Polarstart PS-5565TW Installation Instructions Manual

Automatic transmission two-way remote starter & alarm system with built-in pager

Hide thumbs

Table of Contents

Quick Links

Download this manual

Table of Contents.....................................

Introduction...........................................

What's included?.....................................

Before you get Started...............................

Installation Points to Remember...................

PS-5565TW Features...............................

Programmable Features..............................

Harness Description...................................

Wiring Schematic.....................................

IGN / ACC / CRANK relay output. .............

Programming transmitter............................

Transmitter functions.................................

Valet operation........................................

TACH learning....................................

NOTICE:

THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY ELECTRICAL OR MECHANICAL DAMAGE TO

THE VEHICLE OR TO THE UNIT DUE TO IMPROPER INSTALLATION OF THE PRODUCT.

THIS UNIT MUST BE INSTALLED BY AN AUTHORIZED POLARSTART TRAINED TECHNICIAN USING ALL

SAFETY DEVICES SUPPLIED. Please review the installation guide carefully before any work begins.

WARNING

THIS UNIT IS FOR MANUAL TRANSMISSIONS ONLY.

Rev.2.10 La - 10/12/01 + Bulletin Nov/27/01 Manufactured in Canada by POLARSTART

POLARSTART

PS-5565TW

Automatic Transmission Two-Way remote

starter & alarm system with built-in pager

Installation Guide

Table of Contents

P.1

P.2

P.3

P.4

P.5

P.6

P.8

P.9

P.10

P.11

Programming options.................................

Ready Mode.......................................

Clutch bypassing....................................

Parking brake wire.................................

Secure lock..........................................

Starter disable.....................................

Ground output....................................

Multi-car operation...............................

Resetting the module............................

Vehicle status request..................................

Diagnostic light flashes.........................

Testing.............................................

Closing up.........................................

Warranty...........................................

P.12

P.14

P.15

P.16

P.17

P.18

Table of Contents

Need help?

Do you have a question about the PS-5565TW and is the answer not in the manual?

