Winmate E430x Quick Start Manual

How to Start your E430x
• Before you remove the back cover, make sure the
E430x is power off.
Make the E430x facing down, and then unscrew the screws of E430x.
1.
Gently pull E430x out of its back cover.
2.
Pull the plastic strap, and then remove the battery.
3.
Insert the SIM card (with its gold contacts facing down and cut-off
4.
corner facing out) all the way into the SIM card slot.
Caution! Please make sure you have removed both the battery
and USB cable while inserting SIM card.
Push the metal cover backward and lift the metal cover. Then put
5.
the SD card into the socket, close the metal cover and push
forward till click sound.
Reinsert the battery.
6.
Fix the back cover with screws.
7.
Use the bundled power adapter and USB cable to charge E430x
8.
for 4hrs.
E430x
Quick Start Guide
v1.0
For the complete user manual and other
helpful resources, go to Winmate website
www.winmate.com.tw
