Provision NE Series User Manual

H.264 4/8/16-channel digital video recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DVR User Manual
alarm shop
NE Series
For H.264 4/8/16-channel digital video recorder
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NE Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Provision NE Series

Summary of Contents for Provision NE Series

  • Page 1 DVR User Manual alarm shop NE Series For H.264 4/8/16-channel digital video recorder All rights reserved...
  • Page 2 DVR User Manual alarm shop For H.264 4/8/16-channel digital video recorder All rights reserved...
  • Page 3 Digital Video Recorder User Manual CAUTION Please read this user manual carefully to ensure that you can use the device correctly and safely We do not warrant all the content is correct. The contents of this manual are subject to change without notice This device should be operated only from the type of power source indicated on the marking label.

  • Page 4: Table Of Contents

    Digital Video Recorder User Manual Table of Contents Introduction ..........................................7 1.1 DVR Introduction ....................................... 7 1.2 Main Features ........................................7 Hardware Installation ......................................10 2.1 Install Hard Drive &DVD Writer ..................................10 2.1.1 Install Hard Drive ....................................10 alarm shop 2.1.2 Install DVD Writer....................................
  • Page 5 Digital Video Recorder User Manual Main menu setup guide ....................................... 24 4.1 Basic configuration......................................25 4.1.1 System ........................................25 4.1.2 Time & date ......................................27 4.1.3 DST ........................................27 4.2 Live configuration ......................................28 4.2.1 Live ........................................28 4.2.2 Host monitor ......................................30 4.2.3 SPOT........................................
  • Page 6 Digital Video Recorder User Manual 4.5.5 Alarm out ....................................... 49 4.6 Network configuration ...................................... 50 4.6.1 Network ......................................... 50 4.6.2 Network stream ...................................... 54 4.7 User management configuration ..................................56 4.8 P.T.Z configuration ......................................58 Record search & playback and backup ................................63 5.1 Time search ........................................
  • Page 7 Digital Video Recorder User Manual 7.1.1 On LAN ........................................73 7.1.2 On WAN ........................................ 75 7.2 The remote live preview interface as below: ..............................76 7.3 Remote playback & backup ....................................81 7.3.1 Remote playback ....................................81 7.3.2 Remote backup ...................................... 86 7.4 Remote System configuration ..................................

  • Page 8: Introduction

    Digital Video Recorder User Manual Introduction 1.1 DVR Introduction This model DVR (Digital Video Recorder) is designed specially for CCTV system. It adopts high performance video processing chips and embedded Linux system. Meanwhile, it utilizes many most advanced technologies, such as standard H.264 with low bit rate, Dual stream, SATA interface, VGA output mouse supported, IE browser supported with full remote control, mobile view(by phones), etc., which ensure its powerful functions and high stability.
  • Page 9 Digital Video Recorder User Manual • Support saving recorded files with AVI standard format to a remote computer through internet RECORD & PLAYBACK • Record modes: Manual, Schedule, Motion detection and Sensor alarm recording • Support recycle after HDD full •...
  • Page 10 Digital Video Recorder User Manual SECURITY • Customize user right: log search, system setup, two way audio, file management, disk management, remote login, live view, manual record, playback, PTZ control and remote live view • Support 1 administrator and 15 users. •...

  • Page 11: Hardware Installation

    Digital Video Recorder User Manual Hardware Installation Notice: Check the unit and the accessories after getting the DVR. alarm shop Please disconnect the power before being connected to other devices. Don't hot plug in/out 2.1 Install Hard Drive &DVD Writer 2.1.1 Install Hard Drive Notice: 1.

  • Page 12: Install Dvd Writer

    Digital Video Recorder User Manual alarm shop Fig 2.2 Screw HDD 2.1.2 Install DVD Writer Notice: 1. The writers must be the compatible devices we recommend. Please refer to “Appendix C Compatible Devices” 2. This device is only for backup Step1: Unscrew and Open the top cover Step2: Connect the power and data cables.

  • Page 13: Front Panel Instructions

    Digital Video Recorder User Manual Fig 2.4 Screw the Writer 2.2 Front Panel Instructions alarm shop Notice: The pictures are only for reference; please make the object as the standard. The Front Panel interface for is shown as Fig 2.5: Fig 2.5 Front Panel...

