, input the DNS host IP address. 【Remote manage】 Set the IP address and port of host 【Remote manage IP】 server who will receive the message 【Remote manage port】...
Page 79 DVR Server Manual Choices are DCIF, CIF, QCIF, 2CIF and 4CIF. The higher the resolution is, the more disk space needed. 【Stream Type】Select video and audio or only video record. If you want to preview and record audio, please connect a sound pick-up to your IP camera.
Page 80: Ptz Control
DVR Server Manual Note: This record schedule is only available to EM-DVR and DVS with SD card. There are 4 time segments every day. Every segment has a start time, an end time and a record type. The time segment is set in sequence; every segment can’t be overlapped, included or skipped with any other.
Page 81 DVR Server Manual channels’ configuration as the same as this camera, you can select channel number from drop-list, and press button. 【PTZ Address】Set the address of the decoder, which must be matched with the value of dipswitch in the PTZ. 【PTZ Speed】Set the speed of PTZ.
Page 82: Sensor Setup
DVR Server Manual 【Preset】Set a preset and click “Add” to add it to the Preset Schedule or select one preset and press “Del” to delete from the Preset Schedule. 【Call Time】【Schedule List】 Set the time when the preset will be called. Tour Group Add the Preset cameras into the Tour Group and set the Stay Time for one tour group.
Page 83 DVR Server Manual 【Sensor NO】Select one sensor to be set. 【Sensor Name】Enter the name description of the sensor. 【Type】Select alarm type (sensor type) from “NO”(Normally Open) or “NC”(Normally Closed). 【Policy】Select “Sensor Alarm Handling” firstly, handling policies will be available as below: On screen warning—Display the alarm information on the monitor.
Page 84: Alarm Setup
DVR Server Manual 【Copy to】After finishing one channel, if you want to set any other channels’ configuration as the same as this camera, you can select a channel number from drop-list, and press button. 3.6 Alarm Setup Press button to set alarm parameters. 【Camera】Select a camera to be set from the drop-list and you can copy the configuration to the other cameras by clicking copy button.
Page 85 DVR Server Manual level) for the alarm. 【Set motion detection areas】 Left-click mouse and drag it on the screen to select motion detect area, you can select the whole area or many areas. Also, you can clear one or whole area by press the button clear and test the effect by clicking test button.
Page 86: Chapter4 Playback
DVR Server Manual Chapter4 Playback 4.1 Main Interface Click button in main interface to enter playback interface. 4.2 Steps of Playback...
Page 87: Select Date
The number button with navy blue means this channel has record data. By pressing it directly on the numerical panel, DVR system will play back record data from the first file.
Page 88: Smart Search
DVR Server Manual You can also keep all channels Sync in pause and Next Frame. 2. Smart Search (1). Function Introduction: This function allows users to draw a zone on a video image and do a search for any motions, missing objects, or unattended object events occurred in that zone.
Page 89: Select File
DVR Server Manual When you press the smart button, you should select the area percent by single clicking the right mouse, if the motion percent of the area above the select percent, it will be shown out. Note: 1. Press synchronic button while smart search is running, system will end smart search;...
Page 90 DVR Server Manual After selected the camera to play user can click button to show all the files of this camera. By default, system will play back video file from the first one. In this screen you can change the file you want to play by double clicking it directly. The camera list below the window shows the recorded data of the day you select.
Page 91: Play File And Related Operations
DVR Server Manual of server. 4.3 Play File and Related Operations Press button to set partition mode of Window, there are 1, 4, 9 and 16 splits. To reduce the load of CPU and get best effect, you should select the partition mode according to the record channels amount and resolution.
Page 92: Capture Picture
DVR Server Manual Last frame, Start, Pause, Stop and Next frame First frame, Last minute, Next minute and Last frame of that day. Image zoom in: Press this button and draw a red frame on the video, then, the part in the frame will be enlarged. You can single-right-click on the image to resume.
Page 93: Create File Clip
DVR Server Manual 4.5.1 Create File Clip Press to create file clip after you entered Backup. 【Select channel and save path】Select channel and save path of the backup file on the top of interface. 【File list and attribute】Select a file and double-click it to play and its attribute will display below the list , including begin time, end time, file size, resolution, frame rate etc.
