Summary of Contents for Diamond Multimedia DS3900
-
Page 1: Quick Start Guide
DS3900 USB 3.0 Dual Display Dock Quick start guide... -
Page 2: About This Manual
ABOUT THIS MANUAL This manual provides a beginner's introduction to installing, configuring and using the USB3.0 Gigabit Ethernet Adapter. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. -
Page 3: Table Of Contents
Table of Contents 1. Introduction ....................... 1 Application ........................1 Features ..........................2 Package Contents ......................2 System Requirements ......................2 Front Panel ........................3 Rear Panel ......................... 4 2. Installation ......................5 Driver installation ......................5 Hardware installation ......................6 Verifying the Installation .................... -
Page 4: Introduction
1. Introduction 1. Introduction A USB3.0 Dual Display dock enables multiple USB devices to be connected to the computer using a single USB3.0 cable . Now with one simple cable connection to your computer you can have access to large screen displays, stereo speakers, external hard drive, optical disk drive, printer, USB keyboard and mouse Just plug in the one USB 3.0 cable from the USB3.0 Dual Display dock to any USB 3.0 or USB 2.0 port on your laptop and your displays and accessories will be... -
Page 5: Features
USB 3.0 Display Dock User’s Manual Features USB Downstream Compliant to USB 3.0 and USB 2.0 Two USB3.0 down-stream ports supports Super-speed, high-speed and full-speed traffic Four USB2.0 down-stream ports support Super-speed, high-speed, full-speed and low-speed traffic Ethernet ... -
Page 6: Front Panel
1. Introduction Front Panel Power LED: Glows when the docking station is powered. 3.5 mm stereo audio output port: Connect to stereo headphones or speakers. 1 USB 3.0 downstr eam port : Connect USB peripherals. 2 USB 3.0 downstream port: plus quick charge port (BC 1.2) for Apple iPad and iPhones... -
Page 7: Rear Panel
USB 3.0 Display Dock User’s Manual Rear Panel 4 USB 2.0 downstream ports (A type female connector): Connect to USB peripherals . 10/100/1000 Mbps Ethernet port: Connect to the Ethernet network via a network cable. DVI video output port: Connect to a HDMI monitor. -
Page 8: Installation
2. Installation 2. Installation Driver installation Caution: DO NOT connect the USB display dock to your computer before you install the provided driver. Follow the procedures below to install the driver and then connect the USB display dock to your system : 1. -
Page 9: Hardware Installation
USB 3.0 Display Dock User’s Manual 2. Please wait while Windows configures DisplayLink Core Software. Your screens may temporarily go black or flash during this process. When finished, the installation screen will disappear and you will return to your desktop. Note：On some machines you may need to reboot before you can use your Display dock. -
Page 10: Verifying The Installation
2. Installation Connect your USB devices to the USB ports on the Display dock. As long as one USB device is connected to the port and the connection works properly, If your USB device, such as a printer or optical drive, etc., came with its own AC adaptor, make sure that it is plugged into the device and a working electrical outlet. -
Page 11: Using The Usb Display Dock
USB 3.0 Display Dock User’s Manual 3. Using the USB Display Dock Configuring Displays When USB Display Dock connected , the firmware version will be checked by the host software. If they do not match, the firmware on the device will be updated. While the firmware is updating, a window similar to that shown below will be shown. - Page 12 3. Using the USB Display Dock A menu appears with several options. These are shown and described below. Menu Option Sub-menu Option Description This is the UI title. Clicking on this item will open Windows screen DisplayLink Manager resolution.
- Page 13 USB 3.0 Display Dock User’s Manual Menu Option Sub-menu Option Description Connects to the Microsoft Windows Update Server to check for newer Check for Updates software versions and downloads them, if available. Options to configure In this section of the menu, a list of connected DisplayLink devices will DisplayLink devices this DisplayLink appear.
- Page 14 3. Using the USB Display Dock Display Menu Description Extend Extends your Windows desktop onto this display. Set as Main Monitor Sets this screen as the main display. Switches off the display of the notebook and makes the DisplayLink display the main display. Notebook Monitor Note: This option will only appear when 1 DisplayLink USB screen, is connected.
- Page 15 USB 3.0 Display Dock User’s Manual For an attached DisplayLink device (or screen), it is possible to use Windows Key+P to display a menu (and cycle through it) to allow: Disconnect Projector, Duplicate, Extend, Projector Only. *Actual strings depend on your operation system. These screen shots are from Windows 7 and might vary slightly for each operation system.
-
Page 16: Uninstalling The Driver
4. Uninstalling the Driver 4. Uninstalling the Driver Uninstalling the Driver Please take these steps to uninstall Driver: Open the Control Panel, Programs and Features and double-click Uninstall a Program on Windows 7 or Add or Remove Programs on XP. Select DisplayLink Graphics and click Uninstall Select [Yes] to continue the uninstall process. -
Page 17: Specifications
USB 3.0 Display Dock User’s Manual 5. Specifications General Host Interface Compliant with USB specification 3.0, 2.0 Windows XP, Windows 7, Windows 8 Operating System Support Ports and Connectors Upstream 1 x Upstream USB 3.0 Port (Type A male Connector) 4 x Downstream USB 2.0 Port (Type A female connector) USB Hub Downstream... - Page 18 5. Specifications USB Downstream Compliant to USB 3.0 and USB 2.0 Two USB3.0 down-stream ports supports Super-speed, high-speed and full-speed traffic Four USB2.0 down-stream ports support Super-speed, high-speed, full-speed and low-speed traffic. Ethernet IEEE 802.3, 802.3u, and 802.3ab compatible ...
-
Page 19: Regulatory Compliance
USB 3.0 Display Dock User’s Manual 6. Regulatory Compliance FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 21 One Year Limited Warranty The warranty described below is extended only to the original buyer and is not transferable. PLEASE NOTE THAT THE PRODUCT YOU HAVE PURCHASED IS DISTRIBUTED AND WARRANTED BY DIAMOND MULTIMEDIA ("DIAMOND") AS DESCRIBED BELOW. QUESTIONS REGARDING THIS WARRANTY AND WARRANTY CLAIMS SHOULD BE MADE TO DIAMOND.
