Giantec VPC5000 Series Installation Manual

Vehicle pc system

Advertisement

Quick Links

VPC5000 Series
Vehicle PC System
Installation Manual
Installation Manual
2
Edition, 2007
nd
Copyright
This document is copyrighted, © 2007, and all rights are reserved.
manufacturer reserves the right to make improvements to the products described in this
manual at any time without notice. No part of this manual may be reproduced, copied,
translated or transmitted in any form or by any means without the prior written permission
of the original manufacturer. Information provided in this manual is intended to be
accurate and reliable. However, the original manufacturer assumes no responsibility for
its use, nor for any infringements upon the rights of third parties that may result from such
use.
Copyright © 2007 by Giantec Inc.
All right Reserved
December 2007, Version A.1
Acknowledgments
Award is a trademark of Award Software International, Inc.
VIA is a trademark of VIA Technologies, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines
Corporation.
Intel, Pentium, Celeron, and MMX are registered trademarks of Intel Corporation.
®
Microsoft Windows
is a registered trademark of Microsoft Corp.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
All other product names or trademarks are properties of their respective owners.
For more information, technical support and service about this VPC5000 Vehicle PC,
please contact your supplier where you have purchased from.
nd
This manual is for VPC5000 series (2
Edition, 2007)
VPC5000 Series Vehicle PC Installation Manual verA.1
The original
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VPC5000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Giantec VPC5000 Series

  • Page 1 For more information, technical support and service about this VPC5000 Vehicle PC, please contact your supplier where you have purchased from. Installation Manual This manual is for VPC5000 series (2 Edition, 2007) Edition, 2007 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 2: Limited Warranty

    Liquid has penetrated into the equipment. accident, abuse, misuse, negligence and acts of God. The equipment has obvious sign of breakage. VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 3: Table Of Contents

    Frequency/Voltage Control................60 software… etc.) Appendix A AM/FM/TV Transmission ...............61 A complete description of the problem Appendix B After Service ..................63 The exact wording of any error messages VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 4: Chapter 1 Product Overview

    If the vehicle has installed the parking camera, when shift the gear lever to R (Reverse), automatically, the scene of rear view camera will be displayed。 VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 5 (3)Press to adjust tint level。 5. (LOUD)LOUDNESS Adjustment (1)Press to LOUDNESS。 (2)Press [ENTER]key。 (3)Press to select ON or OFF。 VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 6: Touch Panel Specification

    Press PRESET key ~ , will display each Active Area - 152.4X 91.4 mm record channel Channel Receiving Display current Channel Frequency FM1/FM2/AM1 Displays current radio frequency VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 7: Video Source Selection

    Manual Tuning and Auto Scanning Radio Stations Press [TUNER+] Button or [TUNER-] button to search a radio station manually. The auto scan mode begin with press and hold[TUNER+]/[TUNER-]Button over 2 seconds. VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 8: Radio Station Feature

    TV System NTSC / PAL Auto switching Power Supply 12 VDC Average Maximal Current Operation -20°C~70°C Temperature Overall Width: 3.875” X Depth: 7” X Height: 6.5” Dimension VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 9: Chapter 2 Computing Feature

    Supporting other Windows based software application ◎ Multimedia Graphic User’s Interface Support media file playback ◎ Support music file playback ◎ Support software programs accessing ◎ VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 10 - Power Hold & Resume scheme - Volume Control (Up & Down) x 1 - Tuner scan off only button x 1 - Access keys x 1 VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 11: External I/O Connector

    (7). Red – The wire is ACC line, it’s connect to Car door lock. (8). Yellow – Those wires should be connecting to ACC (9). Black – The wire is connect to ground, usually it connects to car body. VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 12 It defines Radio antenna’s connection. Brown: side Brake VGA Output: The VGA cable is secondary VGA output which is the dual display for back seat Front-Right Speaker Back-Left Speaker VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 13 ◎ wide viewing angle technology ◎ High contrast by Super Wide View technology Connect to Parking Camera ◎ High power LEDs backlight with Mercury-free solution Features Description For Front Panel: VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 14 PC POWER LED indicator DVD-ROM: (23) HDD LED indicator DVD-ROM is ready for data access. It supports any kind of DVD title. PC HOLD LED indicator (24) VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 15: Chapter 3 Chipset Software Installation Utility