Page 94: Backup By Time
DVR Server Manual button to set it as the beginning time, and then drag the bar to select another time and press button to set it as the end time. When you finished, the file attribute on the left will show the size of the file to be created. 【Save file】...
Page 95: View Backup File
DVR Server Manual one camera at one time. 【Select begin time】【Select end time】Select the beginning time and end time of the file to backup. It can backup the data feature and remove file unite function when backup, so that backup procedure is faster. You can check the file’s value by pressing button to show its total value.
Page 96: Burn Video File To Dvd/Cd
DVR Server Manual 【Select channel】Select channel; 【Save Path】Select path of the backup file; Select one file from File List and Double-Click it, this file will be played. The united file is named by “date + begin time” and “date + end time”;...
Page 97 DVR Server Manual ① ③ ② Area ①:File directory. Area ②:File list. Area ③:The File directory and list of CD that is to be burned to. ② to area ③. :Add selected files from area :Delete selected files from area ③. 【Burn CD drive】Select a CD-ROM driver.
Page 98: Search Captured Pictures
DVR Server Manual a third burning software. 4.6 Search Captured Pictures Click to enter the window of search captured pictures: 【Select pictures from directory and file list】 You can select a captured picture from directory list and file list in local disk and the file name will be showed in the top of the window.
Page 99: Pos Playback
DVR Server Manual Note: If you want to save the reworked picture in another file, you can change its name and path here, with BMP or JPG as suffix. Then click the button 【Related operations】 Save the reworked picture. Functional buttons of picture. Smooth the edges of picture.
Page 100 DVR Server Manual Show Txt: show the txt on the screen (if you checked “Text OSD to DVR board” in the Cam setup, the show txt would be invalid). Data: Select the search data. Camera: Select the search camera TXT Filter: Search the content including the word. E.g.:...
Page 101: Acu Playback
DVR Server Manual The word of the TXT Filter is THANK, then, press Search ,the content display all the POS messages with “THANK”. From ... To: Select the begin time and the end time. Press this button to search the record for the setting setup. Press these buttons to back or next the display page.
Page 102 DVR Server Manual Show Txt: show the txt on the screen (If you select txt overlay in the Cam setup, the show txt is invalid.) Data: Select the search data. Camera: Select the search camera. From...To: Select the begin time and the end time. Press this button to search the record for the setting setup.
Page 103: Icon Playback
DVR Server Manual Input “YunJian” in the User Name, then press Search, the content will display all the ACU messages with the user name “YunJian”. 4.9 ICON Playback Press the button , you will see the interface as below:...
Page 104 DVR Server Manual Select the camera. Set the begin time and the end time of the record. Set the time of one view plays. E.g.: As the above image, the time from 9:45 to 12:00, it includes 135 minutes between the begin time and the end time. There are 4 views, the first view shows the 0-10 minutes’...
Page 105: Chapter5 Ie Client
DVR Server Manual Chapter5 IE Client The client user can view video of DVR Server through Internet Explorer. The default web server port is 80. If user changes it to other port, user should add this port number after domain name when visiting the video of Server through Internet Explorer.
Page 106: Connection/Record Status
DVR Server Manual and press will disconnect all connections. If DVR Server’s channel is more than channels that you selected partition mode, you can use button to display DVR Server’s video in sequence. Pressing button will switch full screen mode and Right-Single-Click image can back to normal mode.
Page 107: Quit Program
DVR Server Manual The two functions will be detail described in Local Search Remote Search. 5.2.6 Quit Program Press button to shut down the IE Client. 5.3 Local Search Press button to enter local search: Display setup and data Playing operation area information 5.3.1 Display Setup and Data Information In this area, you can select display partition mode, date, video channel...
Page 108: Playing Operation Area
DVR Server Manual 5.3.2 Playing Operation Area In this area, you can operate video playing: 【 Video-playing time adjustment 】 Press and drag slider bar to adjust video-playing time. 【Information display panel】Display current window’s name, camera’s name and record data’s information. 【Playing-control buttons】...
