E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Fundamental Information on your new EPAC and this Operating Manual6 Scope of Delivery ................. 6 1.1.1 Basic equipment ................... 6 1.1.2 Optional accessories for installation by the specialist bicycle dealer ..6 Other applicable documents ..............
Page 4
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE 6.1.3 Checking other points................. 26 Checking the Saddle, Seat Post ............27 Inspecting the handlebars and handlebar stem ........28 Inspecting the handlebar attachments ..........29 Inspecting the headset ............... 29 Checking the Suspension Fork (if present) ......... 30 Inspecting the brakes .................
Page 5
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE 13.1.1 Dismantling the front wheel ..............53 13.1.2 Install the front wheel ................. 54 13.1.3 Dismantling the rear wheel ..............56 13.1.4 Install the rear wheel ................57 13.2 Installing and dismantling the saddle post with the saddle ....58 13.2.1...
Page 6
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Dear Customer, We wish to congratulate you on your choice of an EPAC from our company and thank you for the trust placed in us. With your EPAC you have acquired a high-quality, environmentally-friendly sports model with which you will have a great deal of pleasure while at the same time doing something to improve your health.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Fundamental Information on your new EPAC and this Operating Manual Scope of Delivery 1.1.1 Basic equipment • a complete bicycle with pedals • a transport lock for the disc brake • charging device •...
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Conventions 1.4.1 Symbols and signal words This draws your attention to how to deal with and the effects of safety information. This draws your attention to a dangerous situation which might WARNING result in death or injury if it is not avoided.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE StVO German road traffic regulations (Highway Code) StVZO German Road Traffic Licensing Regulations Wrench size, measure of tool size Volt, unit of electric tension Watt, unit of electrical and mechanical power 1.4.3...
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE 1.4.4 Representation In this operating manual we use the following representation rules: • Safety instructions are shown with a symbol and signal word in bold - see section 1.4.1, Symbols and signal words.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE For Your Safety Follow the instructions in this operating manual • Please make sure that your specialist bicycle dealer has completed the delivery certificate for your EPAC and that you have received all of the documents referred to in the delivery certificate.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE short-circuits in the rechargeable battery pack, causing the pack to catch fire. A damaged rechargeable battery pack can also cause a life-threatening electric shock. You should always use your EPAC as described in this operating manual and any additional documentation that you may have.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE • Please ensure that your specialist bicycle dealer notes down in the delivery certificate which documentation you have received from him. • Always take your delivery certificate with you if you purchase accessories and modification parts from your specialist bicycle dealer at a later time.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE • Do not use your EPAC to compensate for physical infirmity or lack of fitness. NOTE: Training to ride a bike can help you increase your riding safety and improve your riding technique.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Strong vibrations through use of your EPAC which is not in accordance with the designated purpose, storage in an environment which is too hot (e.g. car interior in strong sunlight) and falls with your EPAC may lead to internal short-circuits in the rechargeable battery pack and therefore cause the rechargeable battery pack to catch fire.
Page 16
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Rotating wheels can injure your hands and other parts of the body. • Keep your hands and other parts of the body away from rotating wheels! • Please ensure that any children sitting on mounted children's seats cannot come into contact with the rotating wheels.
21.00 kg (44 cm) Maximum permitted loading weight 115 kg 115 kg 115 kg (rider + children + luggage) GHOST light SP-DC1 27.2 Saddle support GHOST light SP-DC1 27.2 mm GHOST light SP-DC1 27.2 mm Type rigid rigid rigid Connection Saddle clamping...
Page 18
Maximum permitted loading weight 115 kg 115 kg 115 kg (rider + children + luggage) GHOST light SP-DC1 27.2 GHOST light SP-DC1 27.2 Saddle support GHOST light SP-DC1 27.2 mm Type rigid rigid rigid Connection Saddle clamping Saddle clamping Saddle clamping...
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Construction and Function Your bicycle is a so-called EPAC or pedelec. That is a bicycle whose electric motor helps you to pedal. The pedalling assistance switches on automatically as soon as you pedal and switches off automatically as soon as you stop pedalling.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Brakes and brake assignment • Your EPAC has one or two disc brakes which are independent of one another. • The left-hand brake lever operates the front brake. • The right-hand brake lever operates the rear brake.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Low step frame: Wheels NOTE: A wheel/the wheels are also called the front and rear wheel(s). Your wheel consists of • Hub • Only on the rear wheel hub: geared ring, also called the cassette or sprocket cluster •...
