Sun Power XP Series Owner's Manual

Hide thumbs Also See for XP Series:
Table of Contents

Advertisement

Quick Links

Save Power
with
Sun-Power
Australian made XP Series Automatic Gate Operators
Smart & Green Auto Gate Operators
Installation Guide & Owner's Manual
Please DO NOT attempt installation
without reading
then following this manual
&
Take your time - Read the Manual - Get it right – Enjoy the benefits
Technical support is available if, after having read these instructions, you require assistance
This Instruction Booklet/Owner's Manual, should be retained by Gate owner for future reference.
Further copies are available on our web site
Sun-Power Auto Gates
129 Gladstone Street, Fyshwick ACT 2609
Ph: 02-6280 4655 02-6280 4783 Fax: 02-6280 7592
email
.sungate@bigpond.net.au
www.sungateaustralia.net
This Manual is available on the website
©
V07-2014
Page 1 of 24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XP Series and is the answer not in the manual?

Questions and answers

Related Manuals for Sun Power XP Series

Summary of Contents for Sun Power XP Series

  • Page 1 Save Power with Sun-Power Australian made XP Series Automatic Gate Operators Smart & Green Auto Gate Operators Installation Guide & Owner’s Manual Please DO NOT attempt installation without reading then following this manual & Take your time - Read the Manual - Get it right – Enjoy the benefits Technical support is available if, after having read these instructions, you require assistance This Instruction Booklet/Owner’s Manual, should be retained by Gate owner for future reference.

  • Page 2: Table Of Contents

    Contents: Dear Installer/Owner 3 - 4 Introduction 3 - 4 Warning re wiring changes Installation Standard Installation Install Radio receiver & Antenna When to connect POWER Installation Procedure 5 - 10 Adjusting Limit Switches Side Mount Installation 10 - 11 Restricted side room 11 - 12 Out-swing Installation...

  • Page 3: Dear Installer/Owner

    You simply have to connect up the external devices such as Radio Receiver, Solar Panel, Antenna, Push buttons etc. The design features, in the SUN-POWER XP Series Gate Operators, will save you time on site, and the installation will be neat & tidy.

  • Page 4: Installation

    * XP Series Gate operators will drive a variety of Gate Styles, Sizes & Weights. Suitability is dependent on the quality of hinging and the force required at One Metre from the hinge center-point to open and close the gate, 15 Kg is the maximum for gates opening IN [PULL] and 7.5 Kg for gates opening OUT [PUSH]...

  • Page 5: Installation Procedure

    Fig 1. Standard Installation: *Where the distance is greater than 200mm the Secondary arm may need to be extended, contact Sun-Power if you need assistance. Refer page 10 if restricted side room Ensure that the gates swing freely and that all existing latches/padbolts/Chains etc are disabled or removed from the gate &...
  • Page 6 INSTALLING THE RADIO RECEIVER: Step 1. Ensure that Positive lead [RED] is disconnected and away from the Battery Positive terminal Step 2. Ensure Solar Panel [or Mains power] is NOT Connected to the Gate operator Step 3. Line up the ports on the radio receiver [Rx] with the 6 PRONGS on the Main circuit board - now slide the Radio Receiver [Rx] fully onto the 6 prongs at the bottom end of the main circuit board.
  • Page 7 4. If you have a Pair of Gates then………. Connect the Slave to the Master Unit with 2 Core Flex-Cable [Max load draw 8 Amp at 12 Volts] [Fig.8 cable - 75mm sq – 24/.020 minimum] Refer Fig. 3 All cabling must not be run in conjunction with any high voltage cables or electric fencing – if in doubt, seek advice from a qualified Electrician in Your State or Territory.
  • Page 8 © The XP Operators are set in the factory for a “Standard PULL Installation” When the Master Operator is placed on the LEFT HAND SIDE the wiring [from the inside [motor side] – looking out] Brown above Blue [ref. P. 15 - 16] When the Master Operator is located on the RIGHT HAND SIDE [ motor side - from the inside–...
  • Page 9 © Connect power [12v or 240v or Solar] to the Master Operator and connect the Battery 7. The Limit Switches may now be adjusted [If necessary] [See figure 5.] Each of the Master and Slave Operators has its own pair of cams, one to set the open position & one to set the closed position.

  • Page 10: Side Mount Installation

    Side Mount Installation: The XP Operator may be mounted sideways, with the long side against the Pier/Post, for extra flexibility. This feature is very useful for situations where … [Ref. P 10. Fig. 6]  The Gate must swing further than 90 degrees ...
  • Page 11 Restricted/Limited Side Room Installation - Continued: © Mark a point on the gate suitable for the gate bracket. Holding the gate bracket in position, measure the distance between the hole centers on the gate bracket & Primary arm. iii. Now move the primary arm to its maximum open position. Open the gate & measure the distance again [See figure 8].