  • Page 14: Rear Panel Instructions

    Digital Video Recorder User Manual Item Name Description Digital button Input digitals or choose camera Input number 10 and the above number together with other digital keys 1. Decrease the value in setup －/Backup 2. Enter backup mode in live RECORD/FOCUS Record manually, FOCUS function enables at PTZ.
  • Page 15 Digital Video Recorder User Manual alarm shop Fig 2.6 Rear Panel for 4-ch Item Name Description Video out Connect to monitor Connect to monitor as an AUX output channel by channel. Only video display, Spot out no menu show Audio out Audio output, connect to the sound box Connect to speed dome Connect to keyboard...
  • Page 16 Digital Video Recorder User Manual alarm shop Fig 2.7 Rear Panel for 8-ch Item Name Description Video out Connect to monitor Connect to monitor as an AUX output channel by channel. Only video display, Spot out no menu show Audio out Audio output, connect to the sound box Video in Video input channels from 1-8...
  • Page 17 Digital Video Recorder User Manual The rear Panel interface for 16-ch is shown as Fig 2.8: alarm shop Fig 2.8 Rear Panel for 16-ch Item Name Description Connect to speed dome Connect to keyboard ALARM IN Connect to external sensor1-16 HDMI port Connect to high-definition display device (optional) Network port...

  • Page 18: Remote Controller

    Digital Video Recorder User Manual 2.4 Remote Controller It uses two AAA size batteries and works after loading batteries as following: Step1: Open the battery cover of the Remote Controller Step2: Place batteries. Please take care the poles (+ and -) Step3: Replace the battery cover Notice: Frequently defect checking as following 1.

  • Page 19: Control With Mouse

    Digital Video Recorder User Manual Item Name Function INFOR Button Get information about the DVR like firmware version, HDD information REC Button To record manually Digital Button Input digital or choose camera Multi Screen Button To choose multi screen display mode SEARCH Button To enter search mode MENU Button...

  • Page 20: Use Mouse

    Digital Video Recorder User Manual 1. Make sure the mouse plugs in the USB mouse port not the USB port 2. Change a mouse to try 2.5.2 Use Mouse The structure of the main menu is shown in Fig 2.9 Remote Controller. In live: Double-click left button on one camera to be full screen display.

  • Page 21: Basic Function Instruction

    Digital Video Recorder User Manual Basic Function Instruction 3.1 Power On/Off Before you power on the unit, please make sure all the connection is good. 3.1.1 Power on Step1: connect with the source power; switch on the power button near the power port on the rear panel Step2: the device will be loaded, and the power indicator will display blue Step3: before start, a WIZZARD dialogue box will be pop-up (refer to below picture) and show some information about time zone and time setup.

  • Page 22: Power Off

    Digital Video Recorder User Manual 3.1.2 Power off User can power off the device by using remote controller、keyboard and mouse. By remote controller: Step1: press Power button, the Shut down window will appear, click OK, the unit will power off after a while. Step2: disconnect the power By keyboard and mouse: Step1: enter into...

  • Page 23: Live Preview

    Digital Video Recorder User Manual 3.3 Live preview alarm shop Fig 3-2 live preview interface The explanation of symbol in the live preview interface: symbol meaning symbol meaning Green Manual record or time record Alarm record Yellow Motion detection record Figure icon Move event 3.3.1 Live playback...
  • Page 24 Digital Video Recorder User Manual alarm shop Fig 3-3 live playback...

  • Page 25: Main Menu Setup Guide

    Digital Video Recorder User Manual Main menu setup guide Click right mouse or press ESC button on the front panel, the control bar will display on the bottom of the screen, refer to Fig 4-1: Fig 4-1 main menu toolbar Click the icon beside the screen display mode, a channel select dialog will appear as below: alarm shop...

  • Page 26: Basic Configuration

    Digital Video Recorder User Manual alarm shop Fig 4-2 system setup 4.1 Basic configuration Basic configuration includes three sub menus: system、date& time and DST. 4.1.1 System Step1: enter into system configuration basic configuration system; refer to Fig 4-3:...
  • Page 27 Digital Video Recorder User Manual alarm shop Fig 4-3 basic configuration-basic Step2: in this interface user can setup the device name, device ID, video format, max network users, VGA resolution and language. The definitions for every parameters display as below: Device name: the name of the device.

  • Page 28: Time & Date

    Digital Video Recorder User Manual Note： ： ： ： When switch between VGA and CVBS will change the menu output mode, please connect to relevant monitor. Language: setup the menu language. Note: after changed the language and video output, the device needs to login again. 4.1.2 Time &...

  • Page 29: Live Configuration

    Digital Video Recorder User Manual alarm shop Fig 4-5 basic configuration-DST Step2: in this interface, enable daylight saving time, time offset, mode, start & end month/week/date, etc. Step3: click “default” button to resort default setting; click “apply” button to save the setting; click “exit” button to exit current interface. 4.2 Live configuration Live configuration includes four submenus: live, host monitor, SPOT and mask.
  • Page 30 Digital Video Recorder User Manual alarm shop Fig 4-6 live configuration live Step2: tick off camera name; click “setting” button, a window will pop-up as Fig 4-7: Fig 4-7 live-color adjustment...