    • Identification of Intel® chipset components in the “Device Manager” software. The device drivers for the VPC5000 series board are located in the software installation CD. The driver CD will guide and link you to the utilities and device drivers under a Windows system.
  • Page 16: Installation Guide

    Click “Yes” when you see the following message. 3.3.4 Step 4 The “Install Shield Wizard” appears to begin the installation process. 3.3.2 Step 2 VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 17 3.3.5 Step 5 When the following message appears, click “Finish” to complete the 3.3.7 Step 7 installation and restart Windows. Installation is in progress. 3.3.6 Step 6 VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 18: Chapter 4 Vga Setup

    Chapter 4 VGA Setup Please read the instructions in this chapter carefully before you attempt installation. The VGA drivers for the VPC5000 series are located on the driver CD. Run the supplied SETUP program to install the drivers, don’t copy the files manually.
  • Page 19: Installation Guide

    “VGA Driver” icon to start installation. Click "next" when you see the following message. 4.3.4. Step 4 Click “Next” to begin VGA driver installation. 4.3.2 Step 2 VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 20 Click “Yes” when you see the following message. When the following message appears, click “Finish” to complete the 4.3.5 Step 5 4.3.7 Step 7 installation and restart Windows. Installation continues. 4.3.6 Step 6 VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 21: Further Information

    Driver Installation Please read the instructions in this chapter carefully before you attempt installation. The audio drivers for the VPC5000 series are located on the driver CD. Run the supplied SETUP program to install the drivers, don’t copy the files manually.
  • Page 22: Installation Guide

    Driver” icon to start installation. 5.3.4 Click “Continue Anyway” when you see the following message Step 4 5.3.2 Click “Next” when you see the following message. Step 2 VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 23: Further Information

    Installation is in progress. Further Information Step 5 For further information about the audio installation in your VPC5000 series, including driver updates, troubleshooting guides and FAQ lists, contact your supplier where you have purchased from or visit the following web resources: Realtek website: www.
  • Page 24: Chapter 6 Default Bios Setting

    CMOS RAM for booting if operating in harsh industrial environment causes a soft error. Figure 6.1.2: Award BIOS Initial Setup Screen Figure 6.1.1: Caution Screen VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 25: Entering Setup

    Press “ESC” to allow you to return back to BIOS Initial Setup Screen. Figure 6.2.4 Advanced BIOS features screen Figure 6.2.2: Standard CMOS features screen VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 26: Advanced Chipset Features

    Setup freely. 6.2.2.4 APIC Mode APIC stands for Advanced Programmable Interrupt Controller. The default setting is Enabled. Figure 6.3.2: Advanced Chipset Features VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 27: Integrated Peripherals

    The default setting for the Active to Precharge Delay is 3. 6.3.6 On-Chip VGA The default setting is enabled. Figure 6.4.2 on Chip IDE Device 6.3.7 On-Chip Frame Buffer Size The default setting is 32MB. VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 28 If you enable IDE HDD Block Mode, the enhanced IDE driver will be enabled. Leave default setting is enabled. IDE HDD Block Mode on the default setting. VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 29: Power Management Setup

    Stop Grant allows user to set suspend type to Stop Grant PwrOn allows user to set suspend mode to Power on suspend Figure 6.5.1: Power Management Setup Figure 6.5.2: Power Management Setup VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 30: Pnp/Pci Configurations

    Enable hardware shutdown monitoring to shutdown system when temperature is been defined. 6.7.2 CPU Warning Temperature Enable warning monitoring and warning by buzzer when temperature is been defined. Figure 6.6.2: PnP / PCI Configurations VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 31: Frequency/Voltage Control

    Figure 6.8.2: Frequency/Voltage Control 6.8.1 Auto Detect PCI Clk The default setting is enabled. 6.8.2 Spread Spectrum Enable spread spectrum clock modulation to reduce EMI. VPC5000 Series Vehicle PC Installation Manual ver.A.1 VPC5000 Series Vehicle PC Installation Manual verA.1...
  • Page 32: Appendix B After Service

    Appendix B After Service ▓Entrusted for Repair If the product is still in warranty, please plug off the power, and then send product with the warranty card to Giantec distributors or its service center. ▓ After Service Weak signal noise...
