Masterpiece Technology PDT-1000W User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Copyright
@ 2009 Masterpiece Technology (International) Co., Ltd. All rights reserved. Masterpiece Technology
(International) Co., Ltd. retain the right to make changes to this manual at any time without notice.
Without Masterpiece Technology (International) Co., Ltd written permission shall not be reproduced in
any form, of any part of the dissemination of this manual. This manual has been validated and reviewed
for any loss caused by errors, omissions or discrepancies between the manual and product, Masterpiece
Technology (International) Co., Ltd. does not assume any liability.
Trade Marks
All company and product names mentioned in this manual are the legitimate rights and interests of
people who hold trademarks or registered trademarks.
FCC Class B Information
Has been tested in accordance with Part 15 of the FCC regulations, the products comply with the
provisions of the Class B digital device. These provisions are intended for the installation of the product,
to provide reasonable protection against harmful interference. This equipment generates, uses and can
User Manual
PDT-1000W Series
Vesion： V 1.20
Type No.： PDT-1000W-A0/A2 Series
Date：

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PDT-1000W and is the answer not in the manual?

Questions and answers

Summary of Contents for Masterpiece Technology PDT-1000W

  • Page 1 (International) Co., Ltd. retain the right to make changes to this manual at any time without notice. Without Masterpiece Technology (International) Co., Ltd written permission shall not be reproduced in any form, of any part of the dissemination of this manual. This manual has been validated and reviewed for any loss caused by errors, omissions or discrepancies between the manual and product, Masterpiece Technology (International) Co., Ltd.

  • Page 2: How To Get Help

    radiate radio waves, if not properly installed, used, would cause harmful interference to radio communications. However, it does not guarantee that a particular installation will not cause harmful interference. If the products cause harmful interference to radio and TV signals acceptance (by opening and closing of this product can be determined), the user can try to use the following method to resolve: Readjust or relocate the receiving antenna To increase the distance between the disturbed equipment...
  • Page 3 Liquid enter inside of this product e) Power cable or plug damaged Disclaimer: The Security Operations Guide developed in accordance with IEC 704-1 standard, it is recommended guidance; Masterpiece Technology (International) Co., Ltd. does not bear any responsibility of the consequences of this guide. Directory Chapter 1: Introduction 1.1: Overview...

  • Page 4: Chapter 3: System Settings

    2.6: Set the keyboard backlight 2.7: replace battery 2.8: install / remove the SIM card 2.9: battery charging 2.10: Connecting to a PC Chapter 3: System Settings 3.1: GPRS Settings 3.2: Bluetooth Settings 3.3: WiFi Settings 3.4: Internet Options 3.5: PC Connection 3.6: Stylus 3.7: Auto-run 3.8: Storage Manager...