  • Page 31: Host Monitor

    Digital Video Recorder User Manual Step3: in this interface, user can adjust brightness, hue, saturation and contrast in live; click “default” button to resort default setting, click “OK” button to save the setting. Step4: user can setup all channels with same parameters, tick off “all”, then do relevant setup. Step5: click “default”...

  • Page 32: Spot

    Digital Video Recorder User Manual 4.2.3 SPOT Step1: enter into system configuration live configuration SPOT; refer to Fig 4-9: alarm shop Fig 4-9 live configuration-SPOT Step2: select split mode: 1×1and channel Step3: dwell time: the time interval for a certain dwell picture display switching to next dwell picture display Step4: selected the split mode, then setup current picture group.
  • Page 33 Digital Video Recorder User Manual alarm shop Fig 4-10 live configuration-mask Setup mask area: click Setting button, enter into live image to press left mouse and drag mouse to set mask area, refer to below picture. Click Apply button to save the setting. Delete mask area: select a certain mask area, click left mouse to delete that mask area, click Apply button to save the setting.

  • Page 34: Record Configuration

    Digital Video Recorder User Manual alarm shop Live image mask area 4.3 Record configuration Record configuration includes five sub menus: enable, record bit rate, time, recycle record and stamp. 4.3.1 Enable Step1: enter into system configuration record configuration enable; refer to Fig 4-11:...
  • Page 35 Digital Video Recorder User Manual alarm shop Fig 4-11 record configuration-enable Step2: tick off record, audio and record time Step3: user can setup all channels with same parameters, tick off “all”, then to do relevant setup. Step4: click “default” button to resort default setting; click “apply” button to save the setting; click “exit” button to exit current interface. Definitions and descriptions of Record: Parameter Meaning...

  • Page 36: Record Stream

    Digital Video Recorder User Manual 4.3.2 Record stream Step1: enter into system configuration record configuration record bit rate; refer to Fig 4-12: alarm shop Fig 4-12 record configuration-record bit rate Step2: setup rate, resolution, quality, encode and max bit stream Step3: user can setup all channels with same parameters, tick off “All”, then to do relevant setup.

  • Page 37: Time

    Digital Video Recorder User Manual Resolution Support CIF and D1 Quality The quality of recorded images. The higher the value is, the clearer the recorded image is. Six options: lowest, lower, low, medium, higher and highest. Encode VBR and CBR Range from: 64 Kbps、128 Kbps、256 Kbps、512 Kbps、768 Kbps、1Mbps、...

  • Page 38: Recycle Record

    Digital Video Recorder User Manual Expire time: the hold time of saved records. If the set date is overdue, the record files will be deleted automatically. Step2: user can setup all channels with same parameters, tick off “all”, then to do relevant setup. Step3: click “default”...

  • Page 39: Schedule Configuration

    Digital Video Recorder User Manual Step2: tick off camera name, time stamp; click Set button, user can use cursor to drag the camera name and time stamp in random positions, refer to below Figures: alarm shop Before drag after drag Step3: user can setup all channels with same parameters, tick off “all”, then to do relevant setup.
  • Page 40 Digital Video Recorder User Manual alarm shop Fig 4-15 schedule configuration-schedule Step2: select channel, double-click and a dialog box will pop-up as Fig 4-16, user can edit week schedule: Fig 4-16 schedule-week schedule...

  • Page 41: Motion

    Digital Video Recorder User Manual ① Click “add” button to add a certain day schedule; click “delete” button to delete the selected schedule; Copy: user can copy the specify schedule to other dates. Click “OK” button to save the setting, click “Exit” button to exit current interface. ①...

  • Page 42: Sensor

    Digital Video Recorder User Manual 4.4.3 Sensor Step1: enter into system configuration schedule configuration alarm; refer to Fig 4-18: Step2: the setup steps of alarm are familiar with schedule; user can refer to 4.4.1 Schedule for details. Note: the default schedule of sensor is full-selected, that is, the color of schedule setting interface is blue. alarm shop Fig 4-18 schedule configuration-sensor 4.5 Alarm configuration...
  • Page 43 Digital Video Recorder User Manual Step1: enter into system configuration alarm configuration sensor basic; refer to Fig 4-19: alarm shop Fig 4-19 alarm configuration-sensor-basic Step2: enable sensor alarm, set the alarm type according to triggered alarm type. Two option: NO and NC. Step3: user can setup all channels with same parameters, tick off “all”, then to do relevant setup.
  • Page 44 Digital Video Recorder User Manual alarm shop Fig 4-20 alarm configuration-sensor-alarm handling Step2: select hold time, click Trigger button, and a dialog box will pop-up as Fig 4-21: Fig 4-21 alarm handling-trigger Step3: tick off Buzzer, there will be triggered buzzer alarm out; Full screen alarm: when triggered alarm, there will pop up full screen alarm;...
  • Page 45 Digital Video Recorder User Manual button to exit the current interface. To record: tick off recoding channels, it will record the camera when alarm triggered. Click OK button to save the setting; click Exit button to exit the current interface. To P.T.Z: set linked preset and cruise for alarm.

