Aqua Cycle Plus Owner's Manual

*Boat Specifications*
Original Aqua Cycle (pictured on the front) 12" pontoons
Length: 10'2" Height" 44"
Aqua Cycle Plus
15" pontoons
Width: 70" Length: 13'
Height: 47" Weight: 284 lbs.
Capacity: 800 lbs.
Aqua Cycle 4 x 4
15" pontoons
Width: 70" Length: 13'
Height: 47" Weight: 286 lbs.
Capacity: 800 lbs.
Width: 64"
Weight: 155 lbs. Capacity: 400 lbs.
Aqua Cycle II
15" pontoons
Width: 70" Length: 13'
Height: 47" Weight: 286 lbs.
Capacity: 800 lbs.
Aqua Cycle 15
15" pontoons
Width: 70" Length: 10' 6"
Height: 47" Weight: 200 lbs.
Capacity: 550 lbs.
Owner's Manual
*CARE OF YOUR AQUA CYCLE*
Your paddleboat will give you many years of enjoyment with a minimum of
care. Just follow these directions. Questions? Contact us, we'd be pleased to
help.
Your Aqua Cycle serial number is stamped into the aluminum on the back of
the boat, on the right side of the rear cross member, just above the pontoon.
*LUBRICATION*
Bearings Add 2 to 3 drops of a good lubricating oil (30 weight or higher motor
oil) to each oil cup (total of 6) at the beginning of each boating season and again
approximately every 6 weeks of use.
Pedals Lubricate as required by centering pedals on crank and plac-
ing a small amount of oil on the crank next to the pedals on both sides. Rotate
the pedals over the oil to work lubrication under the pedals. Remove excess oil.
