Itona Md75 with VESA Dock and Power Adapter Cradle

Installation Manual

Itona Md75 with VESA Dock and
Power Adapter Cradle
1
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Itona Md75 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vxl Itona Md75

Summary of Contents for Vxl Itona Md75

  • Page 1: Installation Manual

    Itona Md75 with VESA Dock and Power Adapter Cradle Installation Manual Itona Md75 with VESA Dock and Power Adapter Cradle...

  • Page 2: Revision History

    Itona Md75 with VESA Dock and Power Adapter Cradle Revision History Rev no. Change Details Created by Date Krishna Raju N.R Included new chapters to set up the client May 14 Gokul Anand Included monitor connection methods. May 14 Krishna Raju N.R Included product front view.

  • Page 3: Unpack The Product

    Itona Md75 with VESA Dock and Power Adapter Cradle Unpack the Product 1. Product Packaging Carton 2. Accessory Box 1. Cut open the top side of the carton. 2. Remove the accessory box from the carton. Dispose off Silica gel sachet.
  • Page 4 Itona Md75 with VESA Dock and Power Adapter Cradle Identify the Parts in the Package 1. Monitor Side VESA Dock 2. Md75 thin client with VESA dock and power adapter. 3. Stand Side VESA Dock 4. Wall Inserts (4 Nos.) 5.
  • Page 5 Itona Md75 with VESA Dock and Power Adapter Cradle Disassembly 1. Unscrew the captive screw holding the Stand Side VESA dock. 2. Slide and remove the Stand Side VESA dock. 3. Reverse the thin client to remove the Monitor Side VESA dock.
  • Page 6 Itona Md75 with VESA Dock and Power Adapter Cradle 1. Unscrew the captive screw holding the Monitor Side VESA dock. 2. Slide and remove the Monitor Side VESA dock. Note: Do not remove the Monitor Side VESA dock if you do not intend to mount the client on a wall...
  • Page 7 Itona Md75 with VESA Dock and Power Adapter Cradle Methods of Mounting Method 1: Hanging on Wall / Fixing on the Wall Method 2: Mounting on a Wall Stand...
  • Page 8 Itona Md75 with VESA Dock and Power Adapter Cradle Hanging on the Wall/Fixing on the Wall Drill 4 holes as per center to center dimensions and details given below. 100mm 100mm 100mm Fixing on the Wall Hanging on the wall •...
  • Page 9 Itona Md75 with VESA Dock and Power Adapter Cradle Fix the M4 screws to the wall as shown in the following image. Wall Wall Insert M4x35 Screw 2 to 3mm...
  • Page 10 Itona Md75 with VESA Dock and Power Adapter Cradle Method 1 Hanging on the Wall Using M4x35 wood screws, hang the Stand Side VESA dock on the wall as shown in the following figure.
  • Page 11 Itona Md75 with VESA Dock and Power Adapter Cradle Fixing on the Wall Using M4x35 wood screws, hang the Stand Side VESA dock on the wall as shown in the following figure.
  • Page 12 Itona Md75 with VESA Dock and Power Adapter Cradle Correct Wall Side Dock Orientation Incorrect Wall Side Dock Orientation...
  • Page 13 Itona Md75 with VESA Dock and Power Adapter Cradle 1. Slide and fix the client to the Stand Side VESA dock as shown in the following figure. 2. Tighten the captive screw to fit the client in place..
  • Page 14 Itona Md75 with VESA Dock and Power Adapter Cradle Connect the necessary cables. DVI-I to VGA +DVI Splitter Cable...
  • Page 15 Itona Md75 with VESA Dock and Power Adapter Cradle Method 2: Mounting on a Wall Stand Preparing the Monitor Using M4 screw, fix the Monitor Side VESA dock behind the monitor.
  • Page 16 Itona Md75 with VESA Dock and Power Adapter Cradle Correct MonitorSide Dock Orientation Incorrect Monitor Side Dock Orientation...
  • Page 17 Itona Md75 with VESA Dock and Power Adapter Cradle Preparing the Wall Stand Fix the Stand Side VESA Dock using the M4 screws as show in the following image. Note: Ensure that the Sliding guide is at the top.
  • Page 18 Itona Md75 with VESA Dock and Power Adapter Cradle Correct Stand Side Dock Orientation Incorrect Stand Side Dock Orientation...
  • Page 19 Itona Md75 with VESA Dock and Power Adapter Cradle 1. Slide and fix the client to the Stand Side VESA dock as shown in the following figure. 2. Tighten the captive screw to fit the client in place..
  • Page 20 Itona Md75 with VESA Dock and Power Adapter Cradle Slide the Monitor assembly into the VESA Dock on the Thin Client and fasten using the Captive Screw.
  • Page 21 Itona Md75 with VESA Dock and Power Adapter Cradle Connect the necessary cables. Side view after installation.
  • Page 22 Itona Md75 with VESA Dock and Power Adapter Cradle Instructions to Connect Dual Monitor To connect two analog (VGA) monitors DVI-I to VGA + DVI "Splitter cable" (Supplied along with Md75)
  • Page 23 Itona Md75 with VESA Dock and Power Adapter Cradle To connect one analog (VGA) monitor and one digital (DVI) monitor DVI-I to VGA + DVI "Splitter cable" (Supplied along with Md75)
  • Page 24 Itona Md75 with VESA Dock and Power Adapter Cradle Do not connect this way.
  • Page 25 Itona Md75 with VESA Dock and Power Adapter Cradle Instructions to Connect Single Monitor To connect one analog (VGA) monitor (option 1)
  • Page 26 Itona Md75 with VESA Dock and Power Adapter Cradle To connect one analog (VGA) monitor (option 2) DVI-I to VGA + DVI "Splitter cable" (Supplied along with Md75)
  • Page 27 Itona Md75 with VESA Dock and Power Adapter Cradle To connect one digital (DVI) monitor...

  • Page 28: Replacing The Power Adapter

    Itona Md75 with VESA Dock and Power Adapter Cradle Replacing the Power Adapter 1. Unplug the power cord and power adapter cable. 2. Unscrew the power adapter cradle thumb screw. 3. Remove the power adapter from the cradle. 4. Place the new power adapter into the cradle with proper cable routing using cable tie as shown below.
  • Page 29 Itona Md75 with VESA Dock and Power Adapter Cradle Thank You...
