User's Guide For
MINI0806 DASH CAMERA
Please read this manual carefully before using.
This manual should be kept for future reference.
WARNING: The dash camera should be set up before driving.
Concentration should always be maintained on the task of driving, let the
dash camera record accidents caused by others not by youself.
Advertisement
Table of Contents
Summary of Contents for mini0806 X44
- Page 1 User's Guide For MINI0806 DASH CAMERA Please read this manual carefully before using. This manual should be kept for future reference. WARNING: The dash camera should be set up before driving. Concentration should always be maintained on the task of driving, let the...
- Page 3 Extract the FIRMWARE.BIN file to the root folder of your microSD card; insert the card into your mini0806 camera and power on. The camera will auto examine the FIRMWARE.BIN file and popup a confirmation dialogue, press the UP or DOWN button to choose YES and press OK to upgrade.
- Page 4 3 - speaker holes 4 - CPL mounting bar 5 - lens 6 - front cooling holes 7 - bottom cooling holes mini0806 camera 8 - side cooling holes 9 - power indicator 10 - recording indicator 11 - GPS/MIC indicator...
- Page 5 APPEARANCE 12 - sticker 13 - HDMI output 14 - card B slot 15 - TFT screen 16 - mounting contacts 17 - UP button 18 - OK button 19 - DOWN button 20 - MIC holes 21 - microUSB port 22 - card A slot 23 - POWER button 24 - mount...
-
Page 6: Operation
OPERATION Read this chapter to know how to operate the camera. TURN ON /OFF YOUR CAMERA You may turn on the camera by pressing the power button. You may turn off the camera by holding the power button for 2 seconds. The camera is also pre-configured to auto turn on and start recording once it receives power, e.g. - Page 7 OPERATION PLAYBACK ON TV When the camera is connected to a TV with an HDMI cable, the camera screen will be turn off and transfer the display to the TV. The operation will be the same as when using playback on the camera. If you want to connect a TV for playback via an AV connection, you need to use the customized AV-out cable (optional accessory).
- Page 8 SETTING The 0806 camera is pre-configured to provide you with a simple plug and play experience - the default settings are the most popular options. Please read this chapter to help you to customize the camera setting, when you require a slightly different experience. The default setting are listed in BOLD.
- Page 9 SETTING EXPOSURE COMPENSATION Here you can manually adjust the Exposure Values to improve the image brightness. options: -2.0 -1.7 -1.3 -1.0 -0.7 -0.3 +0.3 +0.7 +1.0 +1.3 +1.7 +2.0 WHITE BALANCE Here you can set the image white balance mode to improve colour balance in videos/images in different weather and lighting conditions.
-
Page 10: Motion Detection
SETTING aware that the maximum video file size is 4GB. options: 1 MIN 3 MIN 5 MIN LDWS DETECTION The camera will warn when it detects a lane departure, including normal planned lane departures. Here you can define the speed threshold above which the LDWS will become active. - Page 11 SETTING options: MIDDLE HIGH GREEN INDICATOR Here you can define the indicating function of the Green Indicator. options: GPS STATUS MIC STATUS G-SENSOR SENSITIVITY The G-sensor is used to detect the 3-axis impacting forces. If any impact over the threshold value is detected, the current recording file will be locked/protected to avoid being over-writen.
- Page 12 SETTING options: LOG ONLY SPEED STAMPING The 0806 camera can record your driving speed and stamp the speed data on video. Here you can define the speed data display method options: KM/H DRIVER NUMBER STAMPING The 0806 camera can stamp your driver number or your customized information on video.
-
Page 13: Restore Defaults
SETTING CHOOSE CARD Here you can choose the card(s) on which you want to store the videos and photos. If set to AUTO, the recording will be alternated between card A and card B once it is full . options: AUTO CARD A ONLY CARD B ONLY... - Page 14 UI & PLAYER WHITE BALANCE EXPOSURE 0.0EV COMPENSATION LOOP RECORDING DUAL CARDS FILE LOCKED MIC ON VIDEO RECORDING MODE BATTERY POWER SYSTEM TIME GPS INVALID REMAINING TIME MOTION DETECTION RECORDING TIME PARKING GUARD CARD B WORKING RECORDING VIDEO AREA MAP AREA PROGRASS LONGITUDE &...
-
Page 15: Specification
HDMI output to TV and optional AV-out supports Circular Polarizing Filters supports 160degree rotating and 6 degree offset built in 3.7V 200mAh Li-Polymer Battery mini0806 camera box content dash camera unit GPS logging mounting bracket 2° and 4° angle mounting wedge wedge mounting screws M1.4*5mm... - Page 16 There are two wedges attached in accessories bag, one is 2° angle and another is 4° angle. With these you can mount the mini0806 camera at a 2°, 4°, or with both together 6° offset location. mini0806mount...
-
Page 17: Power Source
POWER SOURCE The mini 0806 camera can be powered by power lead for cigar lighter socket, or hardwire kit. Power lead for cigar lighter socket is a easy&fast connecting method for cameras, the only thing you need to do is plug the power lead into the cigar light socket in your car. - Page 18 ACCESSORIES All the accessories listed in this page are optional. CPL filter Reduce the reflection from shiny surface like vegetation, sweaty skin, water surface, glass, road, and let the natural color come through at the same time. Some of the light coming from the sky is also polarized to give a more dramatic sky and high contrast clouds, rendering outdoor scenes...
-
Page 19: Troubleshooting
What to do if the camera has locked up and will not respond to button presses? Remove the camera from the mount or turn off the power, then hold the power button for 20 seconds, the camera will auto reset. More questions? Please get help from www.mini0806.com! - Page 20 MORE THAN A DASH CAMERA www.mini0806.com...