  • Page 46: Motion

    Digital Video Recorder User Manual 4.5.2 Motion Motion includes two sub menus: motion and schedule. ① Motion Step1: enter into system configuration alarm configuration motion; refer to Fig 4-23: alarm shop Fig 4-23 alarm configuration-motion Step2: enable motion alarm, set alarm hold time which means time interval between two adjacent detective motions. If there is other motion detected during the interval period which is considered continuous movement;...
  • Page 47 Digital Video Recorder User Manual Fig 4-24 motion-area Step5: in the Area interface, user can drag slide bar to set the sensitivity value (1-8), the default value is 4. The higher the value is the higher alarm shop sensitivity you get. Due to the sensitivity is influenced by color and time (day or night), user can adjust its value according to the practical conditions;...

  • Page 48: Video Loss

    Digital Video Recorder User Manual Step6: user can setup all channels with same parameters, tick off “all”, then to do relevant setup. Step7: click “default” button to resort default setting; click “apply” button to save the setting; click “exit” button to exit current interface. ①...

  • Page 49: Other Alarm

    Digital Video Recorder User Manual alarm shop Fig 4-26 alarm configuration-video loss Step2: the setup steps of video loss trigger are familiar with alarm handling; user can refer to Chapter 4.5.1 Sensor alarm handling for more details. Step3: user can setup all channels with same parameters, tick off “all”, then to do relevant setup. Step4: click “default”...

  • Page 50: Alarm Out

    Digital Video Recorder User Manual Step1: enter into system configuration other alarm; refer to Fig 4-27: Step2: select a hard disk in the pull down list box, when the disk capacity is lower than that value, there will appear some text information on the lower right of the live image.

  • Page 51: Network Configuration

    Digital Video Recorder User Manual Note: the default schedule of motion detection is full-selected, that is, the color of schedule setting interface is blue. ① Buzzer Step1: enter into system configuration buzzer; Step2: tick off Buzzer, set buzzer alarm hold time 4.6 Network configuration Network configuration includes two submenus: network and network stream.
  • Page 52 Digital Video Recorder User Manual Step2: HTTP port: the default value is 80. If the value changed, user needs to add the port number when typing IP address in IE address blank .i.e. set HTTP port to 82, IP address: http://192.168.0.25, user needs to input that address: http://192.168.0.25:82 into IE browser.
  • Page 53 Digital Video Recorder User Manual alarm shop Fig 4-30 Register dialog box (2) Login Step 1: Return to homepage after registering successfully. Step 2: Click "Account Manager" on the right of homepage to login. Step 3: Input the username and password with the information that you have registered. Step 4: Click "Enter"...
  • Page 54 Digital Video Recorder User Manual Fig 4-31 Log in (3) Domain Setup Step 1: Click "Domain Management" on the left to set the domain. alarm shop Fig 4-32 Domain setup Step 2: Input the domain in the textbox. For example, you set DVR as the domain. Step 3: Click "Submit"...

  • Page 55: Network Stream

    Digital Video Recorder User Manual server name, user name and password. Click Save button to save the setting. ① Enter into configuration interface of the router, map the server port and IP address. Click Save button to save the setting ①...
  • Page 56 Digital Video Recorder User Manual alarm shop Fig 4-33 network configuration-sub stream Step2: select fps, resolution, quality, encode and max bit rate Step3: user can setup all channels with same parameters, tick off “all”, then to do relevant setup. Step4: click “default” button to resort default setting; click “apply” button to save the setting; click “exit” button to exit current interface. Definitions and descriptions of network stream: Parameter Meaning...

  • Page 57: User Management Configuration

    Digital Video Recorder User Manual options: lowest, lower, low, medium, higher and highest. Encode VBR and CBR Range from: 64 Kbps、128 Kbps、256 Kbps、512 Kbps、768 Kbps、1Mbps、2 Mbps Max bit rate 4.7 User management configuration Step1: enter into system configuration user management configuration; refer to Fig 4-34: alarm shop Fig 4-34 user management configuration Step2: click Add button, a dialog box will pop-up as Fig 4-35:...
  • Page 58 Digital Video Recorder User Manual ① General: Input user name, password; select user type: normal and advance, input the MAC address of the PC; click OK button, this user will be added into the user list box; click Exit button to exit the current interface. Note: when the default value of binding PC MAC address is 0, the user is not bind with the specify computer;...