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE On your EPAC the wheels are attached as follows. • with quick-release axle (for operation see section 8.4.1). Electrical equipment The components of the electric pedal assistance and their operation are described in the enclosed Bosch original operating instructions.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Before your First Ride WARNING Danger from serious falls and accidents Your EPAC is pre-assembled before being shipped to your specialist bicycle dealer. Some of the safety-relevant parts are not yet sufficiently mounted. The final assembly of your EPAC has to be carried out by your specialist bicycle dealer, i.e.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Before Every Use WARNING Danger from serious falls and accidents A EPAC that is not completely ready for safe operation can lead to dangerous riding situations, falls and accidents. • Check that your EPAC is safe for use before every journey.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE 6.1.2 Checking the tyres 6.1.2.1 Checking the position of the valve As a result of stresses and strains and low tyre pressure, the tyre and inner tube can move on the rim and result in incorrect positioning of the valves. The valve base may tear off during the journey and result in a sudden loss of pressure in the tyre.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE 6.1.2.2 Checking the tyres Inspect your tyres for visible signs of damage, foreign bodies and wear. • The tyre rubber must have its original profile over its whole surface. • The tyre fabric under the rubber layer must not be visible.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Loosen the small retaining nut at the top of the valve Check the air pressure with a suitable tyre pressure gauge or an air pump with pressure gauge. NOTE: If necessary, please ask your specialist bicycle dealer to show you how to use the pressure gauge.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Remove such items carefully. If you have had spoke reflectors fitted, check that these are firmly fitted in place. If they are loose, please remove them completely. Check whether your wheels have been damaged by these loose parts.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Inspecting the handlebars and handlebar stem WARNING Danger from falls and accidents Incorrectly mounted or damaged handlebars and handlebar stems may result in dangerous riding situations, falls and accidents. • If you discover damage to these parts or have any doubt about their integrity, you must not use your EPAC again under any circumstances.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE • None of the parts must twist or move. • No cracking or grinding noises should be heard. Inspecting the handlebar attachments How to check the attachment of the gear lever, brake levers and grips: Grip the front wheel firmly between your legs or hold the handlebars tightly with one hand.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE • The headset must not exhibit any play. • No cracking must be heard or felt. • No crunching noise may be heard. Turn the handlebars with the front wheel several times to the left and right.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Pull on both brake levers completely with the bike at a standstill. The smallest distance between the brake lever and handlebar grip must be at least 10 mm. Try to push the EPAC with both brakes applied.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Inspect the brake disc for damage. It must not exhibit any dents, cracks, deep scratches or other mechanical damage. Raise the front and rear wheels alternately and turn the wheel by hand. The brake disc must run smoothly.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE WARNING Danger from falls and accidents Failure of the headlight and rear light can lead to dangerous riding situations in the dark or with poor visibility. You might fail to see obstacles or be overlooked yourself by other road users.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Touch the arm of the stand lightly to push it downwards. The arm of the stand must not fold down. With adjustable-length stands: use hand force to check that the extendable section cannot be moved.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Adjusting the EPAC NOTE: You may carry out certain adjustments on your EPAC yourself. You should only carry out this work yourself if you have the stated tools. Adjusting the saddle position Your saddle is attached with two clamping bolts.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE 7.3.1 Adjusting the hardness of the spring If your suspension fork has a steel spring suspension, you can adjust the behaviour of the spring preload on the left fork leg. The rule of thumb is: The suspension fork should sink in approximately 20 to 25% of the total suspension travel distance when the rider sits on the bicycle in the riding position.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE (which can be heard as hissing) as small as possible. 7.3.3 Switching off the suspension With the red lever on the right fork rod you can turn off the suspension of the fork almost completely.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Operating the EPAC Electric drive The components of the electric pedal assistance and their operation are described in the enclosed Bosch original operating instructions. Gears Your EPAC has a derailleur made by Shimano with so-called Rapidfire gear levers. When the gear is changed, the chain is moved to a different sprocket.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE The right-hand switch operates the rear derailleur. Here switching to a larger sprocket results in a lower gear ratio (= lower gear). The pedalling resistance becomes lower, you can only reach a lower speed, but it is easier to climb hills.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Quick-release axles The hubs of your wheels are mounted with quick-release axles in the dropouts of the fork or frame. The clamping of your saddle post is equipped with a quick-release axle. These clamping systems permit quick removal and installation of these components without the use of tools.
Page 42
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE • Turn the screw nut in an anti-clockwise direction until the wheel can be pulled out of the frame or front forks without great effort. NOTE: Make sure that you do not lose the springs.