Questions and answers

Summary of Contents for Polarstart PS-5565TW

Page 1: Table Of Contents
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY ELECTRICAL OR MECHANICAL DAMAGE TO THE VEHICLE OR TO THE UNIT DUE TO IMPROPER INSTALLATION OF THE PRODUCT. THIS UNIT MUST BE INSTALLED BY AN AUTHORIZED POLARSTART TRAINED TECHNICIAN USING ALL SAFETY DEVICES SUPPLIED. Please review the installation guide carefully before any work begins.
Page 2: Introduction
With the addition of over 15 new features, this product will satisfy any demand for high-end systems, and standard features. After installing the system, we hope you too will agree that the new PS-5565TW is a breakthrough in vehicle convenience technology, and remote starter systems.
Page 3: Before You Get Started
BEFORE YOU GET STARTED… WARNING! This unit is for MANUAL TRANSMISSIONS ONLY! FCC USER NOTICE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. INSTALLATION POINTS TO REMEMBER •...
Page 4: Ps-5565Tw Features
5 BUTTON, 15 CHANNEL REMOTE TRANSCEIVER • INDEPENDENT ARM / DISARM WIRES • OEM HORN CONTROL. ** • MULTI-CAR OPERATION (Can control 2 separate Polarstart equipped cars.) • PLUG IN VALET SWITCH AND L.E.D. • DIAGNOSTICS VIA PARKING LIGHTS •...
Page 5: Programmable Features
DISARM/UNLOCK systems i.e.: Maxima, Pathfinder, and Volks…) • REMOTE START RUN TIME The PS-5565TW can be programmed to run the engine for 4 / 15 / 25 minutes. Standard default run time is 15 minutes in Gas mode, and 20 minutes in Diesel mode. •...
Page 6: Harness Description
HARNESS DESCRIPTION 5 PIN MAIN IGNITION HARNESS WIRE Wire color Function Description +12 VOLT Connect to the largest 12-volt supply wire at the IGNITION harness. Ensure that the OEM power wire is fused greater than 25 BATTERY amps. YELLOW 30 AMP Connect to vehicle’s IGNITION wire.
Page 7 11 PIN-ACCESSORIES HARNESS Wire Wire color Function Description BROWN LOCK (-) Programmable 500 mA. ¾ sec – 4 sec – or DBL pulse negative output. Programmable 500 mA. ¾ sec – 4 sec – or DBL pulse negative GREEN UNLOCK (-) output.
Page 8 TECHNICAL BULLETIN for the PS-5565 TW (LA - Nov.27, 2001) There is a mistake in the wiring diagram of the installation manual: Wire no.17 is actually to be connected to the Parking Brake wire; it is not an External Trigger. This is the correct wiring diagram for the PS-5565 TW: the earlier heading of wire no.17 "EXTERNAL TRIGGER"...
Page 9: Nd Ign / Acc / Crank Relay Output
PROGRAMMING A TRANSMITTER The PS-5565TW transmitter does not come pre-programmed and must be code learned after the wiring of the module is complete. The system has the ability to learn up to 4 different transmitters, if a fifth transmitter is learned the first transmitter in memory will be lost.
Page 10: Transmitter Functions
TRANSMITTER FUNCTIONS Information Panel will flash command confirmation with a corresponding Beep and light flash LOCK (ALARM ARM) REMOTE ENGINE STOP Cold weather timer ON. UNLOCK (ALARM DISARM) Remote Engine START TRUNK release (SILENT ARM) VALET OPERATION REMOTE STARTER VALET MODE The system can be placed in Remote Starter Valet Mode.
Page 11: Tach Learning
AUTO TACH LEARNING The PS-5565TW system is equipped with an auto-learn procedure that will tell you if you have the correct TACH wire. § TACH adjustment procedures should be done every time a new unit is installed. This is because the TACH signal from some IGNITION systems can sometimes be too high or too low, thus causing failed starts under different temperatures.
Page 12: Programming Options
PROGRAMMING OPTIONS The PS-5565TW System is equipped with 2 custom programming menus that allow the user to custom fit the system’s outputs according to the installation requirements. These options are designed to help make interfacing with all vehicles possible. To get into custom programming mode you must do the following: * Ensure that the IGNITION and the VALET switch are turned OFF .
Page 13 FUNCTION 5 – Door Lock Timing OPTION 1* 3/4 second LOCK / UNLOCK pulses. OPTION 2 4 second LOCK / UNLOCK pulses. OPTION 3 Single ¾ second LOCK pulse, and TWO - ¼ second UNLOCK pulses. FUNCTION 6 – Siren / OEM Horn Control OPTION 1* Siren Mode - ENABLED OPTION 2...
Page 14: Ready Mode
SETTING THE UNIT INTO READY MODE This UNIT is designed for MANUAL transmission only, therefore must be set into READY-MODE in order to remote start the vehicle. If the system is not in READY-MODE the vehicle CANNOT be started by remote. Once the system has been set into READY-MODE the vehicle can be started and stopped as many times as you wish, however should the DOORS / HOOD or TRUNK be opened without the vehicle running under remote start, the system will exit READY-MODE.
Page 15: Secure Lock
It can be used to activate external relays, bypass kits or external module. MULTI-CAR OPERATION The PS-5565TW systems feature Multi-Car operation. This allows the owner of two Polarstart systems in two of his/her vehicles to control both systems with one transmitter (Both vehicles must be equipped with an PS-5565TW).
Page 16: Resetting The Module
RESETTING THE MODULE The PS-5565TW system is equipped with a reset function that allows the installer to erase all transmitter codes and return all programmed options to factory default. To reset the module: NOTE: System flashes PARKING LIGHTS 8 times upon reset.
Page 17: Testing
DIAGNOSTICS - PARKING LIGHTS FLASH RATE FLASHES RATE DESCRIPTION Alarm system armed and doors locked OR end of run time OR run time canceled Quick OR trunk open OR cancelled cold weather OR cannot start after maximum attempts of tries. Quick Alarm disarmed and doors unlocked.
Page 18: Warranty
Polarstart will replace the remote starter module free of charge with a new remote starter module. 2) For the second year after date of manufacture, as specified by the serial number on the module, Polarstart will replace the remote starter module free of charge with a repaired or refurbished remote starter module.