  • Page 12: Out-Swing Installation

    Several factors must be considered to determine the most suitable arm length. These include  The drive through width required - The Placement of the XP Gate Operator - The location of the gate on the Post/Pier/Pillar . Direct support is available from SUN-POWER in these situations.
  • Page 13 Settings: Important: ALL adjustments to TRIM POTS/Dials must be done slowly and carefully with a correctly sized flat-blade screwdriver or Trim pot adjusting Tool Auto Close The Operator Control Board is supplied with a “JUMPER” installed on a 3 PIN Block. This allows the gate to automatically close after a specific period.

  • Page 14: Trim Pots - Settings

    XP Series Auto Gate Operator Trim Pots: Settings, locations and functions There are Six adjustable [6] Trim Pots 1. R 1 Auto Close: Clockwise = Minimum time 2. R 2 Motor 1 Auto reverse: Clockwise = Less power 3. R 8 Motor 2 Auto reverse: Clockwise = Less power 4.
  • Page 15 WARNING! fghfcxh 240v Wiring Diagram ONLY For Solar operator, refer to Solar Wiring Diagram Travel time clockwise = minimum time 3 pin block. Jumper on 1 & 2 = Auto Close Jumper on 2 & 3 = Manual Close Standard installation BLUE/BROWN polarity Standard installation Refer P.5 –...
  • Page 16 WARNING! SOLAR Wiring Diagram ONLY For 240v operator, refer to 240v Wiring Diagram Travel time clockwise = minimum time 3 pin block. Jumper on 1 & 2 = Auto Close Jumper on 2 & 3 = Manual Close Standard installation Standard installation BLUE/BROWN polarity BLUE/BROWN polarity...

  • Page 17: Sequence

    Sun-Power XP Circuit Board L.E.D Light Sequence XP Auto Gate Operators are fully factory tested [before shipping] to work as below. LED’s are located as follows [Refer to drawing below for approximate locations]  YELLOW – ‘travel time’ LED – top right hand of the board [Adjustable Ref.

  • Page 18: Anti-Clash Leaf Delay

    Anti – Clash Leaf Delay for Pairs of Gates. To avoid jamming there is a time delay between the movement of each gate. This delay may be independently adjusted for the Opening sequence & the Closing sequence. LEFT HAND Installations [Master Operator on the Left] - Dial “R 24” changes the Closing delay & “R 27”...

  • Page 19: Solar Wiring Detail

    100 Metres from Gate Operator using 6mm Fig.8 Cable [T/S 2 x 65/0.30]. All Sun-Power Auto Gate Operator Kits [Solar, 240v and 12v] are supplied complete with 9 Amp Hour SLA Battery. This battery should be checked regularly. Instructions for changing battery - refer Page 4 Quality 9 AH Batteries are available from Sun-Power and from most reputable battery suppliers.

  • Page 20: Electric Lock [El]

    Photoelectric safety beams can supplied for use with the XP Solar Gate Operator [but not when used with electric lock] please contact us if you require this [This is a Pre-Install application] Connecting the 433 mhz antenna The Sun-Power standard Radio Receiver [SP Rx 30 Plug-on] [Standard as from Jan 2009] is Piggy backed onto the Main Circuit Board it is located on the front Right hand corner.

  • Page 21: Trouble Shooting

    Other faults may be due to incorrect settings. Refer to “Settings” section on Page 13 of this manual to ensure all the settings are correct. All Sun-Power XP Gate Operators include a battery, check battery regularly Low battery power a. Re-charge battery. Check battery quality and replace if necessary.
  • Page 22 SP50DK Radio Keypad Factory default setting: Pin code 1: 1234 Pin code 2: 5678 Learning to receiver: 1. Enter the 4 digit pin number. (default PIN or your new pin if changed) 2. Then press and release the learn button on the receiver and red LED will come on. 3.
  • Page 23 Important: Holding down Program Button [Centre top] on Radio receiver Rx 30 will delete all previous coding Programming Sun-Power SP Tx 10 - 4 Channel radio transmitters to Sun-Power SP Rx 30 Plug-on radio receiver. Click and release the Program Button [the round black button on Radio Receiver [Rx30] - a red light should appear, then immediately Press &...
  • Page 24 Specifications & Freight Dimensions Sun-Power XP Series Auto Gate Operators Chassis & Case 245mm High x 140mm Wide x 335mm Deep Primary arm. Pivot centres 540 mm Secondary arm. Pivot centres 545mm Sizes & Weights of various Kits: XP 100 Single Kit 1 Ctn.