  • Page 59: Configuration

    Digital Video Recorder User Manual 4.8 P.T.Z configuration P.T.Z configuration includes two submenus: serial port and advance ① Serial port Step1: enter into system configuration P.T.Z configuration serial port; refer to Fig 4-37: alarm shop Fig 4-37 P.T.Z configuration-serial port Step2: tick off Enable, setup the value of address, baud rate and protocol according to the settings of the speed dome.
  • Page 60 Digital Video Recorder User Manual Parameter Meaning Address The address of the PTZ device Baud rate of the PTZ device. Range form: 110、 300、 600、 1200、 2400、 4800、 Baud rate 9600、19200、34800、57600、115200、230400、460800、21600. Communication protocol of the PTZ device. Range from: NULL、PELCOP、 Protocol PELCOD 、...
  • Page 61 Digital Video Recorder User Manual alarm shop Fig 4-39 advance-preset setting a. in the preset set interface, click Setting button, a dialog will pop-up as Fig 3-40: Fig 3-40 preset set-setting b. user can control the dome rotates up, up left, down, right down, left , left down, right and up right and stop rotating; adjust the rotate speed and the value of zoom, focus and iris of the dome;...
  • Page 62 Digital Video Recorder User Manual Step3: in the Advance interface, click cruise “Setting” button, a dialog box will pop-up as Fig 4-41: alarm shop Fig 4-41 cruise set a. click Add button to add cruise line in the list box (max 8 cruise line can be added); select a cruise line, click Setup button, a dialog box will pop-up as Fig 4-42: Fig 4-42 cruise set-modify cruise line...
  • Page 63 Digital Video Recorder User Manual b. click Add icon to set the speed and time of preset point; select a preset point, click Delete icon to delete that preset point; click Modify icon to modify the setting of a preset point. User can click those icons to adjust the position of preset point.

  • Page 64: Record Search & Playback And Backup

    Digital Video Recorder User Manual Record search & playback and backup Search configuration includes three submenus: time search, event search and file manager. 5.1 Time search Step1: enter into Search configuration time search; refer to Fig 5-1: alarm shop Fig 5-1 Search configuration-time search Step2: select channel, screen display mode, the highlight date in the calendar means have record data Step3: select a date, press Search button, click the time grid to set the play start time or input play record time manually.

  • Page 65: Event Search

    Digital Video Recorder User Manual Playback buttons Note: when the monitor resolution is VGA800*600, the time search interface will appear a hide button, click this button, the whole interface can be expanded. alarm shop 5.2 Event search Step1: enter into Search configuration event search; refer to Fig 5-2: Fig 5-2 Search configuration-event search...

  • Page 66: File Manager

    Digital Video Recorder User Manual Step2: click Search button, the searched event information will displayed in the event list box, user can select date, channel, tick off Motion, Sensor or All accordingly. Step3: double check a certain record file to playback. Note: when the monitor resolution is VGA800*600, the event search interface will appear a hide button, click this button, the whole interface can be expanded.

  • Page 67: Backup

    Digital Video Recorder User Manual Step3: tick off “All” button; user can lock/unlock or delete all files in the file manager column. Step4: double click an unlocked item to playback. Note: when the monitor resolution is VGA800*600, the file manager interface will appear a hide button, click this button, the whole interface can be expanded.
  • Page 68 Digital Video Recorder User Manual alarm shop Fig 5-5 backup information Step4: in the backup information interface, user can check the relevant information of backup files, storage type, save file type, etc. click Apply button to starting backup. Note: when the monitor resolution is VGA800*600, the file manager interface will appear a hide button, click this button, the whole interface can be expanded.

  • Page 69: Manage Dvr

    Digital Video Recorder User Manual Manage DVR 6.1 Check system information Check system information includes five submenus: system, event, log, network and online user. 6.1.1 System information In this interface, user can check the hardware version, MCU version, kernel version, device ID, etc. refer to Fig 6-1: alarm shop Fig 6-1 system information 6.1.2 Event information...

  • Page 70: Log Information

    Digital Video Recorder User Manual alarm shop Fig 6-2 event information 6.1.3 Log information In this interface, user can check relevant log information according to set date; refer to Fig 6-3: Fig 6-3 log information...

