Summary of Contents for Creative SB1590

  • Page 2: Package Checklist

    Introduction ® Congratulations on your purchase of Sound Blaster E5! This portable headphone amplifier and USB DAC (Digital-to-Analog Converter) features powerful noise reduction microphones that record clean, high quality audio directly to smart devices or PCs and Macs. The built-in powerful SB-Axx1™ sound and ®...

  • Page 3: Registering Your Product

    Using Creative Software AutoUpdate Locating, downloading and installing updates for your Creative products is now simpler and faster with the web-based Creative Software AutoUpdate system. When you connect to Creative Software AutoUpdate via the Internet, the website will analyze your computer system to determine your operating system, language and which Creative products are connected to your system.

  • Page 4: About Your Hardware

    About Your Hardware The Sound Blaster E5 has input and output jacks to enable connection to various devices while controls on the side give you basic control over your audio device. CAUTION: Do not store the device in high temperatures or leave the device in a car exposed to direct sunlight for a long period of time.

  • Page 5: Controls And Indicators

    Controls & Indicators Control / Description Indicator Power / Bluetooth Power / Bluetooth button button and Power On – Press and hold 1 sec indicator Bluetooth pairing – Press and hold 2 sec Power Off – Press and hold 4 sec Indicator White: Power ON Blue (blinking): Bluetooth discovery/pairing mode...

  • Page 6: Input / Output Jacks

    Input / Output Jacks Bottom Jack / Control Description Headphone jacks Connects to stereo headphones with a 3.50 mm (1/8- inch) plug. Volume control Adjusts the audio output volume. knob Increase volume: Turn clockwise Decrease volume: Turn anti-clockwise Mute or unmute the volume: Press once Line / Mic / Optical In Connects to line-level sources (smartphones, tablets, jack...
  • Page 7 Setting Up Your Audio Device Step 1: Charging your Sound Blaster E5 Connect your Sound Blaster E5 directly to a USB port on your computer. You can also connect to a wall outlet using USB power adapter* (not included). * DC 5V, 1 A Charge your Sound Blaster E5 for approximately 4 to 5 hours.
  • Page 8 Step 2: Turning On Sound Blaster E5 Press the Power / Bluetooth button to turn on Sound Blaster E5. Power On – Press and hold 1 sec Bluetooth pairing – Press and hold 2 sec Power Off – Press and hold 4 sec Battery level indication In On mode, the three white LEDs light up according to the battery level of your Sound Blaster E5.

  • Page 9: Step 3: Connecting To An Audio Source

    Step 3: Connecting to an Audio Source One-touch pairing with NFC You may pair your NFC-enabled devices (such as Bluetooth mobile devices) with the Sound Blaster E5 with a single tap using NFC technology. Simply follow these steps to connect them. Action LED Status Device Status...
  • Page 10 Manual Bluetooth pairing To enjoy your favorite music from your Bluetooth devices, simply follow these steps to connect them. Action LED Status Device Status Press and hold Power / Bluetooth indicator blinks Pairing mode. Bluetooth button for 2 seconds. in blue. Ready to be paired with new device.

  • Page 11: Connecting To A Computer Via Usb

    Connecting to a computer via USB (a) Micro-USB cable (b) Desktop (c) Laptop Note: Connecting the Sound Blaster E5 to a USB hub is not recommended. Setting the Sound Blaster E5 as the default audio device For Windows 1. Go to Control Panel and click Sound. 2.
  • Page 12 Connecting to a mobile device via USB Host (a) USB cable (not included) (b) Smartphone (c) Tablet Sound Blaster E5 – Setting Up Your Audio Device...
  • Page 13 Connecting to line-in sources (e.g. MP3 player, CD player) (a) 3.5 mm (1/8") stereo analog cable (available separately) (b) PC/Mac (c) Tablet/Smartphone (d) Portable media player (e) DAT/CD players Sound Blaster E5 – Setting Up Your Audio Device...
  • Page 14 Connecting to optical-in sources (e.g. DVD/Blu-ray player, TV set) (a) Mini-TOSLINK cable (b) DVD player (c) TV set (d) Game console Sound Blaster E5 – Setting Up Your Audio Device...
  • Page 15 Step 4: Connecting to Headphones / Microphones / Speakers Connecting to headphones CAUTION: Set the appropriate gain level (L or H) before connecting your headphones to the Headphone jack to prevent damaging your headphones. Low: For headphones with low impedance (32 ~ 120 ohms). Gain: up to 5 dB. High: For headphones with high impedance (120 ~ 600 ohms).
  • Page 16 Connecting to microphones For Windows 1. Go to Control Panel and click Sound. 2. Click the Recording tab, select Sound Blaster E5 (External Mic), then click the Set Default button. For Mac 1. Go to System Preferences and click Sound. 2. Click the Input tab, then select Sound Blaster E5 (External Mic). Note: You can only use one external microphone at a time.