Page 43
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE • Place the spring and screw nut on to the quick-release axle. • Turn the nut in a clockwise direction on to the right-hand end of the quick- release axle, which is protruding out of the hub.
Page 44
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Now turn the screw nut until the eccentrically pivoted lever when turned through 90° about its pivot can only move against a resista nce (it then forms more or less the straight extension of the hub axle).
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE loose and move its position. This can lead to dangerous riding situations, falls and accidents. Open the quick-release lever. Tighten the nut slightly in a clockwise direction. Close the quick-release lever. •...
Page 46
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE • Before closing the quick-release lever, ensure that the clamp is flush and in the correct position on the seat tube. Original operating instructions 12/2012...
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Loading the EPAC WARNING Danger from falls and accidents Adding an extra load impairs the riding behaviour of your EPAC and the braking distance becomes longer. And if you overload your EPAC, it is possible that parts of it might even break or fail.
Page 48
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE How to determine the maximum permitted loading weight: If you would like to transport a child on your EPAC: Weigh the child on a calibrated set of scales. Weigh yourself wearing all of your cycling clothes and helmet on a calibrated set of scales.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Riding the EPAC WARNING Danger from falls and accidents With your EPAC you can reach unusually high speeds. • You should only use this EPAC if you can safely ride at high speeds and brake from such speeds.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE WARNING Danger from falls and accidents Your driving safety depends in part on your speed and the driving conditions. The faster you ride and the more unfavourable the riding conditions are, the greater is your risk.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE What to do in the case of a fall or accident WARNING Fire Hazard If your EPAC falls over this may result in short circuits in the rechargeable battery pack and cause the rechargeable battery pack to catch fire.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Parking the EPAC safely WARNING Risk of injury from your EPAC falling over A EPAC that is supported by its kickstand or leaning against a house wall or garden fence, for example, can fall over when subjected to a small force. This may cause injury to individuals or animals and damage other objects.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Transporting the EPAC WARNING Danger of injury through shearing and trapping in the back wheel If you load your EPAC with the motor switched on, this may start up unintentionally if the pedals are touched.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE After long downhill rides it is possible that the brake discs have become very hot. • Do not touch the brake discs immediately after a downhill ride. • Allow the brake discs to cool down for at least 5 minutes before touching them.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Place your EPAC carefully on the ground with the fork ends. 13.1.2 Install the front wheel Remove the transport lock from the brake pistons Original operating instructions 12/2012...
Page 56
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Pick up the EPAC by the handlebars. Position the hub of the front wheel under the fork ends of the front-wheel fork. Insert the wheel so that the brake disc slides smoothly between the brake pads.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Lower the fork carefully until the axle is flush with the stop of the fork ends on the left and right. • When clamping with the quick-release axle Close the quick-release axle in accordance with section 8.4.1, Opening, closing the quick-release axles .
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE If your bike has a disc brake, insert the enclosed transport lock between the brake pistons. After removing the wheels, lay the bike carefully on its left side. 13.1.4 Install the rear wheel If your bike has a disc brake, remove the transport lock from the brake pistons.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE 13.2 Installing and dismantling the saddle post with the saddle In order to make it easier to transport your EPAC you can dismantle the saddle post and the saddle. The saddle post is fastened with a clamp in the seat tube of the frame. The clamping is performed by means of a quick-release axle and knurled nut.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE 13.2.2 Installing the saddle post If the insertion area is free of grease: Grease the insertion area of the saddle post. Push the saddle with saddle post into the saddle tube of the frame until the required saddle height is obtained.
Page 61
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Do not rely on the marking on the saddle post. Check the correct insertion depth as follows: • Place a finger tip against the saddle post in the installed position immediately above the clamping bolt.
Page 62
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Turn the saddle so that the saddle tip is pointing in the direction of travel. Ensure that the clamp is flush with the frame and that the slots in the saddle tube and clamp are aligned.
Page 63
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE situations, falls and accidents. Original operating instructions 12/2012...
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Maintaining the EPAC WARNING Danger of injuries to fingers and arms, danger of accidents During testing the EPAC might move off unexpectedly. Turn off the electric drive (see attached BOSCH original operating instructions).
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE 14.2 How to clean and care for your EPAC WARNING Danger of Injury Before carrying out any work on your EPAC, make sure that it is not prepared for moving off (traction standby). To do this, switch off the electric drive (see attached BOSCH original operating instructions).