  • Page 71: Network Information

    Digital Video Recorder User Manual 6.1.4 Network information In this interface, user can check relevant parameters of network; refer to Fig 6-4: alarm shop Fig 6-4 network information 6.1.5 Online information In this interface, user can check the details of the current connection of online users; refer to Fig 6-5: Fig 6-5 online information...

  • Page 72: Manual Alarm

    Digital Video Recorder User Manual 6.1.6 Manual alarm In this interface, user can check the relevant parameters of manual alarm; refer to Fig 6-6: alarm shop Fig 6-6 manual alarm 6.1.7 Disk manager Step1: enter into disk manager interface; refer to Fig 5-7: Fig 6-7 disk manager Note: please format the hard disk before record.

  • Page 73: Upgrade

    Digital Video Recorder User Manual Step2: click Refresh button to refresh the disk information of the list box; set the property of the disk then click Apply button to save the setting Step3: checked a hard disk, click Format button to star format. Note: all recorded files in the hard disk will be lost after formatted.

  • Page 74: Remote Surveillance

    Digital Video Recorder User Manual Remote Surveillance 7.1 Accessing DVR If making remote view, the DVR must connect with LAN or internet. Then enable network server in the unit. Please refer to 4.6 Network Configuration. This unit supports IE browser, not any client software installed. In addition, it supports XP and Vista. 7.1.1 On LAN Step1: Input IP address, Subnet, Gateway.
  • Page 75 Digital Video Recorder User Manual alarm shop Fig 7.1 View with IE browser Notice: If HTTP port is not 80, other number instead, need add the port number after IP address. For example, set HTTP port as 82, need input IP address like 192.168.0.25:82. User name and password here are the same with that used on the DVR.

  • Page 76: On Wan

    Digital Video Recorder User Manual 7.1.2 On WAN There are two ways that the DVR is connected to internet. 1. Connect the DVR to internet through a router or virtual server. Step1: Input IP address, Subnet, Gateway. If using DHCP, please enable DHCP in both the DVR and router. Step2: Enter Video to set network video parameters like resolution, frame rate etc.

  • Page 77: The Remote Live Preview Interface As Below

    Digital Video Recorder User Manual 7.2 The remote live preview interface as below: alarm shop Fig 7-2 Remote live preview interface...
  • Page 78 Digital Video Recorder User Manual Symbol and function Definitions: ① ② ③ Channel indicator Screen display mode Volume ④ ⑤ ⑥ Snapping picture Start record Playback ⑦ ⑧ ⑨ Master/sub stream Color adjustment PTZ control status Note: click button to record manual and the record file will be saved in user’s PC. Screen display mode: Click the icon beside the screen display mode, channel select dialog will appear as below:...
  • Page 79 Digital Video Recorder User Manual alarm shop Fig 7-4 Single snap User can multiple pictures , select the picture number from Frame pull down list box, such as 3, tick off “Title” and “Time”, it will show capture title and time on the snap pictures simultaneously. Refer to Fig 6-5: Fig 7-5 Multi-picture snap Click “Browse”...
  • Page 80 Digital Video Recorder User Manual Color adjustment: Drag the slide bar to adjust Brightness, Contrast, Hue, and Saturation. Click Default to reset them to original value. Description Buttons Drag the scroll bar to adjust the brightness of channel Drag the scroll bar to adjust the contrast of channel Drag the scroll bar to adjust the saturation of channel Drag the scroll bar to adjust the hue of channel Click this button to recover the default value of brightness, contrast, saturation and hue.
  • Page 81 Digital Video Recorder User Manual 'Zoom' button. Click button near 'Zoom' button to zoom in the locale picture of this camera. Click button near 'Zoom' button to zoom out the locale picture of this camera. 'Focus' button. Click button near 'Focus' button to have long focus. Click button near 'Focus' button to have short focus.

  • Page 82: Remote Playback & Backup

    Digital Video Recorder User Manual 7.3 Remote playback & backup 7.3.1 Remote playback Click button to enter into record playback interface, refer to Fig 7-7: Select the record date and channels; double-click the file name in the record file list box, user can play that file and preview the picture. alarm shop Fig 7-7 Play record file interface...
  • Page 83 Digital Video Recorder User Manual This DVR supports remote time search, event search and file management. By Time Search: Step1: Enter into Search time search; refer to Fig 7-8: alarm shop Fig 7-8 time search interface Step2: click “Search” button. The record data will be displayed in the data information list box; the highlight date in the area② means have record...
  • Page 84 Digital Video Recorder User Manual data, click those data; select the record channels in area③ Step3: User can set the data playing time and display mode in the area① as required Step4: Select certain item from the data information list box, click “play” button to playback Step5: Click the relevant buttons in the interface;...
  • Page 85 Digital Video Recorder User Manual By Event Search: Step1: Enter into Search event search; refer to Fig 7-10: alarm shop Fig 7-10 event search interface Step2: click the highlight date and select record channels and then tick off the event type: motion and sensor, click “search” button Step3: the events will be display in the event list box, double-click certain item to playback File Management Step1: Enter into Search file management;...
  • Page 86 Digital Video Recorder User Manual alarm shop Fig 7-11 file management interface Lock: select certain file item in the file list box, click “Lock” button to lock this file that ca not be deleted or overlaid Unlock: select a locked file, click “unlock” button to unlock this file Delete: select an unlock file, click “delete”...