  • Page 17: Connecting To Speakers

    Connecting to speakers BASS TREBLE VOLUME AUX IN (a) 3.5 mm 2-channel audio cable (available separately) (b) Analog speakers (c) Mini-TOSLINK cable (d) Digital speakers Note: Line Out audio is muted if a device is connected to the Headphone jacks. Sound Blaster E5 –...

  • Page 18: Installing And Uninstalling Software

    6. Double-click the Install icon and follow the subsequent on-screen instructions to complete the installation. 7. Launch the Sound Blaster E-Series Control Panel from the Applications > Creative folder. Note: Depending on your operating system, model and software version, the user interface or color theme may differ.
  • Page 19 If the User Account Control dialog box appears, click the Continue button. 4. Click the Yes button. 5. When prompted, restart your computer. For Mac OS 1. Click Applications > Creative > Creative Uninstaller. 2. Select Sound Blaster E5. 3. Click the Uninstall button. 4. Follow the on-screen instructions.

  • Page 20: Installing The Mobile App

    Installing the Mobile App Sound Blaster Central (for iOS and Android) Sound Blaster E5 comes with an amazing app, Sound Blaster Central, that supports both iOS and Android OS, so you can customize your audio – you now have total control right from the palm of your hand.

  • Page 21: Step 1: Adjusting The Volume

    Using Your Audio Device Step 1: Adjusting the volume WARNING: Set the volume control at minimum level before connecting headphones or speakers. Do not listen to audio at high volumes for prolonged periods of time to avoid impairing your hearing. Adjust the volume to a comfortable level using the volume control.
  • Page 22 Step 2: Using your Sound Blaster E5 Your Sound Blaster E5 works seamlessly with many external devices to perform different tasks: Playing audio Recording audio Answering calls Note: Line Out audio is muted if a device is connected to the Headphone jacks. Playing audio from a Bluetooth device BASS TREBLE...
  • Page 23 Enhance audio playback with SBX Pro Studio enhancements such as immersion control, dynamic range restoration, low-frequency boost, dialog boost, and automatic volume levelling. See Using the Creative Software Suite – SBX Pro Studio Settings. Sound Blaster E5 – Using Your Audio Device...
  • Page 24 Playing audio from a mobile device via USB Host BASS TREBLE VOLUM AUX IN Sound Blaster E5 – Using Your Audio Device...
  • Page 25 Playing audio from a line-in/optical-in device BASS TREBLE VOLUME AUX IN Sound Blaster E5 – Using Your Audio Device...
  • Page 26 Recording audio to an iOS mobile device You can record audio to your iOS mobile device using the built-in microphones of the Sound Blaster E5, or an external microphone connected to the Sound Blaster E5. Use a voice recording application on your mobile device to record audio. Microphone array orientation The built-in stereo microphones with horizontal or vertical orientation sensor creates a beamforming microphone array that works together with CrystalVoice technology to ensure crystal clear recording.
  • Page 27 Recording audio to a computer Easily record audio on your computer with the built-in microphones of the Sound Blaster E5, or an external microphone connected to the Sound Blaster E5. Use a voice recording application on your computer to record audio. Note: The built-in microphones will be disabled automatically when an external microphone is connected.
  • Page 28 You can record audio from a line-in source (game console, DVD player, TV set) and store them in your mobile or computer via the Sound Blaster E5. Note: Signal levels can be adjusted using the Sound Blaster E-Series Control Panel. See Using the Creative Software Suite. Sound Blaster E5 – Using Your Audio Device...
  • Page 29 Recording "What U Hear" (For Windows OS) The Sound Blaster E5 is equipped with What U Hear feature that allows you to record what is being played on the speakers/headphones as it is. Thus, you can also record voice conversations held over instant messaging tools such as Google Talk, Skype etc.

  • Page 30: Answering Calls

    If two headphones are connected, you will be able to listen to the call on both headphones. CrystalVoice enhancements help to further this experience by enhancing the clarity of communications. See Using the Creative Software Suite– CrystalVoice Settings. Sound Blaster E5 – Using Your Audio Device...
  • Page 31 Product Registration For iOS and Android Sound Blaster Central Bonus Pack Software (for Windows only) Various other bonus Creative applications are also compatible for your audio device. Visit support.creative.com and navigate to the relevant product page to view and download these...
  • Page 32 Sound Blaster E-Series Control Panel Configuring Your Software Settings Click each feature to access its settings page. More information on each feature can be found in thei respective sections in this manual. Sound Blaster E5 – Using the Creative Software Suite...
  • Page 33 SBX Pro Studio Dialog Plus enhances the voices in movies for clearer dialog, allowing the listener to hear the dialog over the rest of the soundtrack and over ambient noise in the listening environment. Sound Blaster E5 – Using the Creative Software Suite...
  • Page 34 Multiple microphones are used to focus, enhance the speaker's voice, and eliminate sounds outside the zone. CrystalVoice Mic EQ automatically adjusts the microphone audio according to the preset equalizer settings. Select an equalizer preset suitable for your microphone. Sound Blaster E5 – Using the Creative Software Suite...
  • Page 35 – Equalizer SPDIF-Out Direct allows bit-to-bit streaming of up to 24-bit 96kHz PCM data to the optical output without processing. SPDIF-Out Direct will remain on until the device is power off. Sound Blaster E5 – Using the Creative Software Suite...