Page 109: Fast Download Record Data
DVR Server Manual video of current channel you selected. After finishing it, system will inform the save path. 5.4.1 Fast Download Record Data In the playback mode, select one camera that there is record data, open file list panel, select one record data file, and click button, the selected data file will download fast.
Page 110: Chapter6 Mobile Client
Select “Enable” to allow the PDA to connect With DVR server in the Network Setup of the DVR system. Note: GPRS is charged by data flow, so shut down the MobileDVR application if you do not need view cameras.
Page 111: Download Software
DVR Server Manual 6.2 Download Software You have the following methods to download our mobile client software from DVR: 1. Download through wireless technology (in Wireless LAN) such as Blue tooth, infrared etc. 2. Copy mobile client software to phone directly through data cable. 3.
Page 112: Connection
DVR Server Manual You can install the mobile client as install java games in your smart phone, install mobile client in your smart phone directly (downloaded the program in WAN or LAN) or use the application supplied by the manufacture of your smart phone to download mobile client.
Page 113: Ptz Control
DVR Server Manual → 6.6 PTZ Control Press the “Options” button and select the “PTZ” button to enter the PTZ control interface. 【Orientation control】: Select the button and press “OK”,it will change into . After that, by pressing and holding the up, down, right and left buttons, the PTZ camera will move up, down, right and left.
Page 114: Appendix A: Fast Key Reference
DVR Server Manual Appendix A: Fast Key Reference Please refer to Shortcuts Keyboard Setup. This color key denotes PTZ control. This color key is other function control. PTZ control: Function Up(in the status of preview for PTZ control) ↑ Play in fast speed (in the status of instant playback and review playback) Down(in the status of preview for PTZ control) ↓...
Page 115 DVR Server Manual Play next frame((in pause condition of review playback) Home Zoom- Zoom+ Insert Focus- Delete Focus+ C、 —、 Num0-9G、 Presets Control Operation Call preset Enter C、—、 Num0-9 Presets Control Operation Other controls: Function System Help Switch the camera channel Next screen Page Down Previous screen...
Page 116: Appendix B: Audio Preview
DVR Server Manual Appendix B: Audio Preview NV Series Card Audio Preview To 40 series card, please connect the card use the cable in the box as follows: Note: Sometimes there is no preview sound, Solution: double click the volume control in the taskbar, open the properties dialog box, and check AUX control.
Page 117: Dg Series Card Audio Preview
DVR Server Manual To NV 42 series card, there is no need to connect the “audio in” and “audio out” cable. However, a sound pick-up is necessary if you want to hear and record the sound, no matter what’s the type of the card. DG Series Card Audio Preview The connection is same as NV 40 series card.
Page 118: Appendix C: How To Use "Copy File" Folder
DVR Server Manual Appendix C: How to Use “Copy File” Folder In installation CD, there is a file named “Copy File”. If you want to replace some files in installation directory, you can copy new files into “CopyFile”, when you finished the installation, the new files will replace the old files automatically.
Page 119: Appendix D: Dvr Board Explanation
DVR Server Manual Appendix D: DVR Board Explanation This DVR System manual is suitable for all NV and DG series DVR boards, including: NV400XHC, NV400XHF, NV400XHS, NV4016HCS, NV4216HCI and NV42XXHFV; DG40XXHC, DG40XXHC–E, DG4108HC (N) and DG4108HF, etc. NV Series Board Cards NV400XHC: Support dual-stream.
Page 120: Appendix E: How To Use 3G Function
DVR Server Manual Appendix E: How to Use 3G Function For a DG camera supports 3G function, you can enable its 3G function in our DVR software by checking the box in front of Enable 3G. The steps to config 3G function are as below: First of all, forward 3G server port to your router if you want to use 3G function in WAN.
Page 121 DVR Server Manual The third is to enter 3G Setting to config 3G function. Insert a card in the camera first. Then, you should select a 3G type according to your phone from WCDMA, TD-SCDMA and CDMA2000. Check the box after Advanced to set APN according to your phone. The 3G Status will turn to be “pppoe dial-up success!”...
Page 122 DVR Server Manual Note: You can’t modify the camera once it is connected to the DVR. If you want to change the stream type, you should delete first and then re-add it. You have to modify its stream type before it is added to the software.