  • Page 87: Remote Backup

    Digital Video Recorder User Manual 7.3.2 Remote backup Click Backup button to enter into backup interface, refers to Fig 7-12: alarm shop Fig 7-12 remote backup interface Step1: select channels, set the start and end time, then click “search’ button, the file information will be displayed in the file list box Step2: select backup files, click “browse”...

  • Page 88: Remote System Configuration

    Digital Video Recorder User Manual 7.4 Remote System configuration User can remote setup the parameters of the device. Functions of remote configurations include: basic configuration, live configuration, record configuration, schedule configuration, alarm configuration, network configuration, PTZ configuration and user configuration. User should firstly select an item in the menu list on the left, and then setup the relative parameters.

  • Page 89: Mobile Surveillance

    Digital Video Recorder User Manual Mobile Surveillance This DVR supports mobile surveillance by Iphone, Gphone or smart phones with WinCE and symbian OS. At the same time, it supports 3G network. We tested Dopod D600 (WM5) and Dopod S1 (WM6), which work fine with the DVR. It wants to make mobile surveillance, need first enable network service on the DVR, and refer to Chapter 4.6 Network configuration.
  • Page 90 Digital Video Recorder User Manual alarm shop Step3： ： ： ： Click “Yes” to start downloading and installing: Step4： ： ： ： PCam will be opened automatically after installed...
  • Page 91 Digital Video Recorder User Manual Step5： Input the server’s address, ID and password respectively in the columns of “Server”, “User” and “Password”, and click “Go” to log on the server. It will show the picture if access successfully. alarm shop Step6：...

  • Page 92: By Phones With Symbian

    Digital Video Recorder User Manual 8.2 By Phones with Symbian Please use the smart phones with symbian version supported by this unit. Step1： Firstly enable the network access on mobile phone. Then run Web browser. Step2： Input the DVR server’s IP address in a new-built bookmark. Click this bookmark to connect to the DVR. alarm shop Step3：...
  • Page 93 Digital Video Recorder User Manual Live view: to do mobile live view Image view: to check the pictures snapped in live view System setting: Login setting and Alarm setting. Help: function indication and help alarm shop Step7： Click System setting--->Login Setting to enter login interface.
  • Page 94 Digital Video Recorder User Manual Step8： Input the server’s address, ID and password respectively. Then save. Notice: About Access point, there may be different access points in different countries or from service providers. Step9： Enter Live View, it will connect the server and display pictures. alarm shop Notice: User name and password here are the same with that used on the DVR.

  • Page 95: The Operation Method For Iphone Mobile Clients

    Digital Video Recorder User Manual 8.3 The operation method for iPhone mobile clients At present, the software only supports version of iPhone os2.2 and above, if phone firmware lower than this version please upgrade it. Below is the operation method for iPhone mobile clients: Step1：Enter into App Store function of iPhone alarm shop function to search “SuperCam”, the required programs will be displayed on the top of search box...
  • Page 96 Digital Video Recorder User Manual Step 3: Click SuperCam, enter into “introduce” interface and click FREE”, it will change into “INSTALL” alarm shop Step 4: Enter into iTunes Store password, click “OK”will display below interface Note: if it was the first time for user to operate please enter into user ID; if there is no Store account, user need to apply one. Step 5: Just be patient to download and install.
  • Page 97 Digital Video Recorder User Manual alarm shop Step 6: Click “System setting”, enter into login interface. Enter into server’s IP address (or domain name), user’s ID and password. Click Back to save. Step 7: Click Live View, the default Cam1 picture will be displayed. Click to capture picture.
  • Page 98 Digital Video Recorder User Manual alarm shop Step 8: On function interface, click Image View to view the captured picture. Click to switch to next or previous picture. Click delete the current picture. Iphone help...
  • Page 99 Digital Video Recorder User Manual alarm shop Pic1 Pic2 Pic3 Live View After successfully installed SuperCam software, Click on System Setting (Pic 1), and then input Server IP address or Domain, User name and password to log in (Pic 2). If connected successfully, it will go to Live View of CH1 as default (Pic 3), please choose other desired channels from channel button underneath.
  • Page 100 Digital Video Recorder User Manual Image View alarm shop Pic 4 Pic 5 Item Buttons Explanations Item Buttons Explanations Item Buttons Explanations Previous picture Next Picture The first Picture The last picture Delete Search Pictures, search page as Pic 5...