  • Page 36: Mixer Settings

    Under Recording, adjust your recording volumes or to mute/unmute them. 2. Mixer settings Click the icon to mute/unmute the input/output. You can click the icon to adjust more settings for your input/output. Sound Blaster E5 – Using the Creative Software Suite...

  • Page 37: Equalizer Settings

    Selecting a preset will move the EQ sliders to the appropriate values. You can then adjust the equalizer setting by dragging the sliders up or down to the desired level. Click to save the new configuration as a new preset. Sound Blaster E5 – Using the Creative Software Suite...

  • Page 38: General Specifications

    General Specifications Inputs One 3.5 mm (1/8") line-in/mic-in/optical-in jack Built-in stereo microphones Outputs Two 3.5 mm (1/8") headphones jack One 3.5 mm (1/8") line-out/optical-out jack Connectivity One USB Type A host port One Micro-USB Type B port Controls and Indicators Power / Bluetooth button and indicator SBX / Call button and indicator Gain switch for headphones gain setting...

  • Page 39: Troubleshooting And Support

    Troubleshooting and Support This section provides solutions to problems you may encounter during installation or normal use. This includes: Problems with Sound Problems with Audio Streaming via USB Host Problems with Simultaneous Playback/Recording Tips to Improve Your Recording Quality Restore Default Settings Problems with Sound No sound from the headphones.
  • Page 40 Control knob for 5 seconds and then release. All settings and configurations made previously on your device will be erased. Additional Support If you encounter any other issues or have any other enquiries about your Sound Blaster E5 or any other Creative products, please visit our comprehensive knowledge base at support.creative.com www.soundblaster.com for additional information.

  • Page 41: Safety Information

    The product must be disposed of according to the local environmental regulations. To replace the battery, return your product to your regional support office. For product service information, go to www.creative.com. Do not expose to excessive heat such as sunlight, fire or the like.
  • Page 42 Wireless Product The short wave radio frequency signals of a wireless device may impair the operation of other electronic and medical devices. Switch off the device where it is prohibited. Do not use the device in medical facilities, aircraft, refueling points, close to automatic doors, automatic fire alarms or other automatically controlled devices.
  • Page 43 (Arrêté du 24 Juillet 1998). Les caractéristiques techniques de ces écouteurs se trouvent dans le manuel en ligne et/ou sur le site internet de Creative. Si vous choisissez d'utiliser un autre casque ou d'autres écouteurs, veuillez vous assurer au préalable que leurs caractéristiques techniques soient les mêmes.

  • Page 44: Regulatory Information

    Regulatory Information Notice for the USA Federal Communication Commission (FCC) Interference Statement FCC Part 15: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 45: Notice For Canada

    Notice for Canada This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. Cet appareil numérique de classe B est conforme aux normes canadiennes NMB-003 et CNR-210. This device complies with Industry Canada licence-exempt RSS standard. Operation is subject to the following two conditions: 1.

  • Page 46: Declaration Of Conformity

    DECLARATION OF CONFORMITY According to the FCC96 208 and ET95-19 Manufacturer/Importer’s Name: Creative Labs, Inc. Manufacturer/Importer’s Address: 1901 McCarthy Boulevard Milpitas, CA. 95035 Tel: (408) 428-6600 declares under its sole responsibility that the product Trade Name: Creative Model Numbers: SB1590...

  • Page 47: European Compliance

    MODIFICATION : toute modification non approuvée explicitement par Creative Technology Limited ou l'une de ses sociétés affiliées peut entraîner l'annulation de la garantie et des droits de garantie de l'utilisateur.

