Summary of Contents for Osmo Wood Orbiter
- Page 1 Operating Manual: Osmo Wood Orbiter Please read the operating manual carefully and observe the safety notices and information on making a suitable brush selection and correctly setting the brush pressure.
-
Page 3: Function Principle
3. From here the liquid is striped by a steel blade and conveyed to the dirty water tank. Process for assembling the Osmo Wood Orbiter Ensure that all the parts in the image are available, please compare the parts to the operating instructions in order to assemble the Orbiter correctly. - Page 4 Assembly: 1. Insert the two tubular stems in the bow-shaped handle. There is a sticker on both tubes “LEFT BOTTOM REAR/ RIGHT BOTTOM REAR”. These tubes must be mounted in the direction of motion (cable at the rear). Tighten the knurled screws manually (looking at the machine from the operating side).
- Page 5 2 small screws on the right-hand side of the housing, only then can the connector be firmly pushed into place, as far as it will go, using the back of your hand. Gently tighten the screws. The Osmo Wood Orbiter is now ready for operation.
- Page 6 Using the Osmo Wood Orbiter Switching the machine on and off Switching on Gently press the safety pedal using your foot (1) and slowly pull the shaft towards you (2). The motor starts and the brushes slowly begin to turn.
-
Page 7: Work Position
Work position Press the red button up and lower the handle into the work position. The transport wheels move up and the Orbiter can be operated. Adjusting the brush pressure The brush pressure can be adjusted to four settings using the black button on the left side of the machine (pressure regulator). - Page 8 1. Only use low-foaming, non-aggressive cleaning agents from Osmo: Wash & Care (internal), Water (external). 2. Exterior use: First apply the Wood Reviver "Power Gel" using the Osmo floor brush, a hard bristle brush or scrubber and then move over the area with the Orbiter.
- Page 9 3. Stop the liquid supply approx. 30 cm. before the wall or the turning point and continue towards the wall. Graphic 1 Graphic 2 Press 4. Drag the Orbiter back along the same track. The dirty water is absorbed upon return movement. To start only loosely fit the dirty water tank so that the reviver is allowed to circulate on the surface for longer and has a better effect (outdoor area), then stop the water supply and click the dirty water tank into place to remove the dirt.
- Page 10 Edge brush (optional) To achieve better cleaning results around the edges, please use the edge brush set. Mounting the edge brush 1. Tighten the guard using a plastic screw on the front at the left cover. 2. Push the hexagonal spindle with the edge brush through the shaft support parts until you feel it engages.
- Page 11 9. Reinsert the brushes by reinserting the floating axles from the right. Repair To ensure the long term enjoyment of the Osmo Wood Orbiter, please observe the following points: Clean the brushes on a regular basis. Do not use a high-pressure or steam cleaner.
- Page 12 Osmo Holz and Color GmbH & Co. KG Affhüppen Esch 12, D-48231 Warendorf · P.O. Box 110161, D-48203 Warendorf Phone +49 (0) 2581 / 922-100, Fax +49 (0) 2581 / 922-200 · www.osmo.com, info@osmo.com...
