Page 3: Introduction
Introduction Thank you for purchasing The Diy Track Defender® vehicle tracker and alarm ® The Defender can be installed in any type or make of vehicle with a voltage range of 12-24v. However the immobiliser Function only operates on 12volt vehicles. -
Page 4: Hardware And Accessories
Immobiliser Relay Alarm Siren SOS Panic Button Remote Contol Tools needed for installation The following tools are recommended for installation of the DEFENDER® vehicle tracking and alarm system Metric and standard socket set. Screwdriver set Side cutters, wire strippers Digital multimeter... -
Page 5: Fixtures And Fittings
Antenna connection Connect the GSM and GPS antenna to the tracking module. Please note: the correct antenna must be connected to the corresponding point. GSM Antenna to GSM Jack GPS Antenna to GPS Jack All rights reserved. ©2011 DIY TRACK... -
Page 6: Installation Process
To prevent a possible transient voltage surge it advised to disconnect the vehicle battery. Disconnect the ground (-) cable/terminal. Please note warranty does not cover damage from a transient voltage surge. ® Securely attach the 10 Pin connector plug into the DEFENDER module. Locate the Red cable/wire found on the 10 pin connector. -
Page 7: Wiring Diagram
Connect the green wire of the relay (30) to one end of the positive wire that you cut Connect the green wire of the relay (87a) to one end of the positive wire that you cut WARNING Solder and insulate all connections (Crimping should be avoided wherever possible) All rights reserved. ©2011 DIY TRACK... -
Page 8: Accessories
Connect the black wire on the siren cable to the closest point of a solid chassis ground uninhibited by paint or plastics Fix the siren securely in the engin compartment Antenna for the Remote Control WARNING Solder and insulate all connections (Crimping should be avoided wherever possible) All rights reserved. ©2011 DIY TRACK... -
Page 9: Antenna Placement
GPS Antenna Placement The DEFENDER® will work best if the GPS antenna has a clear view of the sky and as much of the horizon as possible. Any metal between the GPS antenna and the satellites will degrade the signal and reduce the overall performance. - Page 10 Start at the top and carefully pull it away just slightly. It is usually held in place by clips. When you have loosend a small part of the cover, slide your hands down to the middle and pull gently towards you All rights reserved. ©2011 DIY TRACK...
- Page 11 Some vehicles have an airbag in the pillar. in such cases install the antenna below the airbag Replace the cover by lining up the clips with the corresponding holes on the pillar Slide the internal battery switch to the “ON” Position All rights reserved. ©2011 DIY TRACK...
-
Page 12: Warranty
We are not responsible for acts or omissions of any other service provider, for information provided through the equipment, for use of or installation of Diy-Track products unless caused by the sole and gross negligence of Diy-Track All rights reserved. ©2011 DIY TRACK... -
Page 13: Online Tracking
The SMS must be sent exactly like the above example with no spaces You will receive a reply with a 15 digit number, please email this number to support@diytrack.co.za so that we can activate your tracker. All rights reserved. ©2011 DIY TRACK... -
Page 14: Sms Commands
Dial the tracker mobile number from an authorized number, it will hang up your call and you will receive an SMS with a clickable Gmaps link in the text. Perfect for tracking on a cell phone with internet availability. All rights reserved. ©2011 DIY TRACK... - Page 15 You can now dial the tracker to hear the conversation and sounds around the microphone Please note : You must return the tracker to “track mode” to track the vehicle again. Send SMS: tracker123456 All rights reserved. ©2011 DIY TRACK...
- Page 16 SMS space Please note : The SMS must be sent exactly like the above example with the space and all letters must be lowercase Send SMS: nomove123456 to disable the movement alert All rights reserved. ©2011 DIY TRACK...
- Page 17 When the tracker device enters silent mode, the siren won’t sound if an alarm is trggered, but the tracker will send an alert SMS to the authorised numbers Send SMS: silent123456 Send SMS: disarm123456 to disable silent mode Please note : The SMS must be sent exactly like the above examples All rights reserved. ©2011 DIY TRACK...
- Page 18 Send SMS to the tracker to activate the function of storing Setup: sdlog123456 data on SD card; Cancel: Send SMS sdlog123456 0 to the tracker to deactivate the function of storing data on SD card. All rights reserved. ©2011 DIY TRACK...
