P R E S E T M O D E 3 :
T O U C H S E N S I T I V E O V E R D R I V E
Gives a touch responsive, huge amp-like overdrive
that stays true to your guitars tone and cleans up
nicely with playing dynamics.
Mode: Drive, Harmonic Drive Switch Down
Function: Single Pedal: Boost Switch stays on, use
the bypass switch to engage and bypass the
overdrive pedal.
1. Put the pedal into drive mode via the
HARMONIC DRIVE ON/OFF
2. Max out the INPUT VOLUME
3. Max out the BOOST GAIN
4. Max out the DRIVE MIX KNOB
5. Dial back OUTPUT VOLUME
6. Use the BYPASS SWITCH
the overdrive pedal while leaving the Boost on
1 6 | P R E D R I V E U S E R M A N U A L
mini toggle
as needed
to bypass or activate
4
5
1
3
P E T T Y J O H N E L E C T R O N I C S . C O M
2
6
