Microsens Entry Line Ethernet VDSL2 Extender Manual

Entry Line
Ethernet VDSL2 Extender –
Manual
Introduce
The Industrial Ethernet to VDSL2 extender is long reach Ethernet module with one
Ethernet port (RJ-45 connector) and one VDSL port (RJ-45 connector). It provides
Ethernet and VDSL technologies to extend Ethernet over single-pair phone line by
using a VDSL signal. Up to 88/49 Mbps transition bandwidth within 200m and 22/5.3
Mbps for 1km long range connections provides ultra-high performance to the pervasive
telephone line network. It has the advantage of minimum installation time and
minimum expense by allowing video streaming and data to share the same telephone
pair without interference.
Features
Standard
ITU-T
LED Indicators
Connector
DIP Switch
Cabling
MICROSENS GmbH & Co. KG - Kueferstraße 16 - 59067 Hamm / Germany - Tel. +49 23 81/94 52-0 - FAX -100 - www.microsens.com
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
ITU-T
-G.993.1(VDSL)
-G.997.1 compatible
Per unit: Power1, Power2, P-Fail
LAN port: LNK/ACT, SPD
VDSL port: LNK/ACT, CO
10/100TX: 1 x RJ-45 with auto MDI/MDI-X function.
VDSL: 1 x RJ-45 with female Phone Jack
DIP1: Master, Slave switch
DIP2: Impulse noise protection
DIP3: Rate limit control
DIP4: General protection
10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable EIA/TIA-568
100-ohm (100m)
100Base-TX: 2-pair UTP/STP Cat. 5 cable EIA/TIA-568 100-
ohm (100m)
VDSL: Twisted-pair telephone