  • Page 5: Chapter 1: Introduction

    1.1: Overview PDT-1000W MPTIC PDT-1000W is a lightweight design mobile data terminal with 400MHz processor and Windows CE 5.0 O/S. It is widely used in the fields of manufacturing, warehousing, express courier, retail industry. Its built-in bar code scan engine, RFID reader and other data collection modules have high recognition rate and acquisition speed, ensure PDT-1000W works with high performance and high reliability on the barcode acquisition and data processing work.
  • Page 6 System Specifications: Processor: SAMSUNG 400MHz System memory: 128MB Program Memory: 128MB Operating systems: Microsoft Windows CE.NET 5.0 Display Specifications: Display Type: 2.8 "TFT LCD Display resolution: 240 * 320 Viewing area: 43.2 * 57.6mm Screen Brightness: 250 cd/m2 Interface specifications: USB Device 1.1 interface * 1 USB Host 1.1 Interface * 1 (A2 version only) RS-232 COM interface * 1...
  • Page 7 Barcode type: UPC-A, UPC-E, EAN-13, EAN-8, ISBN / ISSN, Code 39 full ASCII, Code 32, Trioptic Code 39, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5 Codabar (NW7), Code 128, Code 93, Code 11 (USD-8), MSI / Plessey, UK / Plessey, UCC/EAN128, China Post, China Finance, GS1 DataBar 2D barcode Jet: Jet Type: CMOS sensor Read distance: 51mm - 330mm...
  • Page 8 When PDT-1000W is running, press the key and hold for 1 second, PDT-1000W displays "Turn off the power window. Press the "Sleep" button, then processor of PDT-1000W enters sleep mode, PDT-1000W will turn off the LCD screen, the scanning module and all wireless communication modules.
  • Page 9 Press the "off" button, PDT-1000W will switch off power, unsaved data will be lost at all. Press the "restart" button, PDT-1000W will restart, unsaved data will be lost at all. While PDT-1000W is in sleep mode, press the button, the device will wake up and enter into running state, the processor will run, the scanning module will work, as well as all wireless communication modules.
  • Page 10 The terminal can be connected to PC directly via the USB port, we recommend to install Microsoft ActiveSync software. Start ActiveSync, PC will automatically search for the USB port and establish a connection with the PDT-1000W. Microsoft ActiveSync is on the disc of the accessories box, after installation, run the ActiveSync program.
  • Page 11 Connect PDT-1000W to PC with a USB cable in the accessories box. The bottom of USB port is illustrated as picture on right The ActiveSync program automatically detects PDT-1000W, "New Partnership" window is displayed. Press the icon to select "Yes", press the "Next"...
  • Page 12 The user can write application software at PC side, and access PDT-1000W through the ActiveSync interface then exchange or transfer data and file to PDT-1000W automatically. Please refer to the relevant technical documentation for development works...
  • Page 13 Similar to the standard Windows operating system, Windows CE.NET system have desktop, file manager, control panel and other parts; parameters of related functions of PDT-1000W are all in the Control Panel. Click on the System icon on the taskbar to display the Start menu,...
  • Page 14 WiFi network, the connection status icon is displayed, after landing, icon is displayed. Not select “Automatically connect to the WiFi network ", after restart, PDT-1000W will not connect to WiFi networks. 3.4: Internet Options Double-click the Internet Options icon in the Control Panel, "Internet Options"...
  • Page 15 "PC Connection Properties” window, set the connection between PDT-1000W and PC, e.g. a USB or serial connection. Select “Enable PC connected directly ", allows PDT-1000W connect to Window displays the current connection, in case need to change the connection mode, press the "Change the connection ..." button in the pop-up "Change Connection"...

  • Page 16: Storage Manager

    PDT-1000W running specified applications automatically after starting Copy auto run programs to the Flash file directory of PDT-1000W, input the programs address and file name to the text box in the window, or click the Browse button on right to locate the program.

  • Page 17: Administrator Password

    "Administrator Password" window will be displayed. User can set the security status of PDT-1000W after startup. Check the "enable administrator password", input password in the Password field, and press the OK button, PDT-1000W will boot into safe mode. Only in administrator mode, user can operate PDT-1000W’s file system and control panel.
  • Page 18 3.12: Date / Time Double-click the "Date / Time" icon on the Control Panel, the “Date/Time Properties” window will display, user can set the system date, time, and time zone. 3.13: Remove Programs Double-click the "Remove Programs" icon on the Control Panel., "Remove Programs"...
  • Page 19 Select the "Automatically open bar code scanning” option, after starting PDT-1000W, you can scan a bar code by pressing the button. In case not select "Automatically open bar code scanning" option, the user...
  • Page 20 Please refer to Chapter 4 of this manual “application programming interface API” to learn more about related functions. Select “Send serial data (COM2 interface)” option, the PDT-1000W will send scanned data in ASCII mode to application program over COM2 port.
  • Page 21 Double click the "Dialing" icon in the Control Panel, the "Dialing Properties” window will display. This window allows you to set and view some of the parameters PDT-1000W used to establish a modem dial-up connection, such as location, phone number information, as well as dial-up, call mode.

  • Page 22: Taskbar And Start Menu

    3.21: Certificate Double click the "Certificate" icon in the Control Panel, the “Certificate” window will display. You can view the certificate installed on PDT-1000W. Windows CE system maintains a trusted certification authority (CA) database. While try secure connection, Windows CE extract the root certificate from the certificate chain and check it in accordance with the Certificate Authority database.