Page 66
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE spray. Allow the EPAC to dry for a while. Spray the entire EPAC with a suitable cleansing agent. Use a water jet to rinse down the entire EPAC. You can also carry out additional wet cleaning with the help of a sponge or cloth.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Polish your EPAC after the prescribed waiting time with a clean, lint-free cotton cloth. Clean the brake discs by hand using a clean, dry, lint-free cotton cloth and a suitable degreasing agent.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE What to do in the case of faults WARNING Danger from falls and accidents resulting from unexpected after-running If your engine management system is faulty, your EPAC may continue running. • Be ready to brake at all times •...
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE 15.1 Gear shift, drive Malfunction Possible cause(s) Remedy Gears do not change or do not Shift lever not actuated correctly Actuate the lever again change smoothly Shift mechanism maladjusted Contact your specialist bicycle dealer.
Page 70
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Malfunction Possible cause(s) Remedy • Incorrect operation of the • Leave the bicycle where it is. Chain jumped off sprocket gearshift • Make sure the EPAC cannot • Maladjusted or damaged gear move off.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Malfunction Possible cause(s) Remedy • Repeated incorrect operation Chain jumps off repeatedly Operate the gearshift correctly, see section 8.2, Gears. of the gearshift • Maladjusted or damaged gear Contact your specialist workshop...
Page 72
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE WARNING Danger from falls and accidents Defects and faults in the frame and suspension can lead to dangerous riding situations, falls, accidents and material damage. • Contact your specialist bicycle dealer immediately if you notice the slightest malfunction.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE 15.4 Luggage rack and lights WARNING Danger from falls and accidents Defects and faults in the luggage rack and lights can lead to dangerous riding situations, falls, accidents and material damage. • Contact your specialist bicycle dealer immediately if you notice the slightest malfunction.
Page 74
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Malfunction Possible cause(s) Remedy • Tyre damaged Wheels “jump” Contact your specialist bicycle dealer immediately. • Spoke broken Noises: cracking, banging, Foreign matter has become Remove the foreign matter. Use grinding, etc.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE 15.5.1 Flat tyre WARNING Danger from falls and accidents Errors during repairs can lead to dangerous riding behaviour. You should carry out these repairs yourself only if you have the necessary tools.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE when riding over sharp-edged obstacles with too little air pressure. If the rim is not damaged: Install a new inner tube. If the leak is on the outside: • Hold the inner tube next to the rim with a tyre, as it was mounted. Check the area of the tyre where the hole is located in the inner tube.
Page 77
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Malfunction Possible cause(s) Remedy Remove the screen and attach it again Display not correctly attached (see BOSCH instructions) Charge the battery pack (see BOSCH Rechargeable battery pack flat instructions) No display Please contact your specialist bicycle Rechargeable battery pack broken dealer.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Taking the EPAC out of operation NOTE: The incorrect storage of your EPAC can damage the bearing, tyres and rechargeable battery pack and promote corrosion. Store your EPAC in accordance with the following specifications if you are not going to use your EPAC for longer than 2 months.
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE Disposing of the EPAC Like all electrical and electronic equipment, your EPAC contains substances which are harmful to the environment and human health, as well as materials which can be reused and recycled. In the European Economic Area (EEA) you are therefore obliged to keep your EPAC separate from the domestic waste and make use of a return and collection system.
EPAC and sends it to the firm GHOST-Bikes. Alternatively, you can complete an online registration on the GHOST website. The guarantee period begins with the purchase of the EPAC by you as the end-customer from an authorised dealer. If the guarantee card is not returned to the firm GHOST- Bikes or the EPAC is not registered online, no guarantee will apply.
Page 85
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE E3: Quick-release axle E4: Quick-release lever • Illustration F F1: Click pedal F2: Switch, gear lever • Illustration G G1: Valve nut G2: Valve cap G3: Valve G4: Inner tube • Illustration I...
Page 86
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE I1: Tyre lever (appearance varies according to manufacturer) Original operating instructions 12/2012...
Page 87
E-HYBRIDE CROSS GHOST EPAC E-HYBRIDE TREKKING E-HYBRIDE WAVE About us Manufacturer: GHOST Bikes GmbH An der Tongrube 3 95652 Waldsassen Germany Phone: +49 9632 92550 Fax: +49 9632 925516 www.ghost-bikes.com info@ghost-bikes.de Original operating instructions 12/2012...
Page 88
GHOST-Bikes GmbH An der Tongrube 3 D-95652 Waldsassen www.ghost-bikes.com...