  • Page 48: Conformità Alle Normative Europee

    Störungen anderer Geräte oder unerwünschten Auswirkungen auf das Produkt führen. MODIFIZIERUNG: Jegliche Änderung oder Modifizierung des Produkts, die nicht ausdrücklich von Creative Technology Limited oder einer der zugehörigen Firmen genehmigt worden ist, kann für den Benutzer zum Erlöschen der Garantie und der Gewährleistungsrechte führen.
  • Page 49 AANPASSING: Alle wijzigingen of modificaties die niet uitdrukkelijk zijn goedgekeurd door Creative Technology Limited of een van de gelieerde maatschappijen, kunnen ertoe leiden dat de rechten van de gebruiker met betrekking tot garantie en vrijwaring vervallen.
  • Page 50 MODIFICAÇÃO: Quaisquer alterações ou modificações que não sejam expressamente aprovadas pela Creative Technology Limited ou por uma das suas afiliadas, pode anular a garantia do utilizador e os direitos inerentes à mesma. Europeisk efterlevnad Denna produkt uppfyller följande:...
  • Page 51 MODIFIKASJON: Eventuelle endringer eller modifikasjoner som ikke uttrykkelig er godkjent av Creative Technology Limited eller et av dets tilknyttede selskaper, kan ugyldiggjøre garantien eller garantirettighetene. Overholdelse af Europæiske regler og standarder Dette produkt overholder følgende:...
  • Page 52 Luokan rajoituksia noudattamattoman tietokoneen tai vääränlaisten kaapeleiden käyttäminen voi aiheuttaa häiriöitä muihin laitteisiin tai haitata itse laitteen toimintaa. MUOKKAUKSET: Muutokset tai muokkaukset, joita Creative Technology Limited tai sen tytäryhtiöt eivät nimenomaisesti ole hyväksyneet, voivat mitätöidä tuotteelle annetun takuun. Evropská shoda Tento výrobek splňuje následující...
  • Page 53 MODYFIKACJE: Dokonanie jakichkolwiek zmian lub modyfikacji, na które firma Creative Technology Limited lub spółki z nią stowarzyszone nie udzielają wyraźnej zgody, może doprowadzić do unieważnienia praw gwarancji i rękojmi użytkownika.
  • Page 54 λάθος καλώδια μπορεί να οδηγήσει σε παρεμβολές με άλλες συσκευές ή ανεπιθύμητες επιδράσεις στο προϊόν. ΤΡΟΠΟΠΟΙΗΣΗ: Οι όποιες αλλαγές ή τροποποιήσεις που δεν έχουν εγκριθεί ρητά από την Creative Technology Limited ή κάποια από τις θυγατρικές της ενδέχεται να ακυρώσουν την εγγύηση του χρήστη...
  • Page 55 Prevádzka pomocou necertifikovaných pocítacov alebo nesprávnych káblov môže mat’ za následok rušenie iných zariadení alebo nežiaduce úcinky na výrobok. ÚPRAVY: Akékolvek zmeny alebo úpravy, ktoré neboli výslovne odsúhlasené spolocnost’ou Creative Technology Limited alebo jednou z jej sesterských spolocností, môžu zrušit’ platnost’ záruky a zárucných práv používatela.
  • Page 56 Sertifikalı olmayan bilgisayarlarla veya yanlış kablolarla birlikte kullanılması, diğer cihazların düzgün çalışmamasına veya üründe istenmeyen etkiler görülmesine neden olabilir. DEĞİŞİKLİKLER: Creative Technology Limited veya bağlı şirketlerinden biri tarafından açıkça onaylanmamış tüm değişiklikler kullanıcının garanti ve teminat haklarını geçersiz kılabilir.

  • Page 57: Notice For Japan

    Обладнання відповідає вимогам Технічного регламенту щодо обмеження використання деяких небезпечних речовин в електричному та електронному обладнанні, затвердженого постановою Кабінету Міністрів України від 3 грудня 2008 № 1057 Notice for Japan 充電式電池のリサイクル 充電式リチウム電池はリサイクル可能な資源です。 Creative製品に埋め込まれている充電式リチウム電池をリサイクルするために、本体から電池を取り外さないで ください。リサイクルに関する情報および指示については、 Creative Media K Kカスタマーサポート http://jp.creative.com/support/contact/ (日本語) をご覧ください。 交換可能な (取り外し可能な) 充電式リチウム電池のリサイクルについては、以下をご覧ください。 充電式リチウム電池が完全に放電した場合、取り外すことを推奨します。 電池の金属部分にはセロハンテープなどの絶縁物質で覆うなど、注意が必要です。 充電式電池のリサイクルおよび回収、および対応店舗に関する情報は、JBRCのホームページをご覧くださ い。(http://www.jbrc.com/) Notice for Korea B급...
  • Page 58 Notice for China Vietnam RoHS Statement This product is in compliance with Circular 30/2011/TTBCT of the Ministry of Trade of the Socialist Republic of Vietnam (“Circular”), it does not contain the following substances in concentration greater than the Maximum Limit value as specified in the Circular. Maximum Limit (ppm) 1, 2 Substance lead...

  • Page 59: License And Copyright

    Information in this document is subject to change without notice and does not represent a commitment on the part of Creative Technology Ltd. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose without the written permission of Creative Technology Ltd.
