ReSound TV Steamer 2 Getting Started

Setting up your
A
tV Streamer 2
the tV Streamer 2 supports both analog and
digital audio input.
Depending on your tV, sound system, computer
or other audio device, the installation of tV
Streamer 2 may be done in several ways
described on the following pages.
For all installations it is required that you:
1. plug the power cord into the
micro-uSB socket on the tV
Streamer 2
2. plug the other end of the power
cord into an electric wall outlet
Connect the tV Streamer 2 to
your audio source using one of the
following 5 installations.
1. ConneCting the tV Streamer 2 to
an analog auDio SourCe (e.g. tV
or SounD SyStem)
1. plug the stereo mini-jack
on the audio cable into the
stereo mini-jack input on the
tV Streamer 2
2. plug the other end audio 1. Mini-jack input
cord into the "auDio
out" terminals on the
audio source
the "auDio out" is usually
marked "l – r" for left and
right, and can usually be
found on the back of the
audio source.
2. ConneCting the tV Streamer 2
to an analog auDio SourCe uSing
a heaDphone mini-jaCk aDaptor
1. plug the stereo mini-jack
on the audio cable into the
stereo mini-jack input on the
tV Streamer 2
2. Connect the stereo mini-jack 1. Mini-jack input
adapter to the red and
white plugs at the other
end of the audio cable
3. plug the stereo mini-jack
adapter into the audio
sources' "heaDphone"
output terminal
4. ConneCting the tV Streamer 2
to a Digital auDio SourCe uSing
the optiCal (toSlink) auDio input
1. insert one of the plugs on the
optical audio cable into the
optical audio input socket on
the tV Streamer 2
1. Optical input
Note: most optical cables
are delivered with a
small protective cap to
protect the tip of the
cable. please remove
this protective cap before
inserting the cable
2. plug the other end of the
optical audio cable into the
"Digital audio out/optical"
on your audio source
3. ConneCting the tV Streamer 2
to an analog auDio SourCe uSing
a SCart aDapter
1. plug the stereo mini-jack
on the audio cable into the
stereo mini-jack input on the
tV Streamer 2
2. Connect the scart adapter to 1. Mini-jack input
the red and white plugs at
the other end of the audio
cable
3. plug the scart adapter into
the audio source's scart
terminal
5. ConneCting the tV Streamer 2 to
a Digital auDio SourCe uSing the
Coaxial auDio input
1. insert one of the plugs on the
coaxial audio cable into the
coaxial audio input socket on
the tV Streamer 2
1. Coaxial input
2. plug the other end of the
coaxial audio cable into
the "Digital audio out/
Coaxial" on your audio
source