  • Page 101: Appendix A Faq

    Digital Video Recorder User Manual Appendix A Q1. Why the DVR cannot start after connected to the power? a. The adapter has been damaged. Please change an adapter b. The power of the adapter is not enough. Please remove the HDD to check c.
  • Page 102 Digital Video Recorder User Manual Q5. Cannot record a. Don't format HDD. Please format it manually first. b. Don't enable record function or incorrect setup. Please refer to Chapter 5 Record search & playback and backup. c. HDD is full and not enables recycle function. Please refer to 4.3 Record configuration. Chang a new HDD or enable recycle. d.
  • Page 103 Digital Video Recorder User Manual ③ Enable all the sub options under “ActiveX controls and plug-ins” refer to Fig 7-2 ④ Then click ok to finish setup. b. Other plug-ins or anti-virus block activeX. Please uninstall or close them. alarm shop Fig7-1 Fig7-2 Q8: How to deal with when DVR starts, it displays “please wait…”all the time...
  • Page 104 Digital Video Recorder User Manual Second possible reason: It is forced to stop because hard disk has disabled track which causes the system checking hard disk cannot skip Solution: Change another new hard disk or reformat the broken one Q9: How to input password and digital numbers The method to input password and digital numbers is to click the box behind password or items needing to input by numbers, and then the small keyboard will appear.
  • Page 105 Digital Video Recorder User Manual Motherboard Intel 845 512M NVIDIA GeForce MX440/FX5200 ATIRADEON 7500/X300 Windows 2000(SP4 above) /Windows XP(SP2 above) /VISTA DirectX Q13: What are the PC configurations for 16-ch real time product with fully open channel mainstream? alarm shop PC Module Parameters Intel Core(TM)2 Duo CPU E4600...

  • Page 106: Appendix B Calculate Recording Capacity

    Digital Video Recorder User Manual Appendix B Calculate Recording Capacity Users can calculate the size of hard disk according to the saving time and DVR recording settings. The DVR uses fixed video bit rate. The below are the details at different settings. Frame Rate Video Format...

  • Page 107: Appendix C Compatible Devices

    Digital Video Recorder User Manual Appendix C Compatible Devices 1. Compatible USB drive after test. Brand Capacity 512MB, 1G, 2GB Netac Kingston Aigo alarm shop Smatter vider SanDisk Tab C.1 Compatible USB drive 2. Compatible SATA CD/DVD writers after test Brand Model TECLAST...

  • Page 108: Appendix D 4-Ch Dvr Specifications

    Digital Video Recorder User Manual Appendix D 4-CH Specifications Compression format Standard H.264 Baseline Composite：1.0V p-p/75 ，BNC×2 , VGAX1 Video output Composite：1.0V p-p/75 ，BNC×4 Video input VGA Resolution 1280*1024 /1024*768/ 800*600 Record Resolution 352*288/704*576 (PAL), 352*240/704*480(NTSC) Display Frame Rate 100FPS (PAL), 120FPS (NTSC) Record Frame Rate 100FPS (PAL),...

  • Page 109: Appendix E 8-Ch Dvr Specifications

    Digital Video Recorder User Manual Appendix E 8-CH Specifications Compression format Standard H.264 Baseline Composite：1.0V p-p/75 ，BNC×2 , VGAX1 Video output Composite：1.0V p-p/75 ，BNC×8 Video input VGA Resolution 1280*1024 /1024*768/ 800*600 Record Resolution 352*288/704*576 (PAL), 352*240/704*480(NTSC) Display Frame Rate 200FPS (PAL), 240FPS (NTSC) Record Frame Rate 200FPS (PAL),...

  • Page 110: Appendix F 16-Ch Dvr Specifications

    Digital Video Recorder User Manual Appendix F 16-CH Specifications Compression format Standard H.264 Baseline Composite：1.0V p-p/75 ，BNC×2, VGAX1 Video output Composite：1.0V p-p/75 ，BNC×16 Video input VGA Resolution 1280*1024 /1024*768/ 800*600 Record Resolution 352*288/704*576 (PAL), 352*240/704*480(NTSC) Display Frame Rate 400FPS (PAL), 480FPS (NTSC) Record Frame Rate 400FPS (PAL),...
